Smeg LSP367X Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Questo manuale d'istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per
il tuo prodotto tra le
migliori offerte di Lavastoviglie
Contents
1.
Description of the controls ________________________________ 2
2.
Operating instructions ___________________________________ 16
3.
Cleaning and maintenance _______________________________ 31
4.
Troubleshooting _______________________________________ 35
Thank you for choosing one of our products.
You are advised to read this manual carefully; it contains all the
information you need use your dishwasher safely, correctly and in the
most satisfactory manner.
Following the cleaning instructions provided here will keep your
dishwasher's performance at peak levels in the long term.
USER INSTRUCTIONS: these consist of recommendations for using the
appliance, a description of its controls and of the correct cleaning and
maintenance procedures.
Smeg LSP367X
o cerca
1

Advertisement

loading

Related Manuals for Smeg LSP367X

Summary of Contents for Smeg LSP367X

  • Page 1 Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Smeg LSP367X o cerca il tuo prodotto tra le migliori offerte di Lavastoviglie Contents Description of the controls ________________________________ 2 Operating instructions ___________________________________ 16 Cleaning and maintenance _______________________________ 31 Troubleshooting _______________________________________ 35 Thank you for choosing one of our products.

  • Page 2: Description Of The Controls

    User instructions 1. Description of the controls Front panel All the dishwasher controls are grouped on the front panel. ON/OFF BUTTON SELECTION PROGRAM BUTTONS (P1…P5) OPTION SELECTION BUTTON CONFIRM OPTIONS BUTTON DELAY PROGRAM BUTTON START/PAUSE BUTTON POWER ON LIGHT PROGRAMS INDICATOR LIGHTS INFORMATION DISPLAY RECESSED DOOR HANDLE N.B.: symbols and styling are guideline and may vary depending on...
  • Page 3 User instructions Information display The dishwasher is equipped with a practical DISPLAY which provides information on the programmed dishwasher functions. 4-FIGURE DISPLAY RINSE AID WARNING LIGHT SALT WARNING LIGHT START/PAUSE BUTTON OPTIONS LIGHT PROGRAMS TABLE The manual contains the programs table for several models. To find the table for your dishwasher, compare the program symbols at the top of the table with those on your control panel.
  • Page 4 User instructions PROGRAMS TABLE DURATION CONSUMPTION PROGRAMME LOAD CROCKERY AND PROGRAM NUMBER CUTLERY PROGRESS MINUTES POWER WATER & SYMBOL KWh (1) LITRES 1 SOAK Pans and dishes awaiting 0,02 Cold prewash completion of the load Wash at 45° C 2 GLASS Glass, china and mixed Cold rinse 1,10...
  • Page 5 User instructions QUICK TIME PROGRAMS (see relevant section for explanation of functioning modes) LOAD CROCKERY AND DURATION CONSUMPTION PROGRAMME CUTLERY PROGRAM MINUTI WATER POWER NUMBER E PROGRESS LITRES KWh (1) SYMBOL RAPID 27’ Dishes with light dirt, Wash at 38° C 0,70 washed immediately after Rinse at 50°...
