DSW-1H
WIRELESS SUBWOOFER
Owner's Manual
1

Advertisement

Table of Contents
loading

Related Manuals for Denon DSW-1H

Summary of Contents for Denon DSW-1H

  • Page 1 Contents Setup Troubleshooting Status LED Appendix DSW-1H WIRELESS SUBWOOFER Owner’s Manual...
  • Page 2 Getting the HEOS app Setting up your first DSW-1H Adding more HEOS devices Adding wired HEOS devices Adding wireless HEOS devices Connecting devices Pairing a DSW-1H to a HEOS device Pairing DSW-1H to DHT-S716H Pairing DSW-1H to other HEOS device Unpairing the DSW-1H...
  • Page 3 Contents Setup Troubleshooting Status LED Appendix Updating your system Specifications Advanced features Information Wireless performance Trademarks Power management Power modes Quick Start Mode Deep Standby Basic troubleshooting My HEOS device won’t connect to my network using the audio cable My HEOS device turns off and the status LED flashes in red Connecting to a WPS network Resetting your HEOS device Status LED table...
  • Page 4 Introduction The DSW-1H is part of the HEOS wireless multi-room sound system that enables you to enjoy your favorite music anywhere and everywhere around your home. By utilizing your existing home network and the HEOS app on your iOS or Android™ device, you can explore, browse, and play music from your own music library or from many online streaming music services.

  • Page 5: Before Your Begin

    Ethernet network, a Wi-Fi connection to the router is required to control the system using the HEOS Control app. If you do not have a wireless network, please contact your local Denon dealer or electronics retailer to assist you with purchasing and installing a wireless network in your home.

  • Page 6: Hardware Requirements

    Contents Setup Troubleshooting Status LED Appendix o Hardware Requirements Use the DSW-1H together with existing HEOS devices. [Example] DHT-S716H HEOS Amp HEOS speaker NOTE 0 DSW-1H can not be used by itself.

  • Page 7: Controller Requirements

    Contents Setup Troubleshooting Status LED Appendix o Controller requirements You can control your HEOS wireless multi-room sound system using the free HEOS app on any iOS or Android mobile device that meets these minimum requirements: iOS Minimum Requirements Android Minimum Requirements iOS version 8.0 or later Android OS version 4.0 or later All resolutions...
  • Page 8 Contents Setup Troubleshooting Status LED Appendix Getting to know your DSW-1H Unpack your DSW-1H from the box and verify that the following items are included: DSW-1H Quick Start Guide Warranty (North America model only) Safety instructions Power cord 1/8 inch (3.5 mm) setup cable...

  • Page 9: Front Panel

    Contents Setup Troubleshooting Status LED Appendix o Front panel A Status LED Please refer to the “Status LED table” for LED color and state meaning. (v p. 27)
  • Page 10 Contents Setup Troubleshooting Status LED Appendix o Controls A Volume up/down buttons (+, –) Adjusts the HEOS device’s volume level up or down. B Mute button (:) Mutes or unmutes the HEOS device’s volume.

  • Page 11: Back Panel

    Contents Setup Troubleshooting Status LED Appendix o Back panel AUX IN NETWORK 5V/1A--- RESET AC IN CONNECT r t y A AUX jack (AUX IN) E AC inlet (AC IN) Used to add the HEOS device to your wireless network. Used to connect the power cord.
  • Page 12 Appendix Placing your DSW-1H The DSW-1H is designed to add HEOS multi-room audio functionality to an external device which offers audio amplification. You should place your DSW-1H in a convenient location near the speakers you are connecting it to. The DSW-1H must be within range of your wireless network.
  • Page 13 Contents Setup Troubleshooting Status LED Appendix Powering your DSW-1H Connect the power cord included in the box to the back of the DSW-1H and the plug to a wall outlet. AUX IN NETWORK 5V/1A--- RESET AC IN CONNECT for North America...

