Smeg LSP252CSX Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Sommario
1

General safety instructions _______________________________ 2

2.
Installation ____________________________________________ 9
3.

Description of the controls _______________________________ 15
4.

Operating instructions __________________________________ 21
5

Cleaning and maintenance ______________________________ 22
6

Troubleshooting _______________________________________ 23
Thank you for choosing one of our products.
You are advised to read this manual carefully; it contains all the
information you need about the right conditions for the proper, safe use
of your dishwasher.
This manual contains only the basic information required to use the
appliance. The complete manual can be obtained from
www.smeg.com/download-manuals
by entering the product code shown on the plate attached to the inner
right hand edge of the dishwasher door.
The manual can be accessed quickly via the QR code using a device
with a QR reader application.






1

Advertisement

loading

Related Manuals for Smeg LSP252CSX

Summary of Contents for Smeg LSP252CSX

  • Page 1: Table Of Contents

    This manual contains only the basic information required to use the appliance. The complete manual can be obtained from www.smeg.com/download-manuals by entering the product code shown on the plate attached to the inner right hand edge of the dishwasher door.

  • Page 2: General Safety Instructions

    Warnings TRANSLATION OF THE ORIGINAL INSTRUCTIONS 1 General safety instructions  This manual is an integral part of the appliance; it must always be kept intact together with the dishwasher for future reference (even if sold). Before using appliance, carefully read instructions contained in this manual.
  • Page 3 Warnings  Never leave waste packaging unattended. Do not allow children to play with packaging materials. Separate waste packaging materials by type and consign them to the nearest recycling centre.  The plate with the technical data, serial number and marking is in a visible position on the inside edge of the door.
  • Page 4 Warnings  Building-in the appliance underneath a hob is absolutely forbidden. Installing a hob on top of free- standing appliance is absolutely forbidden.  To ensure stability, install the appliance only under continuous worktop, securely fixed to adjacent cabinets. If the appliance is installed in a high cabinet, both the appliance and the cabinet must be adequately fixed.
  • Page 5 Warnings  The appliance must be connected to the water supply by means of new hoses.  Briefly test the appliance after installation. Run a wash cycle with a temperature of between 45 and 70°C with the dishwasher empty and using a specific dishwasher detergent.
  • Page 6 Warnings suffocation. Observe all the safety instructions on the packaging of these products.  Do not drink the water residues which may be present on the dishes or appliance at the end of the washing program.  Never place solvents such as alcohol or turpentine, which are potentially explosive, inside the appliance.
  • Page 7 Warnings have it replaced by the manufacturer or an authorised technical service centre.  Some components are live even with the on/off button in the off position. Before performing any maintenance work on the appliance, disconnect it from the electrical power supply. ...
  • Page 8 Warnings 1.1 Declaration of conformity The appliance complies with the essential requirements of the following European directives: - 2009/125/EC - 2011/65/EU - 2014/35/EU - IEC/EN 62471, risk group 1, for models with internal lighting.  IEC/EN 61770 1.2 Disposal This appliance must be disposed of separately from other waste (directives 2012/19/EC).

  • Page 9: Installation

    Installation 2. Installation 2.1 Technical characteristics Water supply pressure min. 0,05 - max. 0,9 MPa (min. 0.5 – max. 9 bar) Water supply temperature max. 60°C Capacity 12-13 standard place settings Class of protection against IPX0 moisture Protection against electric class I shock Electrical data...
  • Page 10 Installation 2.2 General Information  This appliance may be placed up against walls or other furniture units.  If the appliance is installed near a heat source, fit a special insulating panel to prevent overheating and malfunction of the appliance. ...
  • Page 11 Installation Building-in a dishwasher underneath a hob is absolutely forbidden. Moreover, dishwashers may not be installed directly touching appliances which are not conventional built-in kitchen appliances (e.g. fireplaces, stoves, etc.). When installing the dishwasher in a compartment next to one or more other appliances, it is essential to comply with all the recommendations provided appliance’s manufacturer...
  • Page 12 Installation 2.3 Water supply connection CONNECTING TO THE WATER SUPPLY Connect the intake hose to a cold water supply with ¾” gas thread, inserting the filter A supplied with the dishwasher. Take care to screw the hose firmly into place with your hands and then complete by tightening about ¼...
  • Page 13 Installation DRAIN CONNECTION Insert the dishwasher’s drain hose into a drain pipe having a diameter of at least 4 cm, or alternatively, place it inside the kitchen sink using the plastic support provided, taking care not to crush or excessively bend the hose.
  • Page 14 Installation 2.4 Electrical connection Check that the voltage and the frequency of the mains match the ratings on the name plate of the appliance positioned on the inner edge of the door.  The plug on the supply cord and the corresponding socket outlet must be of the same type and meet the regulations in force.

