Stamina Active Aging EasyDecompress Owner's Manual page 11

ASSEMBLY INSTRUCTIONS
STEP 8
Insert the FOOTBAR(10) into the SLIDING FRAME(8) and secure with HEX BOLTS(M6x1x35mm)(62),
WASHERS(M6)(67), and NYLOCK NUTS(M6x1)(63). The HEX BOLTS(M6x1x35mm)(62) must fit inside
the hex-shaped holes in the SLIDING FRAME(8) to properly secure the FOOTBAR(10).
STEP 9
Insert the ADJUSTABLE INSTEP FRAME(9) into the SLIDING FRAME(8) and lock in one of the adjustment
holes with the SHORT PULL PIN(59). Slide the FOAM PADS(53) on both ends of the ADJUSTABLE
INSTEP FRAME(9).
NOTE: There are four adjustment holes in the SLIDING FRAME(8) which allow the ADJUSTABLE INSTEP
FRAME(9) to be attached in four different positions. Find the position which is most comfortable
for holding your ankles while performing the back stretching exercise.
53
11
9
59
8
67
63
53
62
10