  • Page 6 User instructions PROGRAMS TABLE DURATION CONSUMPTION PROGRAMME LOAD CROCKERY AND PROGRAM NUMBER MINUTES POWER CUTLERY PROGRESS WATER & SYMBOL kWh (1) LITRES 1 RAPID 27’ Dishes with light dirt, Wash at 38° C 0,70 washed immediately after Rinse at 50° C Wash at 45°...
  • Page 7 User instructions QUICK TIME PROGRAMS (see relevant section for explanation of functioning modes) DURATION CONSUMPTION PROGRAMME PROGRAM LOAD CROCKERY AND NUMBER E PROGRESS MINUTI WATER POWER CUTLERY SYMBOL LITRES kWh (1) 6 SOAK Pans and dishes awaiting 0,02 Cold prewash completion of the load DELICATE Cold prewash...
  • Page 8 User instructions NOTES AND REFERENCES Only run the soak program with half loads. Options cannot be used with the soak program. The ENERSAVE option cannot be used with soak, ultra clean, or any programs which do not include the final drying stage. Standard programme under EN 50242.
  • Page 9 User instructions Washing programs The dishwasher is equipped with a control panel and an INFORMATION DISPLAY from which it is possible to carry out all the power switch-on, switch-off and programming operations. Before starting a washing program make sure that: •...
  • Page 10 User instructions START PROGRAM At this point, in order to start the machine, it is only enough to press the START/PAUSE (6) for some seconds until the symbol START/PAUSE (D) start to flash and confirmation “beep” is heard. From this moment the cycle duration on the DISPLAY (9) starts to decrease.
  • Page 11 User instructions STOPPING A PROGRAM To cancel a program which is running: • Interrupt the program (see " ") INTERRUPTING A PROGRAM • Press the START/PAUSE button and hold it down; the display will show "P0" and the dishwasher will immediately switch to the end of the cycle and drain the tank (during this process, the "START/PAUSE symbol will flash).
  • Page 12 User instructions PROGRAM DELAY The PROGRAM DELAY button can be pressed to delay the start of the washing program by from 1 to 12/24 hours depending on the model. This option allows the dishwasher to be operated at the time of day of the user's choice.
  • Page 13 User instructions OPTIONS The options are controlled by the OPTION SELECTION button Press the button to access the procedure, confirmed by flashing of one of the OPTIONS lights (E). N.B.: The PROGRAM DELAY light only comes on when the specific PROGRAM DELAY button is pressed.
  • Page 14 User instructions ENERSAVE This option can be selected with the wash programme of choice to further reduce energy consumption. Drying is aided by a special device that automatically releases the door, which opens slowly and smoothly by a few centimetres. This ensures perfect drying and greater control of rinsing temperatures, which can be kept at lower levels for significant energy saving.
  • Page 15 User instructions These products are not suitable for use with excessively “hard” water. If the hardness level set is higher than H3, when the option is activated the relative light flashes to indicate that the product is being used incorrectly; the dishwasher will still work, but washing results may be poor.