  • Page 15: Description Of The Controls

    Istruzioni per l'utente 3. Description of the controls 3.1 Front panel All the dishwasher controls are grouped on the front panel. Programming and option selection are only possible with the door closed. ON/OFF BUTTON AND WARNING LIGHT OPTION SELECTION BUTTONS AND WARNING LIGHTS “CHILD LOCK”...
  • Page 16 Istruzioni per l'utente SWITCHING ON When the ON/OFF button (1) is pressed, the dishwasher switches on. The indicator lights will display the dishwasher's "status". PROGRAMMING Programming operations are only possible with the door closed. As long as the door is open, the PROGRAMS (8) lights remain off. PROGRAM SELECTION Press the PROGRAM SELECTION button (6) several times until the light of the program required comes on.
  • Page 17 Istruzioni per l'utente INTERRUPTION A PROGRAM To interrupt a program in progress:  press the START/PAUSE button (7); the light of the program in progress remains on (confirmation beep);  you may now restart the program by pressing button (7) again until it restarts, or change or annul the program (see "C HANGING ", or "A...
  • Page 18 Istruzioni per l'utente PROGRAMS TABLE Program CRYSTAL 45° ● 45°C 1,15 cold ● 52°C cold 0,735 (*)(**) MIX 65° ● cold 65°C cold 1,35 FULL EXPRESS 60’ ● 65°C cold 1,40 HYGIENE 99,9% ● cold 70°C 1,20 cold Automatic door opening – Dry Assist Automatic door opening is included in programs indicated with ** in the first column.
  • Page 19 Istruzioni per l'utente AUTOMATIC DOOR OPENING – DRY ASSIST (always included in the ECO program) The program ends with a drying cycle that consists of a time during which the door is closed, and a time during which the door is slightly open (just waiting, to assist drying).
  • Page 20 Istruzioni per l'utente Option Description Modifies some of the parameters to ensure 1 EXTRA DRY improved drying. Allows the wash cycles 1 or 3 to be delayed by up 2 DELAY to 9, 12 or 24 hours depending on the models. “CHILD LOCK”...

  • Page 21: Operating Instructions

    Istruzioni per l'utente 4. Operating instructions After having installed the dishwasher, remove the basket retainers. 4.1 Adding the salt The salt prevents the formation of scale deposits.  Unscrew the cap of the salt container.  Only for the first time, fill the container with a litre of water.

  • Page 22: Cleaning And Maintenance

    Istruzioni per l'utente Cleaning and maintenance Before carrying out any work, always unplug the appliance from the electrical supply or switch off the omnipolar circuit breaker. CLEANING THE WATER INTAKE FILTER Close the water supply tap, unscrew the end of the water intake hose, remove the filter A and clean it under running water.

  • Page 23: Troubleshooting

    Istruzioni per l'utente 6 Troubleshooting The dishwasher is equipped with a self-diagnostics system that is capable of detecting and signalling a number of possible faults. FAULT DESCRIPTION Acquastop failure The anti-flooding system has been activated (for the relevant models only). The system is tripped in case of water leaks.
  • Page 24 Istruzioni per l'utente FAULT DESCRIPTION Turbine flow-regulator malfunction (for the relevant models only) The appliance is not able to "measure" the amount of water loaded accurately. Interrupt the program and switch off the dishwasher. Switch the dishwasher back on, program it again and start the washing cycle.
