Samsung HM1900 User Manual

www.samsung.com
Please read this manual before operating your headset, and keep it for future reference.
Understand all safety precautions before using your headset to ensure safe and proper
use.
Graphics used in this manual are for illustration purposes. The actual products may vary.
Safety precautions
When using your headset while driving, follow local regulations in the region you are in.
• Never disassemble or modify your headset for any reason. Doing this may cause the
headset to malfunction or become combustible. Bring the headset to an authorised
service centre to repair it.
• Keep your device and all accessories out of the reach of small children or animals.
Small parts may cause choking or serious injury if swallowed.
• Avoid exposing your device to very cold or very hot temperatures (below 5 °C or
above 35 °C).
Extreme temperatures can cause the deformation of the device and reduce the
charging capacity and life of your device.
• Do not allow your device to get wet — liquids can cause serious damage. Do not
handle your device with wet hands. Water damage to your device can void your
manufacturer's warranty.
• Avoid using your device's light close to the eyes of children or animals.
• Do not use the device during a thunderstorm. Thunderstorms can cause the device
to malfunction and increase the risk of electric shock.
Excessive exposure to loud sounds can cause hearing damage. Exposure to
loud sounds while driving may distract your attention and cause an accident.
Use only the minimum volume setting necessary to hear your conversation.
Instructional icons
Before you start, familiarise yourself with the icons you will see in this manual:
Warning—situations that could cause injury to yourself or others
Caution—situations that could cause damage to your device or other
equipment
Note—notes, usage tips, or additional information
Getting started
Your headset overview
Ear hook
Talk button
Volume button
Earpiece
Indicator light
Make sure you have the following items: headset, travel adapter, ear hook,
ear rubbers and user manual. The supplied items may vary.
Button functions
Button Function
Power
Slide to turn the headset on or off.
switch
•
Press and hold for 3 seconds to enter Pairing mode.
•
Press to answer or end a call.
•
Talk Press and hold to reject an incoming call.
•
Press and hold to place a call on hold.
•
Press and hold to switch between calls.
•
Press to adjust the volume.
Volume
• Press and hold to turn the microphone on or off during a call.
-1-
Turning the headset on or off
HM1900
To turn the headset on
User manual Slide the Power switch on. The blue indicator light flashes 4 times.
Turning the headset on for the first time, it will automatically enter pairing mode
for approx. 3 minutes.
To turn the headset off
Slide the Power switch off. The indicator light flashes blue and red then turns off.
Printed in China
GH68-36873C
English. 09/2012. Rev. 1.1
Charging the headset
This headset has a rechargeable internal battery which is non-removable. Make sure the
headset is fully charged before using it for the first time.
Use only Samsung-approved chargers. Unauthorised or Non-Samsung chargers
could cause damage to the headset or in extreme circumstances an explosion, it
could also invalidate any warranty on the product.
1
Connect the travel adapter to the charging socket on the headset.
2
Plug the travel adapter in to the wall socket. During charging, the indicator light will
turn red. If charging does not begin, unplug the travel adapter and plug it in again.
3
When the headset is fully charged, the red indicator light changes to blue. Unplug
the travel adapter from the wall socket and the headset.
•
Repeatedly charging and discharging of the headset, over time will cause the
battery performance to diminish. This is normal for all rechargeable batteries.
•
Never make or receive calls while charging, always disconnect your headset
from the charger and answer the call.
Checking the battery level
To check the battery level, press and hold the Volume down button and the Talk button
at the same time. Depending on the battery level, the indicator light flashes 5 times in
one of the following colours:
Battery level
Above 80%
80 ~20%
Below 20%
When the headset battery is low
The headset indicator light flashes red and you can hear beeps. If the headset powers off
during a call, the call will be automatically transferred to the phone.
Wearing the headset
Depending on which ear you are going to wear the headset, simply adjust the ear hook
accordingly.
Charging socket
Power switch
Microphone
You can also use the optional ear rubbers instead of the ear hook. Remove
the earpiece cover and attach the ear rubber. Then, rotate the ear rubber left or
right slightly depending on which ear you are going to wear the headset.
Turning the indicator light on or off
The Headset status light is there to show you the current status of your headset, but if it
bothers you at night, you can turn it off.
•
Press and hold both Volume buttons simultaneously to turn the indicator light on
or off.
• You cannot switch the indicator off while in pairing mode.
• The indicator light will always work when the headset is turned on or off, when
a call is received, in Pairing mode and when the battery is low.
Using your headset
To ensure you get the best performance from your headset
•
•
•
Pairing and connecting the headset
Pairing means a unique and encrypted wireless connection between two Bluetooth
devices when they agree to communicate with each other.
In Pairing mode, two devices should be placed close enough.
Pairing and connecting the headset with a phone
1
2
3
Pairing via the Active pairing feature
With the Active pairing feature, your headset automatically looks for a Bluetooth device
within range and tries to make a connection with it.
Make sure the phone's Bluetooth visibility option is set on.
•
Indicator light colour
Blue
Violet
Red
Connecting with two Bluetooth phones
With the Multi-point feature activated, your headset can be connected to 2 Bluetooth
phones at the same time.
To turn Multi-point feature on
In Pairing mode, press and hold the
Volume up button. The blue indicator
light flashes twice.
1
2
3
Left Right
4
5
Connecting the headset with a music device
You can also pair and connect your headset with a music device such as an MP3 player.
The process of connecting to a music device is the same as for connecting with a phone.
When connected to both devices (phone and music device) you can make or receive a
call on the phone while listening to music from the music device.
-2-
• Activated functions and features may differ depending on the phone type.
• Some devices, especially those that are not tested or approved by the
Bluetooth Special Interest Group (SIG), may be incompatible with your
headset.
Keep the distance between your headset and device as small as possible and avoid
placing your body or other objects in the signals path.
If you usually use your mobile phone with your right hand, wear the headset on your
right ear.
Covering your headset or device could effect its performance so keep contact
to a minimum.
Enter Pairing mode. (The blue indicator light stays lit and stays for 3 minutes.)
• Press and hold the Talk button for 3 seconds.
Activate the Bluetooth feature on your phone and search for the headset (see your
phone's user manual).
Select the headset (HM1900) from the list of devices found by your phone.
• If requested, enter the Bluetooth PIN 0000 (4 zeros) to pair and connect the headset
to your phone.
• Once pairing is completed, the headset will attempt to reconnect each time you
turn it on.
In Pairing mode, press and hold the Talk button on the headset. The indicator light
colour changes to violet from blue. The headset will attempt active paring for up to
20 seconds.
•
The Bluetooth phone you want to connect with must not be paired
with other devices. If the phone is already connected to another device,
end the connection and restart the Active pairing feature.
• This feature may not be supported on some devices.
To turn Multi-point feature off
In Pairing mode, press and hold the
Volume down button. The red indicator
light flashes twice.
After connecting with the first Bluetooth phone, enter Pairing mode again.
Activate the Bluetooth feature on the second Bluetooth phone and search for the
headset (see your phone's user manual).
Select the headset (HM1900) from the list of devices found by the second Bluetooth
phone.
If requested, enter the Bluetooth PIN 0000 (4 zeros) to connect the headset to the
second Bluetooth phone.
Reconnect to the headset from the first Bluetooth phone.
Some phones may not be able to connect as a second Bluetooth phone.
You cannot control playback using your headset.
-3-
