Sealey SA348 Instructions

thank you for purchasing a sealey product. manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to Wear protective
instruction gloves
manual
1. safety
warning! ensure Health & Safety, local authority and general workshop practice regulations are adhered to when using this equipment.
‰
warning! disconnect from air supply before changing the blade or file, servicing or performing maintenance.
‰
maintain the tool in good condition.
9
Replace or repair damaged parts. Use genuine parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
9
Use in suitable, clean and tidy work area, free from unrelated materials. ensure that there is adequate lighting.
9
warning! Always wear approved eye or face and hand protection when operating the saw.
‰
Remove ill fitting clothing. Remove ties, loose jewellery and contain and/or tie back long hair.
9
Wear appropriate protective clothing and keep hands and body clear of working parts.
9
maintain correct balance and footing. ensure the floor is not slippery and wear non-slip shoes.
9
Keep children and unauthorised persons away from work area.
9
do not use blades that are cracked or deformed.
8
do not use hacksaw blade segments.
8
ensure that blades and files are clamped tightly to the airtool.
9
Check moving parts alignment on a regular basis.
9
ensure workpiece is secure before operating the saw. never hold a workpiece by hand. Use a vice or clamps.
9
warning! ensure correct air pressure is maintained and not exceeded. Recommended pressure is 90psi.
‰
Keep air hose away from heat, oil and sharp edges. Check air hose for wear before each use and ensure that all connections are secure.
9
Prolonged exposure to vibration from this tool poses a health risk. It is the employer's/owner's responsibility to correctly assess the
9
hazard and issue guidelines for safe periods of use and offer suitable protective equipment.
do not use any power source except an air compressor.
8
do not operate the tool near any inflammable substance or on any container that has held an inflammable substance.
8
do not use tool for a task it is not designed to perform.
8
do not operate tool if any parts are damaged or missing as this may cause failure and/or personal injury.
8
do not carry the tool by the hose, or yank the hose from the air supply.
8
do not operate tool when you are tired or under the influence of alcohol, drugs or intoxicating medication.
8
do not carry the tool with your finger on the trigger.
8
do not direct air from the air hose at yourself or others.
8
When not in use disconnect from air supply and store in a safe, dry, childproof location.
9
2. introduction
Suitable for a variety of bodyshop applications such as cutting through panels, sills and chassis members. excellent for initial crash-
repair preparation when quick removal of damaged panels is required. Fitted with safety trigger device. Supplied with a starter pack of
blades.
3. specification
model no.:.................................................................. sa348
Free Speed: ............................................................ 9000bpm
Stroke: ......................................................................... 10mm
maximum Cutting Capacity: ............. 2mm Steel, 3mm Aluminium
Air Consumption: ........................................................... 3cfm
operating Pressure: ...................................................... 90psi
Air Inlet Size: .............................................................1/4"BSP
Weight: ...................................................................... 0.425kg
noise Power:............................................................. 99dB(A)
noise Pressure: ........................................................ 88dB(A)
Vibration/Uncertainty .......................................11.985/1.5m/s
consumables:
14 TPI Air Saw Blade ............................................. SA34/B14
24 TPI Air Saw Blade ............................................. SA34/B24
32 TPI Air Saw Blade ............................................. SA34/B32
© Jack Sealey limited
reciprocating air saw slim body
model no:
Wear eye Wear ear
protection protection
Original Language Version
sa348
2
SA348 Issue 1 12/02/19
