Sealey sm1302.v2 Instructions Manual

thank you for purchasing a sealey product. manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
refer to Wear eye
instructions protection
1. saFetY
1.1. electrical safety
warNiNG! it is the user's responsibility to check the following:
‰
check all electrical equipment and appliances to ensure that they are safe before using. inspect power supply leads, plugs and
all electrical connections for wear and damage. sealey recommend that an rcd (residual current device) is used with all
electrical products. You may obtain an rcd by contacting your local sealey stockist.
if used in the course of business duties, it must be maintained in a safe condition and routinely PAt (Portable Appliance test)
tested.
electrical safety information, it is important that the following information is read and understood.
ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply.
9
regularly inspect power supply cables and plugs for wear or damage and check all connections to ensure that they are secure.
9
Ensure that the voltage rating on the appliance suits the power supply to be used and that the plug is fitted with the correct fuse
9
- see fuse rating in these instructions.
do Not pull or carry the appliance by the power cable.
8
do Not pull the plug from the socket by the cable.
8
do Not use worn or damaged cables, plugs or connectors. ensure that any faulty item is repaired or replaced immediately by a
8
qualified electrician.
This product is fitted with a BS1363/A 13 Amp 3 pin plug.
9
if the cable or plug is damaged during use, switch the electricity supply off and remove from use.
Ensure that repairs are carried out by a qualified electrician.
Replace a damaged plug with a BS1363/A 13 Amp 3 pin plug. If in doubt contact a qualified electrician.
a) connect the Green/YelloW earth wire to the earth terminal 'e'.
b) Connect the BROWN live wire to the live terminal 'L'.
c) Connect the BLUE neutral wire to the neutral terminal 'N'.
ensure that the cable outer sheath extends inside the cable restraint and that the restraint is tight.
Sealey recommend that repairs are carried out by a qualified electrician.
1.2. General safety
warNiNG! ensure that Health & safety, local authority and general workshop practice regulations
‰
are adhered to when using this equipment.
familiarise yourself with the application, limitations and hazards of the saw.
9
warNiNG! disconnect the saw from the mains power and ensure that the cutting blade is at
‰
a complete standstill before attempting to change blades or perform any maintenance.
maintain the saw in good condition (use an authorised service agent).
9
replace or repair damaged parts. use genuine parts only. unauthorised parts may be dangerous and will invalidate the warranty.
9
warNiNG! Keep all guards and holding screws in place, tight and in good working order. check regularly for damaged parts. A guard
‰
or any other part that is damaged should be repaired or replaced before the machine is used. the safety guard is a mandatory fitting
where the saw is used on premises covered by the Health & safety at Work Act.
locate saw in a suitable work area and keep area clean and tidy and free from unrelated materials. ensure that there is adequate
9
lighting.
Keep the saw clean and blades sharp for best and safest performance.
9
ensure that there are no flammable or combustible materials in or near the work area.
9
warNiNG! Always wear approved eye or face protection when operating the saw. use a face or dust mask if dust is generated.
‰
maintain correct balance and footing. ensure the floor is not slippery and wear non-slip shoes.
9
remove ill fitting clothing. remove ties, watches, rings and other loose jewellery and contain and/or tie back long hair.
9
Keep children and unauthorised persons away from the work area.
9
check moving parts alignment on a regular basis.
9
remove adjusting keys and wrenches from the machine and its vicinity before turning it on.
9
Avoid unintentional starting.
9
do Not use the saw for any purpose other than that for which it is designed.
8
do Not operate the saw if any parts are damaged or missing as this may cause failure and/or personal injury.
8
© Jack sealey limited
instructions for
variable speed scroll saw
406mm throat 230v
sm1302.v2
model no:
Wear ear Wear face
protection mask
Original Language Version
Wear protective
gloves
recommended fuse rating
3 Amp
sm1302.V2 | issue 3(i) 14/06/17
