Model No. PETL61010
Serial No.
Find the serial number in the location
shown below. Write the serial number
in the space above for reference.
Serial
Number
Decal
QUESTIONS?
As a manufacturer, we are
committed to providing
complete customer satisfaction.
If you have questions, or if
there are missing parts, pease
call:
08457-089009
Or write:
ICON Health & Fitness, Ltd.
Unit 4
Revie Road Industrial Estate
Revie Road
Beeston
Leeds, LS11 8JG
UK
email: csuk@iconeurope.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
®
USER'S MANUAL
Visit our website at
www.proform.com
Advertisement
Table of Contents
Related Manuals for ProForm 610
Summary of Contents for ProForm 610
- Page 1 ICON Health & Fitness, Ltd. Unit 4 Revie Road Industrial Estate Revie Road Beeston Leeds, LS11 8JG email: csuk@iconeurope.com CAUTION Read all precautions and instruc- tions in this manual before using Visit our website at this equipment. Save this manual for future reference. www.proform.com...
-
Page 2: Table Of Contents
® TABLE OF CONTENTS IMPORTANT PRECAUTIONS ..............3 BEFORE YOU BEGIN . -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read the following important precautions and information before operating the treadmill. 1. It is the responsibility of the owner to ensure 12. If an extension cord is needed, use only a 3- that all users of this treadmill are adequately conductor, 1mm (14-gauge) cord that is no... - Page 4 22. When using iFIT.com CD’s and videos, an 25. Inspect and tighten all parts of the treadmill electronic “chirping” sound will alert you regularly. when the speed and/or incline of the treadmill is about to change. Always listen for the 26.
-
Page 5: Before You Begin
BEFORE YOU BEGIN Thank you for selecting the revolutionary PROFORM please call our our Customer Service Department at ® 610 treadmill. The PROFORM 610 combines ad- 08457-089009. To help us assist you, please note the ® vanced technology with innovative design to help you... -
Page 6: Assembly
ASSEMBLY Assembly requires two people. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Assembly requires your own Phillips screw- driver and rubber mallet Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to the top of the walking belt or the shipping carton. - Page 7 4. Insert a Handrail Extension (85) into the post on the left Upright (82). If necessary, tap the Handrail Extension with Post a rubber mallet to fully insert it. Align the holes in the Handrail Extension with the holes in the post. Next, attach the Handrail Extension by tightening three Handrail Screws (54) into the indicated holes.
-
Page 8: Operation And Adjustment
OPERATION AND ADJUSTMENT THE PERFORMANT LUBE WALKING BELT Your treadmill features a walking belt coated with PERFORMANT LUBE , a high-performance lubricant. IMPOR- TANT: Never apply silicone spray or other substances to the walking belt or the walking platform. Such substances will deteriorate the walking belt and cause excessive wear. -
Page 9: Console Diagram
DIAGRAM OF THE CONSOLE Manual Indicator iFIT.com Indicator Displays LED Track Displays Incline Mode Speed Start Stop Buttons Button Buttons Button Button Clip automatically control the speed and incline of the CAUTION: treadmill as a personal trainer guides you through Before operating the every step of your workout. - Page 10 Change the incline of the treadmill as desired. HOW TO USE THE MANUAL MODE To change the incline of Before operating the con- the treadmill, press the in- sole, make sure that the cline buttons. Each time on/off switch near the one of the buttons is Position power cord is in the on...
- Page 11 Calories/watts/pulse Measure your pulse, if desired. display—This display shows the approximate Note: When using the pulse sensor, make sure number of calories you that your hands are clean. The pulse sensor have burned and your should also be kept clean with a damp cloth and current power output in mild detergent.
- Page 12 HOW TO CONNECT YOUR PORTABLE STEREO HOW TO CONNECT THE TREADMILL TO YOUR CD PLAYER, VCR, OR COMPUTER Note: If your stereo has an RCA-type AUDIO OUT jack, see instruction A below. If your stereo has a 3.5mm LINE OUT jack, see instruction B. If your To use iFIT.com CD’s, the treadmill must be con- stereo has only a PHONES jack, see instruction C.