  • Page 14: Getting The Heos App

    Contents Setup Troubleshooting Status LED Appendix Getting the HEOS app The HEOS app is the heart of the HEOS experience. Using your mobile device and the HEOS app, you can setup, browse, explore, and control your HEOS system right in the palm of your hand, from anywhere in your home. Download the HEOS app for iOS or Android by searching App Store , Google Play™...
  • Page 15 Caution DO NOT connect the Ethernet cable if you are connecting your DSW-1H to a wireless network. If you are connecting the DSW-1H to a wired network, use an Ethernet cable to connect the DSW-1H to your network or router.

  • Page 16: Adding More Heos Devices

    Contents Setup Troubleshooting Status LED Appendix Adding more HEOS devices The HEOS wireless multi-room sound system is a true multiroom audio system that automatically synchronizes audio playback between multiple HEOS devices so that the audio coming from different rooms is perfectly in sync and always sounds amazing! You can easily add up to 32 devices to your HEOS system.

  • Page 17: Connecting Devices

    Follow the instructions in the menu to complete the setup. TV Input NOTE 0 A DSW-1H can not playback any audio unless it is paired with some other HEOS device. 0 A DSW-1H needs to connect your wireless network before pairing.
  • Page 18 0 HEOS Link 0 HEOS speaker NOTE Next Rooms Music Now Playing 0 A DSW-1H can not playback any audio unless it is paired with some other HEOS device. 0 A DSW-1H needs to connect your wireless network before pairing.
  • Page 19 Drag one room into another to group them Name Denon DHT-S716H "Rooms" menu. HEOS 3 Left Disconnect Wireless Surrounds Tap the HEOS device from which to unpair the DSW-1H. HEOS Link Disconnect Wireless Subwoofers Select "Disconnect Wireless Subwoofers"． Denon DHT-S716H HEOS 3 Right...

  • Page 20: Making Adjustments

    Contents Setup Troubleshooting Status LED Appendix Making adjustments You can adjust specific settings for each of your HEOS device in your Adjusting the Level system: Select the Settings a icon located in the upper left Select “Level”. corner of the main “Music” menu to display the Settings menu.

  • Page 21: Adjusting The Phase

    Contents Setup Troubleshooting Status LED Appendix Adjusting the Phase Select “Phase”. Select Normal (default) or 180°. 0 For normal configuration, use “Normal”. 0 The bass volume may increase when switched to “180°” due to the installation location of the Subwoofer. Adjusting the status light brightness Select “Status Light”.

  • Page 22: Updating Your System

    Contents Setup Troubleshooting Status LED Appendix Updating your system HEOS has the ability to add enhancements and updated functionality via your high speed Internet connection. Follow the instructions on the screen to update the HEOS device and/or your controller App. Select “Software Update”.

  • Page 23: Advanced Features

    Contents Setup Troubleshooting Status LED Appendix Advanced features There are a few advanced features of the HEOS system that you may want to explore once you become familiar with the basic operations. You can access the advanced features of the HEOS system by following these steps: Wireless performance Select the Settings a icon located in the upper left corner of the main “Music”...

  • Page 24: Power Management

    Contents Setup Troubleshooting Status LED Appendix Power management Power modes o Quick Start Mode o Deep Standby To save power, the device will automatically enter “Quick Start Mode” The device also has the ability to automatically enter “Deep Standby” whenever there is no network access or playback for 20 minutes and whenever the wired and wireless network connections are removed for will automatically resume to full power whenever the device is selected more than 60 minutes in Quick Start Mode.

  • Page 25: Basic Troubleshooting

    Contents Setup Troubleshooting Troubleshooting Status LED Appendix Basic troubleshooting My HEOS device won’t connect to my network using the audio cable Solution Refer to Page Make sure your mobile device is connected to your wireless network before setting up your device. Alternatively, you can connect your device to your network router using the included Ethernet cable.

  • Page 26: Connecting To A Wps Network

    Contents Setup Troubleshooting Status LED Appendix Connecting to a WPS network Solution Refer to Page If your wireless router support WPS (Wi-Fi Protected Setup™) your HEOS wireless device can optionally connect to your network using the “Push Button” method by following these steps: Wi-Fi Protected Setup™...

