VCR/Source Selector Keys

1. [A, B, C, D] selects a current source. Also selects the output for the MX-1.
The current source is controlled with the transport keys and the jog/shuttle.
2. [SHIFT-A, B, C, D] creates a new scene or source event after the currently
displayed event. (Scene if PROTO≠NONE; Source if PROTO=NONE.)
3. [GO TO-A, B, C, D] when connected to an MX-1, sets the "Next" video
source on the MX-1 and transfers VCR control to the selected Edit Suite
port.
1. [R] allows the Record VCR to be controlled.
1. [COLOR] selects background color as the output for the MX-1.
2. [SHIFT]+[COLOR] selects background color as the output for the MX-1 and
creates a source event with the COL=0.

Production Keys

1. [REC] starts an assemble edit, starts the recorder, and creates a scene event.
2. [SHIFT]+[AUTO REC] starts an auto-assembly, commencing from the
currently displayed EDL event.
1. [PREVIEW] starts a preview of the EDL, commencing from the currently
displayed EDL event.
2. [SHIFT]+[REVIEW/PREVIEW] displays the last edit recorded on your
Record VCR. (Cannot be used if the record VCR is controlled with IR.)
1. [INSERT] creates an Insert edit.
2. [SHIFT]+[SPLIT/INSERT] creates a Split Insert event. Must follow an
Insert or nothing is created.
1. [GPI-M] creates either an MX1, MIXER or GPI event depending on the GPI-
M Configuration parameter.
2. [DELETE]+[GPI-M] deletes all GPI-M events from the current group.
3. [SHIFT]+[DELETE]+[GPI-M] deletes all GPI-M events from the EDL.
1. [GPI-T] creates a GPI-T event.
2. [DELETE]+[GPI-T] deletes all GPI-T events from the current group.
3. [SHIFT]+[DELETE]+[GPI-T] deletes all GPI-T events from the EDL.
1. [IN] updates the IN time code in the current event or creates a new event if
the active source is different from the source in the current event.
2. [SHIFT]+[IN] creates a new event for the current source and enters the IN
time.
3. [GO TO]+[IN] repositions the source VCR to the IN time for the current
event.
