The following tables describe the use of RF connectors and the system LEDs on top of the
FEX-511F casing.
LED
Power
LTE Mode
5G Mode
Management
FortiSASE/LAN
Extension
Bluetooth
10
FortiExtender-511F-QuickStart.indd 10
FortiExtender-511F-QuickStart.indd 10
Description
•
Green Steady: System has booted up and is working properly.
•
Green Flashing: System is booting up.
•
Amber: System is in error state.
•
OFF: System is powered off.
•
Green: System is running in LTE connection mode.
•
OFF: System is not in LTE mode.
•
Blue: System is running in 5G connection mode.
•
OFF: System is not in 5G mode.
•
Blue Steady: System is managed by FortiGate or
FortiExtender Cloud.
•
Blue Flashing: System is connecting to a managing device.
•
OFF: System is running in stand-alone mode.
•
Blue Steady: System is connected to FortiSASE/LAN
Extension.
•
Blue Flashing (at one-second intervals): System is connecting
to
FortiSASE/LAN Extension.
•
Blue Flashing Rapidly (at less-than-one-second intervals):
System is experiencing an error in connecting to FortiSASE/
LAN Extension.
•
OFF: System is not configured for FortiSASE/LAN Extension.
•
Green:
Bluetooth configuration window opens upon
pressing the Bluetooth
configuration occurs.
•
Blue Flashing: Bluetooth configuration is in progress.
•
Blue Steady: Bluetooth configuration is completed. The LED
turns off in 5 seconds.
•
OFF: No Bluetooth configuration is allowed.
button. It closes in 30 seconds if no