  • Page 16: Operating Instructions

    User instructions 2. Operating instructions Once the dishwasher has been correctly installed, prepare for use as follows: • Adjust the water softening system; • Add the regenerating salt; • Add the rinse aid and detergent. Using the water softening system The amount of scale contained in the water (water hardness index) can cause whitish staining on the dry dishes, which...
  • Page 17 User instructions • Do not use table salt as it contains insoluble substances which, over time, may damage the water softening system. • When necessary, refill the regenerating salt container before starting the washing program. In this way, the excess saline solution will be immediately removed by the water;...
  • Page 18 User instructions WATER HARDNESS TABLE WATER HARDNESS SETTING German degrees (° dH) French Degrees (° dF) H 0 NO SALT 0 - 6 0 - 11 7 - 10 12 - 18 11 - 15 19 - 27 16 - 21 28 - 37 22 - 28 38 - 50...
  • Page 19 User instructions ADDING THE RINSE AID The rinse aid helps the dishes dry faster and prevents the formation of scale deposits and staining; it is automatically added to the water during the final rinse cycle, from the container situated on the inner side of the door. To add rinse aid: •...
  • Page 20 User instructions ADDING THE DETERGENT To open the detergent dispenser cap, lightly press the button P. Add the detergent and close the cap carefully. During the washing cycle, the dispenser will be opened automatically. • When a program with hot prewash is selected (see program table), extra detergent must be placed in the cavity G/H (depending on models).
  • Page 21 User instructions The introduction of detergent into the rinse aid dispenser, even in liquid form, will damage the dishwasher. General warnings and recommendations Before using the dishwasher for the first time, it is advisable to read the following recommendations concerning dish types to be washed and their loading.
  • Page 22 User instructions WARNING! • Make sure that the dishes are securely in place so that they cannot tip over or obstruct the rotation of the spray arms during the washing cycle. • Do not place very small objects in the baskets as these could fall and obstruct the spray arms or the wash pump.
  • Page 23 User instructions Using the baskets The dishwasher has a capacity of 13 place-settings, including serving dishes. LOWER BASKET The lower basket receives the full force of the lower spray arm, and should therefore be used for the “toughest” items with a heavier degree of soiling.
  • Page 24 User instructions LOADING THE LOWER BASKET Carefully load flat plates, soup plates, dessert and serving dishes, positioning them vertically. Pots, pans and their covers must be loaded upside down. When loading soup plates and dessert bowls, be sure to leave a gap between them. Loading examples: UPPER BASKET It is recommended to load the upper basket with small- or medium-sized...
  • Page 25 User instructions CUTLERY BASKET The basket has removable top grids into which items of cutlery should be inserted to keep them properly spaced and allow water to pass between them effectively. The top grids and central lid are in the bag of accessories.
  • Page 26 User instructions FLEXI DUO TOP RACK (on some models only) This comprises two independent sliding, pull-out tray racks for easier loading/unloading of cutlery. Various loading systems and configurations are possible. For example, tea cups can be loaded with the right-hand rack set in the low position, while the left-hand rack or both can be removed to allow large dishes to be put in the top basket...
  • Page 27 User instructions Examples of loading for intensive dirt...
  • Page 28 User instructions Examples of loading for intensive dirt FLEXI DUO TOP RACK (on some models only)
  • Page 29 User instructions Depending on the models, the basket may be equipped with some or all of the following accessories: Supports for cups or long objects (ladles, spoons…), on the left; can be tipped to the vertical position when not in use. Long-stemmed glass holder, on the left;...
  • Page 30 User instructions ADJUSTING THE UPPER BASKET The height of the top basket can be adjusted to allow large dishes or pans to be placed in the bottom basket. The adjustment procedure may be type A or B, depending on the dishwasher model purchased.

  • Page 31: Cleaning And Maintenance

    User instructions 3. Cleaning and maintenance Before carrying out any work, always unplug the appliance from the electrical supply or switch off the all-pole disconnection device. General warnings and recommendations Avoid the use of acidic or abrasive detergents. Clean the outer surfaces and door-lining of the dishwasher regularly using a soft cloth moistened with water or with a normal detergent suitable for painted surfaces.
  • Page 32 User instructions CLEANING THE FILTER UNIT • It is advisable to periodically inspect the centre filter C and, if necessary, to clean it. To remove the filter, grip the tabs, turn them anticlockwise and lift upwards; • push the centre filter D from the underside to remove it from the micro-filter: •...
  • Page 33 User instructions BEFORE STARTING THE DISHWASHER AFTER PROLONGED DISUSE: • Check that there are no deposits of sludge or rust inside the water pipe: if there are, allow the water to run from the water supply tap for a few minutes. •...
  • Page 34 User instructions If the dishes fail to dry or remain dull, check that: • there is rinse aid inside the special container; • the rinse aid dispenser setting is correct; • the detergent used is of good quality and has not lost its effectiveness (for example, through incorrect storage, with the box left open).

  • Page 35: Troubleshooting

    User instructions 4. Troubleshooting The dishwasher is equipped with a self-diagnostics system that is capable of detecting and signalling a number of possible faults. TABLE OF FAULTS DETECTED BY THE SELF-DIAGNOSTICS SYSTEM FAULT DESCRIPTION The anti-flooding system (where present) has been tripped service. Er 01 The water level limitation system has tripped.
  • Page 36 User instructions TECHNICAL DATA 597 ÷ 599 mm Width Depth measured flush with the Free standing: 600 mm outer edge of the control panel Semi-integrated: 570 mm Free standing: from 850 mm to 890 mm from 890 mm to 930 mm Height (depending on models) Semi-integrated: from 820 mm to 890 mm from 860 mm to 930 mm...
