CHESTERFIELD
TRADITIONAL 60
Use and Installation Instructions
This appliance must be installed in accordance with the regulations in force and only used in
a well ventilated space.
Read these instructions before installing or using the appliance and retain them for future
reference.
Part no. 195056853.01
Advertisement
Table of Contents
Related Manuals for Cannon Chesterfield Traditional 60 C60GC
Summary of Contents for Cannon Chesterfield Traditional 60 C60GC
- Page 1 CHESTERFIELD TRADITIONAL 60 Use and Installation Instructions This appliance must be installed in accordance with the regulations in force and only used in a well ventilated space. Read these instructions before installing or using the appliance and retain them for future reference.
-
Page 2: Table Of Contents
Introduction For Your Safety Oven Timer Operation Hotplate Grill Main Oven Main Oven Cooking Chart The “Slow Cook” Setting Top Oven Top Oven Cooking Chart Care and Cleaning Something Wrong with your cooker? Installation Instructions Service Information CONTENTS PAGE Back Cover... -
Page 3: Introduction
To help you make the best use of your cooker, PLEASE READ THIS BOOKLET CAREFULLY. Your new cooker is guaranteed and will give lasting service. The guarantee is only applicable if the cooker has been installed in accordance with the Installation Instructions. -
Page 4: For Your Safety
Please read the precautions below before using your cooker. ALWAYS . . . ALWAYS make sure you understand the controls before using the cooker. ALWAYS check that all controls on the cooker are turned off after use. ALWAYS stand back when opening an oven door to allow heat to disperse. ALWAYS use dry, good quality oven gloves when removing items from the ovens. - Page 5 NEVER . . . NEVER leave children unsupervised where the cooker is installed as all surfaces will get hot during and after use. NEVER allow anyone to sit or stand on any part of the cooker. NEVER store items that children may attempt to reach above the cooker. NEVER heat up unopened food containers as pressure can build up causing the container to burst.
-
Page 6: Oven Timer Operation
OVEN TIMER OPERATION The oven timer offers you the following features: 1. Time of Day 2. Automatic Cooking 3. Minute Minder AUTOMATIC COOKING The main oven can be controlled automatically. GUIDANCE ON AUTOMATIC COOKING 1. Select foods which will take the same time to cook. 2. - Page 7 OVEN TIMER OPERATION CLOCKFACE The timer incorporates a 24 hour clock. Ensure the correct time of day is always set, before using your cooker. SYMBOLS A ‘bell’ symbol will light up when you select a Minute Minder Period and will remain lit for the period set.
- Page 8 OVEN TIMER OPERATION SETTING THE TIME OF DAY Step 1 Make sure all oven controls are turned Off. Step 2 Check the electricity supply to the cooker is turned on. Step 3 When switched on the display will show 0.00 and the Auto symbol, Step 4 Press &...
- Page 9 OVEN TIMER OPERATION AUTO COOKING PROGRAMMES There are two Auto Cooking programmes that can be selected using your timer:– (a) To set the timer to switch the oven(s) On and Off Automatically (b) To set timer to switch on immediately and OFF automatically after a set cook period. a) TO SET THE TIMER TO SWITCH THE OVEN(S) ON AND OFF AUTOMATICALLY This allows you to cook at a specified time for a chosen period before the oven switches off Automatically.
- Page 10 OVEN TIMER OPERATION Note 1 When cooking automatically the Cook Period can be checked at any time by simply pressing the Cook Period button. Note 2 When cooking automatically the End Time can be checked at any time by simply pressing the End Time button.
- Page 11 OVEN TIMER OPERATION TO CANCEL AN AUTO COOKING PROGRAMME BEFORE THE COOK PERIOD HAS FINISHED. Step 1 Turn the oven control(s) to the OFF position. Step 2 Press the Manual button to return the oven(s) to “Manual” operation. Note 1 When cooking automatically the Cook Period can be checked at any time by simply pressing the Cook Period button.
