USERʼS MANUAL
Model No. PFTL06711.0
Serial No.
Write the serial number in the space
above for reference.
Serial
Number
Decal
QUESTIONS?
If you have questions, or if parts are
damaged or missing, DO NOT CON-
TACT THE STORE; please contact
Customer Care.
IMPORTANT: Please register this
product (see the limited warranty
on the back cover of this manual)
before contacting Customer Care.
1-888-533-1333
CALL TOLL-FREE:
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–4 p.m. MT
ON THE WEB:
www.proformservice.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.

Advertisement

Table of Contents
loading

Related Manuals for ProForm ProForm 610RT PFTL06711.0

Summary of Contents for ProForm ProForm 610RT PFTL06711.0

  • Page 1 USERʼS MANUAL Model No. PFTL06711.0 Serial No. Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? If you have questions, or if parts are damaged or missing, DO NOT CON- TACT THE STORE; please contact Customer Care.

  • Page 2: Table Of Contents

    Apply the decal in the location shown. Note: The decals may not be shown at actual size. PROFORM is a registered trademark of ICON IP, Inc.

  • Page 3: Important Precautions

    14. To purchase a surge suppressor, see informed of all warnings and precautions. your local PROFORM dealer or call the tele- phone number on the front cover of this man- 3. Use the treadmill only as described.
  • Page 4 20. Never leave the treadmill unattended while it 24. Inspect and properly tighten all parts of the is running. Always remove the key, unplug treadmill regularly. DANGER: the power cord, and press the power switch into the off position when the treadmill is not Always unplug the power in use.

  • Page 5: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the revolutionary PROFORM ing this manual, please see the front cover of this man- ® 610 RT treadmill. The 610 RT treadmill offers an im- ual. To help us assist you, please note the product pressive selection of features designed to make your model number and serial number before contacting us.

  • Page 6: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.

  • Page 7: Assembly

    ASSEMBLY • To hire a service technician to assemble this • To identify small parts, see page 6. product in your home, call 1-800-445-2480. • Assembly requires the following tools: • Assembly requires two persons. the included hex keys • Place all parts in a cleared area and remove the packing materials.
  • Page 8 2. Attach a Wheel (95) to the Base (94) with a 3/8" x 3" Bolt (67), two Wheel Spacers (96), and a 3/8" Nut (10). Do not overtighten the Nut; the Wheel must turn freely. 3. Identify the Right Upright (83), which is marked with a “Right”...
  • Page 9 4. Insert a 3/8" x 5 1/2" Screw (7), a 3/8" x 3 3/4" Screw (97), and a 3/8" x 2 1/4" Screw (31) with three 3/8" Star Washers (11) into the Right Upright (83) in the locations shown. Hold the Right Upright (83) against the Base (94).
  • Page 10 6. Attach a Wheel (95) to the Base (94) with a 3/8" x 3" Bolt (67), two Wheel Spacers (96), and a 3/8" Nut (10). Do not overtighten the Nut; the Wheel must turn freely. Attach the Base Cover (84) to the Base (94) with four #8 x 1/2"...
  • Page 11 8. Set the console assembly face down on a soft surface to avoid scratching the console. Console Wire Identify the Right Handrail (79). Hold the Right Handrail near the console assembly. Route the console wire through the large holes in the top and bottom of the Right Handrail.
  • Page 12 10. Set the console assembly on the Left and Right Console Uprights (82, 83). Be careful not to pinch any Assembly wires. Insert the excess wire into the Right Upright. Start two 5/16" x 3/4" Screws (5) with two 5/16" Star Washers (9) into the Right Upright (83).
  • Page 13 12. Press the Left Outside Upright Cover (87) and the Left Inside Upright Cover (90) around the Left Upright (82). Attach the Upright Covers with a #8 x 1/2" Screw (1). Attach the Right Outside Upright Cover (86) and the Right Inside Upright Cover (88) in the same way.