- Page 13 HOW TO CONNECT YOUR HOME STEREO HOW TO CONNECT YOUR COMPUTER Note: If your stereo has an unused LINE OUT jack, Note: If your computer has a 3.5mm LINE OUT jack, see instruction A below. If the LINE OUT jack is see instruction A.
- Page 14 CD case describe how to B. Plug one end of the audio cable into the jack on the use the CD with a variety of PROFORM treadmills. front of the treadmill near the power cord. Plug the Some instructions may not apply to this treadmill.
- Page 15 Note: If the speed or incline of the treadmill Press the PLAY button on your CD player or does not change when a “chirp” is heard: VCR. A moment after the button is pressed, your per- • Make sure that the iFIT.com indicator is lit and sonal trainer will begin guiding you through your that the time/incline display is not flashing.
-
Page 16: To Use Programs Directly From Site
Follow the desired links on our internet site to HOW TO USE PROGRAMS DIRECTLY FROM select a program. OUR INTERNET SITE Read and follow the on-line instructions for using a program. Our new internet site at www.iFIT.com allows you to access a large selection of programs that interactively Follow the on-line instructions to start the control your treadmill to help you achieve your specific... - Page 17 IMPORTANT: The calo- Follow your progress with the LED track and ries/watts/pulse display the four displays. should be blank. If a “d” ap- pears in the display, the con- See step 5 on page 10. sole is in the “demo” mode. This mode is intended to be Measure your pulse, if desired.
-
Page 18: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, adjust the incline to the lowest position. If this is not done, the treadmill may be permanently damaged. Next, unplug the power cord. CAUTION: You must be able to safely lift 20 kg (45 lbs.) in order to raise, lower, or move the treadmill. -
Page 19: Trouble-Shooting
TROUBLE-SHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If assistance is needed, call our Customer Service Department at 08457-089009. PROBLEM: The power does not turn on SOLUTION: a. - Page 20 PROBLEM: The walking belt slows when walked on SOLUTION: a. If an extension cord is needed, use only a 3-conductor, 1mm (14-gauge) cord that is no longer than 1.5 m (5 ft.). b. If the walking belt is overtightened, treadmill perfor- 7–10 cm mance may decrease and the walking belt may be- come damaged.
-
Page 21: Conditioning Guidelines
CONDITIONING GUIDELINES is to burn fat, adjust the speed and incline of the tread- WARNING: mill until your heart rate is near the lowest number in Before beginning this your training zone. or any exercise program, consult your physi- cian. This is especially important for individu- For maximum fat burning, adjust the speed and incline als over the age of 35 or individuals with pre- of the treadmill until your heart rate is near the middle... -
Page 22: Part List
PART LIST—Model No. PETL61010 R0601A To locate the parts listed below, refer to the EXPLODED DRAWING attached in the centre of this manual. No. Qty. Description No. Qty. Description Motor Belt Front Belly Pan Pulley/Flywheel/Fan Euro Power Cord 3/8” Motor Flange Nut Cable Tie Clamp Motor/Pulley/Flywheel/Fan Belly Pan/Handrail Screws... - Page 23 Screw Hand Pulse Wire Interface Bracket 126* Extension Leg Assembly Extension Leg Belly Pan Foot Extension Leg Cap Foam Tape Shock 8” White Wire, 2F Choke 10” White Wire, 2F Pulse Bar Bolt 14” White Wire, 2F Pulse Bar Washer 4”...
-
Page 24: How To Order Replacement Parts
• The KEY NUMBER AND DESCRIPTION OF THE PART(S) (see the PART LIST on pages 22 and 23 and the EXPLODED DRAWING attached in the centre of this manual) PROFORM is a registered trademark of ICON Health & Fitness, Inc. Part No. 173611 R0601A... - Page 26 EXPLODED DRAWING—Model No. PETL61010 R0601A...