-
Page 12: Hotplate
The hotplate lid is fitted with a safety device which cuts off the gas supply to the hotplate burners unless the lid is fully open. Do not use the safety device as a means of controlling the hotplate burners. The hotplate has two high speed burners and two simmering burners which will accommodate pans between 100mm (4”) and 240mm (9 be positioned centrally over the burners. - Page 13 SAFETY REQUIREMENTS FOR DEEP FAT FRYING 1. Never fill chip pans more than one third full with oil or fat. 2. Never leave oil or fat unattended during the heating or cooling period. 3. Never heat fat or fry with a lid on the pan. 4.
-
Page 14: Grill
CAUTION – ACCESSIBLE PARTS MAY BECOME HOT WHEN THE GRILL IS USED. YOUNG CHILDREN SHOULD BE KEPT AWAY. The grill is fitted with a safety device that will cut off the gas supply to the burner if the flame is extinguished for any reason. Each time the grill is used, the safety device has to be activated by pushing and holding in the control knob for 3 seconds after the gas has lit. - Page 15 TO USE THE GRILL 1. Open the top oven/grill door and withdraw the grill pan. 2. Remove the heat shield from the rear of the shelf for maximum grilling area and place shelf in appropriate position - (Chesterfield only). 3. Push in and turn the control knob clockwise to the large flame symbol. Continue to push in the control knob for a further 3 seconds after the gas has lit, to allow time for the safety device to operate.
-
Page 16: Main Oven
The main oven is fitted with a safety device that re-lights the burner if the flame has been extinguished for any reason and another safety device that reduces the gas flow to a safe level if, for any reason, the burner fails to light. The oven has different heat zones –... - Page 17 COLD START COOKING Anything requiring long slow cooking such as casseroles and rich fruit cakes can be put into a cold oven. Satisfactory results can also be obtained with creamed mixture, rich pastries or yeast mixtures, but for perfection we recommend preheating the oven for about 15 minutes at the gas mark you require for cooking.
-
Page 18: Main Oven Cooking Chart
MAIN OVEN COOKING CHART The following times and setting are for guidance only. You may wish to alter the set- ting to give a result more to your satisfaction. When a different setting to that shown below is given in a recipe, the recipe instructions should be followed. Allow 15 minutes preheat for best results. - Page 19 MAIN OVEN COOKING CHART Food CAKES, PASTRIES AND BISCUITS Small cakes - 2 trays - 1 tray Victoria sandwich 2x8" (205mm) Fatless sponge 2x7" (180mm) - 3 egg mix Christmas cake Madeira cake 7" (180mm) Rich Fruit cake 9" (230mm) Shortcrust pastry Rich Shortcrust pastry - 1 tray Flaky &...
-
Page 20: The "Slow Cook" Setting
THE ‘SLOW COOK’ SETTING The ‘Slow Cook’ setting on the main oven thermostat is used for slow cooking, keeping food warm and warming plates for short periods. USING THE ‘SLOW COOK’ SETTING FOR SLOW COOKING 1. All dishes cooked by the ‘Slow Cook’ setting should be cooked for a minimum 6 hours. -
Page 21: Top Oven
The top oven can be used to cook small quantities of food or used in conjunction with the main oven to provide additional cooking space. The top oven is fitted with a safety device that will cut off the gas supply to the burner if the flame is extinguished for any reason. -
Page 22: Top Oven Cooking Chart
TOP OVEN COOKING CHART The following times and setting are for guidance only. You may wish to alter the set- ting to give a result more to your satisfaction. When a different setting to that shown below is given in a recipe, the recipe instructions should be followed. Allow 15 minutes preheat for best results. - Page 23 TOP OVEN COOKING CHART Food CAKES, PASTRIES AND BISCUITS Small Cakes (16 per tray) Victoria sandwich (2 x 180mm / 7”) Swiss Roll (3 egg quantity) Christmas cake (1 x 205mm / 8”) Madeira cake (1 x 180mm / 7”) Rich Fruit cake (1 x 180mm / 7”) Gingerbread Scones - 16 per tray...
-
Page 24: Care And Cleaning
CARE AND CLEANING Switch off the electricity supply and allow to cool before cleaning the cooker. Clean the cooker regularly and wipe up spills soon after they occur to prevent them from becoming burnt on. Never use biological washing powder, caustic cleaners, harsh abrasives, scouring pads, steam cleaners, aerosol cleaners or oven chemical cleaners of any kind. - Page 25 CARE AND CLEANING COOKER FINISH Vitreous Enamel Hotplate, pan supports, burner caps, roasting dish, grill pan, main oven base, inside of grill compartment Paint Control panel (trim), side panels, doors (trim). Aluminium Hotplate burner bodies, lid rear trim. Glass Chromium Plating Oven shelves, grill pan grid, grill pan handle support Plastic...
