Warning/Caution Symbols Used in This Manual Though Nikon products are designed to provide you with the utmost safety during use, incorrect usage or disregard of the instructions may cause personal injury or property damage. For your own safety, read the instruction manual carefully and thoroughly before using the product.
3. Do not disassemble Disassembly may cause damage to the instrument. Never disassemble any part except as described in this manual. If you notice any malfunction in this instrument, notify your nearest Nikon representative. 4. Lens cleaning Do not get dust, fingerprints, etc., on the lenses. Dirt on the lenses will adversely affect the view of the image.
Page 13
Put a vinyl cover over the equipment to protect it from dust. 7. Regular inspections Regular inspections of the microscope are recommended in order to maintain peak performance. Contact your nearest Nikon representative for details about regular inspections.
Nomenclature and Using The illustration shows SMZ460 zooming body. Eyepiece Zooming knob 10X, 15X and 20X Rotation of the zooming eyepieces are available. knob changes the magnifying power of the objective continuously from the lowest to the highest. The powers are indicated on the knob.
Page 15
Eyepiece inclination Hexagonal wrench SMZ445: 45° from the hanger horizontal SMZ460: 60° from the Holds the supplied horizontal hexagonal wrenches. Hexagonal wrench Screw hole for mounting an (Large) arm for halogen illuminator Supplied with the Screw holes are located on focusing stand for both sides of the arm.
8. Repeat the above processes from 4. to 7. to make sure of exact focusing, and, then the image will keep its sharpness all the time of continuous magnification change by zooming. Antistatic Feature Models SMZ460, SMZ445 and C-PSC Focusing stand are made antistatic. They are very useful in observing specimens weak against static.
Page 17
Symbol for separate collection applicable in European countries Symbol for kildesortering i europeiske land This symbol indicates that this product is to be collected separately. Dette symbolet indikerer at produktet skal kildesorteres. The following apply only to users in European countries. De nedenstående punktene gjelder for alle europeiske brukere.
Page 18
Tel: +1-631-547-8500 Fax: +1-631-547-0306 Semiconductor Inspection Technologies Division 1430 W. Auto Drive, Suite 101, Tempe, AZ 85284, U.S.A. Tel: +1-480-403-4100 Fax: +1-480-403-4199 NIKON INSTRUMENTS EUROPE B.V. Schipholweg 321, P.O. Box 222, 1170 AE Badhoevedorp, The Netherlands Tel: +31-20-44-96-222 Fax: +31-20-44-96-298...
