Assembly Instructions - Stamina Active Aging EasyDecompress Owner's Manual

ASSEMBLY INSTRUCTIONS

Place all parts from the box in a cleared area and position them on the floor in front of you. Remove
all packing materials from your area and place them back into the box. Do not dispose of the packing
materials until assembly is completed. Read each step carefully before beginning. If you are missing
a part, please go to staminaproducts.com under the Customer Care section and order the part
needed, e-mail us at customer.care@staminaproducts.com, or call us toll free at 1-800-375-7520
(in the U.S.). Our Customer Care Staff is available to assist you from 7:30 A.M. to 5:00 P.M. (Central
Time) Monday through Thursday and 8:00 A.M. to 3:00 P.M. (Central Time) on Friday.
Some product parts are fit tested at the factory to ensure proper fit and alignment. Marks in
the paint may be noticeable, but are not an indication of damage.
STEP 1
Refer to the detail view. Pull out the PULL PIN(49) from the MAIN FRAME(1). Unfold the FRONT
SUPPORT(5) and lock in position with the PULL PIN(49). Attach the FRONT STABILIZER(6) to the FRONT
SUPPORT(5) with ACORN NUTS(M8x1.25)(55) and ARC WASHERS(M8)(56).
STEP 2
Pull the SPRING KNOB(16), then unfold the REAR SUPPORT(12) and lock in one of the incline positions
with the SPRING KNOB(16). Insert the REAR STABILIZER(3) into the REAR SUPPORT(12) and secure
with BUTTON HEAD BOLTS w/ WASHERS(M8x1.25x16mm)(13). Turn the LEVELING ENDCAPS(19)
on the REAR STABILIZER(3) as needed until the unit is steady and not rocking.
NOTE: There are three adjustment holes in the bracket on the MAIN FRAME(1) which allow the REAR
SUPPORT(12) to be attached in three different incline positions.
13
13
19
16
12
13
19
3
1
5
1
49
55
56
49
8
5
55
56
6