  • Page 14: Operation And Adjustment

    OPERATION AND ADJUSTMENT HOW TO PLUG IN THE POWER CORD This product is for use on a nominal 120-volt circuit (see drawing 1). A temporary adapter may be used to DANGER: connect the surge suppressor to a 2-pole receptacle if a properly-grounded outlet is not available (see Improper connection drawing 2).
  • Page 15 CONSOLE DIAGRAM Audio Jack FEATURES OF THE CONSOLE You can even listen to your favorite workout music or audio books with the consoleʼs stereo sound system. The treadmill console offers an impressive array of To turn on the power, see page 16. To use the man- features designed to make your workouts more effec- ual mode, see page 16.
  • Page 16 HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room tem- perature before turning on the power. If you do not See HOW TO TURN ON THE POWER at the left.
  • Page 17 4. Change the incline of the treadmill as desired. 6. Measure your heart rate if desired. To change the incline of the treadmill, press the Before using Incline increase or decrease button, or one of the 1 the handgrip Step Incline buttons numbered 0 to 10. Each time heart rate you press one of the buttons, the incline will gradu- monitor, re-...
  • Page 18 HOW TO USE A PRESET WORKOUT is programmed for Current Segment the next segment, 1. Insert the key into the console. the speed and/or incline setting will See HOW TO TURN ON THE POWER on page 16. flash in the dis- plays for a few 2.
  • Page 19 HOW TO USE THE IFIT TRAINING MODE HOW TO USE THE STEREO SOUND SYSTEM The optional iFit Live module allows your treadmill to To play music or audio books through the consoleʼs communicate with your wireless network and unlocks stereo speakers, you must connect your MP3 player, exciting new features.
  • Page 20 THE INFORMATION MODE The console features a display demo mode, designed to be used if the treadmill is displayed in a store. While The console features an information mode that keeps the demo mode is turned on, the console will function track of the total distance that the walking belt has normally when you plug in the power cord, press the moved and the total number of hours that the treadmill...

  • Page 21: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to the lowest position before you fold the treadmill. left.

  • Page 22: Troubleshooting

    TROUBLESHOOTING Most treadmill problems can be solved by following SYMPTOM: The console displays remain lit when the simple steps below. Find the symptom that you remove the key from the console applies, and follow the steps listed. If further assis- tance is needed, see the front cover of this manual.
  • Page 23 SYMPTOM: The walking belt slows when walked on Remove the four #8 x 1" Screws (49) and carefully remove the Motor Hood (61). a. Use only a single-outlet surge suppressor that meets all of the specifications described on page b. If the walking belt is overtightened, treadmill perfor- mance may decrease and the walking belt may be- come damaged.
  • Page 24 SYMPTOM: The walking belt is off-center or slips b. If the walking belt slips when walked on, first re- when walked on move the key and UNPLUG THE POWER CORD. Using the hex key, turn both idler roller screws a. If the walking belt is off-center, first remove the clockwise, 1/4 of a turn.

  • Page 25: Exercise Guidelines

    EXERCISE GUIDELINES WARNING: Burning Fat—To burn fat effectively, you must exer- cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.

  • Page 26: Part List

    PART LIST Model No. PFTL06711.0 R0911A Key No. Qty. Description Key No. Qty. Description #8 x 1/2" Screw Storage Latch #8 x 1" Tek Screw #8 x 1 1/2" Screw 3/8" x 2" Bolt Electronics Bracket 5/16" x 1 1/2" Bolt Controller 5/16"...
  • Page 27 Key No. Qty. Description Key No. Qty. Description Left Accessory Tray Hood Clip Console Base Latch Warning Decal Module Housing Site Warning Decal Right Accessory Tray Wire Tie Clamp Access Door #8 x 3/4" Tek Screw Pulse Bar Small Platform Cushion Frame Crossbar –...

  • Page 28: Exploded Drawing

    EXPLODED DRAWING A Model No. PFTL06711.0 R0911A...
  • Page 29 EXPLODED DRAWING B Model No. PFTL06711.0 R0911A...
  • Page 30 EXPLODED DRAWING C Model No. PFTL06711.0 R0911A...
  • Page 31 EXPLODED DRAWING D Model No. PFTL06711.0 R0911A...

  • Page 32: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to pro- vide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
