- Page 1 IM3048 08/2020 REV09 SPEEDTEC 405S, 405SP, 505S & 505SP OPERATOR’S MANUAL ENGLISH Lincoln Electric Bester Sp. z o.o. ul. Jana III Sobieskiego 19A, 58-263 Bielawa, Poland www.lincolnelectric.eu...
-
Page 2: Table Of Contents
12/05 DZIĘKUJEMY! Za docenienie JAKOŚCI produktów Lincoln Electric. Proszę sprawdzić czy opakowanie i sprzęt nie są uszkodzone. Reklamacje uszkodzeń powstałych podczas transportu muszą być natychmiast zgłoszone do dostawcy (dystrybutora). Dla ułatwienia prosimy o zapisanie na tej stronie danych identyfikacyjnych wyrobów. Nazwa modelu, Kod i Numer Seryjny, które możecie Państwo znaleźć... -
Page 3: Technical Specifications
Technical Specifications NAME INDEX SPEEDTEC 405S K14117-1 SPEEDTEC 405SP K14117-2 SPEEDTEC 505S K14116-1 SPEEDTEC 505SP K14116-2 SPEEDTEC 405SP K14117-6 SPEEDTEC 505SP K14116-6 INPUT Input Voltage U EMC Class Frequency 405S, 405SP 400V ± 10% 50/60Hz 3-phase 505S, 505SP Input Power at Rated Cycle... - Page 4 DIMENSION Weight Height Width Length 405S, 405SP 50 kg 535 mm 300 mm 635 mm 505S, 505SP 50 kg 535 mm 300 mm 635 mm Protection Rating Operating Humidity (t=20°C) 405S, 405SP IP23 ≤ 90 % 505S, 505SP Operating Temperature Storage Temperature 405S, 405SP from -10 ºC to +40 ºC...
-
Page 5: Eco Design Information
2019/1784/EU. Efficiency and idle power consumption: Efficiency when max power consumption Index Name Equivalent model / Idle power consumption K14117-1 SPEEDTEC 405S 86,1 % / 47W No equivalent model K14117-2 SPEEDTEC 405SP 86,1 % / 47W No equivalent model K14116-1... - Page 6 Typical gas usage for MIG/MAG equipment: DC electrode positive Wire Wire Feeding Gas flow Material type diameter Shielding Gas Current Voltage [m/min] [l/min] [mm] Carbon, low 0,9 ÷ 1,1 95 ÷ 200 18 ÷ 22 3,5 – 6,5 Ar 75%, CO alloy steel Aluminium 0,8 ÷...
-
Page 7: Electromagnetic Compatibility (Emc)
If any electromagnetic disturbances are detected the operator must put in place corrective actions to eliminate these disturbances with, if necessary, assistance from Lincoln Electric. Before installing the machine, the operator must check the work area for any devices that may malfunction because of electromagnetic disturbances. -
Page 8: Safety
Failure to follow the instructions in this manual could cause serious personal injury, loss of life, or damage to this equipment. Read and understand the following explanations of the warning symbols. Lincoln Electric is not responsible for damages caused by improper installation, improper care or abnormal operation. - Page 9 WELDING SPARKS CAN CAUSE FIRE OR EXPLOSION: Remove fire hazards from the welding area and have a fire extinguisher readily available. Welding sparks and hot materials from the welding process can easily go through small cracks and openings to adjacent areas. Do not weld on any tanks, drums, containers, or material until the proper steps have been taken to insure that no flammable or toxic vapors will be present.
-
Page 10: Intoduction
SPEEDTEC 405S, 405SP, 505S and 505SP can only be Locate the machine away from radio controlled connected to a mating grounded receptacle. - Page 11 ON again. If the error remains, a maintenance is required. Please contact the nearest authorized technical service center or Lincoln Electric and report the error code read. Indicate no communication between the power source and device which Steady Red Figure 2.
- Page 12 "Accessories" chapter, Source/wire feeder cable K10349- PG-xM or K10349-PGW-xM). Use the shortest possible cable lengths. Water Cooler Connection SPEEDTEC 405S, 405SP, 505S and 505SP work with the water cooler COOLARC 46 (see "Accessories" chapter). WARNING Read and understand the cooler manual before connecting it to the power source.
- Page 13 User Interface Connection Transport & Lifting To connect the User Interface to the power source: Unscrew the Replaceable Panel [4]. WARNING Falling equipment can cause injury and damage to unit. Figure 4. Connect the plug X8 of the power source with the socket X100 of the User Interface.
- Page 14 We respond to our customers based on the best become null and void. information in our possession at that time. Lincoln Electric is not in a position to warrant or guarantee such advice, Any noticeable damage should be reported immediately and assumes no liability, with respect to such information and repaired.
-
Page 15: Weee
12/05 Part List reading instructions Do not use this part list for a machine if its code number is not listed. Contact the Lincoln Electric Service Department for any code number not listed. Use the illustration of assembly page and the table below to determine where the part is located for your particular code machine. -
Page 16: Accessories Suggested
Accessories Suggested K10349-PG-xxM Source/wire feeder cable (gas). Available in 5, 10, 15m. K10349-PGW-xxM Source/wire feeder cable (gas and water). Available in 5, 10 or 15m. K14033-1 Work Lead, 3m - GRD-600A-70-3M. K14105-1 Cooler COOLARC 46. K14096-1 SPEEDTEC CART. K14072-1 LF45 – Digital Wire Feeder. K14083-1 LF45S –...