  • Page 27: Status Led Table

    Contents Setup Troubleshooting Status LED Status LED Appendix Status LED table Device Operation Description Front LED Action Rear LED Action AUX IN NETWORK 5V/1A--- RESET AC IN CONNECT No AC power or Deep Standby (off) (off) AUX IN NETWORK 5V/1A--- RESET AC IN CONNECT...
  • Page 28 Contents Setup Troubleshooting Status LED Appendix Device Operation Description Front LED Action Rear LED Action AUX IN NETWORK 5V/1A--- RESET AC IN CONNECT Not connected (solid) (solid) AUX IN NETWORK 5V/1A--- RESET AC IN CONNECT Connect button was pressed (blink) (blink) Setup AUX IN...
  • Page 29 Contents Setup Troubleshooting Status LED Appendix Device Operation Description Front LED Action Rear LED Action AUX IN NETWORK 5V/1A--- RESET AC IN CONNECT Configured and connected to your network (off) (solid) Setup AUX IN NETWORK 5V/1A--- RESET AC IN CONNECT Error (solid) (solid)
  • Page 30 Contents Setup Troubleshooting Status LED Appendix Device Operation Description Front LED Action Rear LED Action AUX IN NETWORK 5V/1A--- RESET AC IN CONNECT Soft reset - Clear user settings (solid) (fast blink) AUX IN NETWORK 5V/1A--- RESET AC IN CONNECT Hard reset - Factory restore (solid) (blink)
  • Page 31 Contents Setup Troubleshooting Status LED Appendix Device Operation Description Front LED Action Rear LED Action AUX IN NETWORK 5V/1A--- RESET AC IN CONNECT Firmware Error (off) (slow blink (NOT fade)) AUX IN NETWORK 5V/1A--- RESET AC IN CONNECT Hardware Error Errors (off) (fast blink)
  • Page 32 Contents Setup Troubleshooting Status LED Appendix Device Operation Description Front LED Action Rear LED Action AUX IN NETWORK 5V/1A--- RESET AC IN CONNECT a WPS session is active (fast blink) (fast blink) AUX IN NETWORK 5V/1A--- RESET AC IN CONNECT WPS connected (solid) (for 3 sec.

  • Page 33: Supported File Types And Codecs

    Contents Setup Troubleshooting Status LED Appendix Appendix Supported file types and codecs Frequency Sample Rate File Extension Codec Bit Rates 32/44.1/48 88.2/96/176.4 16/24 bit 192 kHz 32 kHz MPEG-1 Audio Layer 3 44.1 kHz 16 bit 32 - 320 kbps CBR/VBR 48 kHz 32 kHz...

  • Page 34: Specifications

    Contents Setup Troubleshooting Status LED Appendix Specifications o Wireless LAN section Network type: Conforming to IEEE 802.11a/b/g/n/ac Used frequency range: 2.4 GHz, 5 GHz o General Operating temperature: 41 °F - 95 °F (5 °C - 35 °C) Power supply: AC 120 V, 60 Hz (for North America) AC 220 - 240 V, 50/60 Hz (for Europe) Power consumption:...
  • Page 35 Contents Setup Troubleshooting Status LED Appendix o Dimensions (Unit : in. (mm)) 6 7/8 (172) 17 3/8 (439) o Weight : 22 lbs 4 oz (10.1 kg) For the purpose of improvement, the specifications and design are subject to change without notice.
  • Page 36 Contents Setup Troubleshooting Status LED Appendix Information Trademarks Amazon, Kindle, Echo, Alexa, Dash, Fire and all related logos are trademarks of Amazon.com, Inc. or its affiliates. Google Play and the Google Play logo are trademarks of Google LLC. Apple, the Apple logo, iPad, iPhone, and iPod touch are trademarks of Apple Inc., registered in the U.S.