-
Page 26: Something Wrong With Your Cooker
SOMETHING WRONG Before contacting your Service Centre or Installer, check the problem guide below, there may be nothing wrong with your cooker. PROBLEM Burner will not light: Grill burner Burner ports Ignitor Hotplate burner Burner ports Ignitor WITH YOUR COOKER CHECK If all burners fail to ignite: Check that sparks appear at the burners;... -
Page 27: Something Wrong
SOMETHING WRONG WITH YOUR COOKER PROBLEM Slight odour or small amount of smoke when grill / oven used first time Oven cooks too fast or too slow Cannot set an “Auto Cook” programme or cannot get the timer to turn the oven on or off at the required times. -
Page 28: Installation Instructions
INSTALLATION INSTRUCTIONS Prior to installation, ensure that the local distribution conditions (nature of the gas and gas pressure) and the adjustment conditions are compatible. The adjustment conditions for this appliance are stated on the data badge which is fitted on the back panel. - Page 29 INSTALLATION INSTRUCTIONS TECHNICAL DATA Gas connection Pressure test point Gas rate adjustment Aeration adjustment Electrical connection BURNER HOTPLATE Front left and rear right HOTPLATE Front right and rear left GRILL MAIN OVEN TOP OVEN ” BSP female) Front left hotplate injector None None Flexible cord fitted with a 3 pin 13 amp plug...
- Page 30 INSTALLATION INSTRUCTIONS SPACE FOR FIXING The cooker can be close fitted below hotplate level. This requires a minimum distance of 600mm between cupboard units of hotplate height. When installing next to a tall cupboard, partition or wall, for a minimum distance of 400mm above hotplate level, allow a side clearance of at least 65mm.
- Page 31 INSTALLATION INSTRUCTIONS UNPACKING THE COOKER Unpack the components from inside the grill and oven: Check that the following parts are present. Grill pan and grid Baking dish Main oven shelves (2) Top oven/grill shelf (1) Aluminium burner bodies(4) LEVELLING Four skid feet are fitted which can be adjusted up or down to level the cooker. CONVERSION FOR USE ON BUTANE (G30) OR PROPANE (G31) Each burner requires the injector to be replaced and bypass screws adjusted or replaced as follows:...
- Page 32 INSTALLATION INSTRUCTIONS Remove the 6 screws securing the timer mounting panel. Without completely removing it, manoeuvre the timer mounting panel to gain access to the thermostat bypass screws. Using a narrow flat bladed screwdriver rotate the bypass screws fully clockwise. The main oven thermostat bypass screw is located on the body of the thermostat below the spindle, the top oven thermostat bypass screw is located on the body of the thermostat to the right of the spindle and the hotplate tap bypass screws are located...
-
Page 33: Electrical Connection
ELECTRICAL CONNECTION WARNING – THIS APPLIANCE MUST BE EARTHED. CONNECT TO A 230-240V A.C. SUPPLY ONLY. Connection to the electricity supply should be made via a properly earthed, readily accessible wall socket which is adjacent to but not directly above, and not more than 1.25m away from the appliance and capable of electrical isolation. - Page 34 INSTALLATION INSTRUCTIONS INSTALLATION AND OPERATIONAL CHECKS After installation, check for gas soundness. The supply pressure can be checked at the front left hotplate burner injector. Fit the hotplate burner bodies and caps, pan supports and shelf shield(s). Referring to the instructions for use where necessary, 1.
- Page 36 Extended Warranties UK 08709 088 088 Monday to Sunday, 8am to 8pm www.cannonservice.co.uk Republic of Ireland: 0123 002 333 UK: 08709 077 077 Monday to Friday, 8.30am to 5pm Saturday, 8.30am to 12noon www.cannonservice.co.uk Republic of Ireland: 0818 313 413 www.cannon.co.uk...
