Kit Instructions
Second Gun and Hose Kit
For use with the LineLazer™ Gasoline Powered Airless LineStripers
Important Safety Instructions
Read all warnings and instructions in this manual. Be familiar with the controls and the
proper usage of the equipment. Save these instructions.
3300 psi (227bar, 22.7MPa) Maximum Working Pressure
Model 241284
Includes Size 319 LineLazer Tip
and Size 517 SwitchTip™
ti25652a
308939D
EN

Advertisement

Table of Contents
loading

Related Manuals for Graco 241284

Summary of Contents for Graco 241284

  • Page 1 Read all warnings and instructions in this manual. Be familiar with the controls and the proper usage of the equipment. Save these instructions. 3300 psi (227bar, 22.7MPa) Maximum Working Pressure Model 241284 Includes Size 319 LineLazer Tip and Size 517 SwitchTip™...

  • Page 2: Pressure Relief Procedure

    Instructions Pressure Relief Procedure Follow the Pressure Relief Procedure whenever you see this symbol This equipment stays pressurized until pressure is manually relieved. To help prevent serious injury from pressurized fluid, such as skin injection, splashing fluid and moving parts, follow the Pressure Relief Procedure when you stop spraying and before cleaning, checking, or servicing the equipment.

  • Page 3: Trigger Cable

    Instructions Trigger Cable The gun is remotely triggered with the dual gun selector on the handle bar. To reduce the risk of injection due to remotely triggering the gun by Be sure end jacket of accident, always disengage the trigger cable from cable seats here.
  • Page 4 Instructions Second Gun Kit Installation NOTE: Fig. 2, which shows the second gun (outside gun) being mounted on the pump Unscrew the filter’s second outlet cap side of the cart, represents the installation at (J). Screw hose (403) onto filter nipple. step 3.
  • Page 5 Instructions DETAIL A CORRECTLY INSTALLED CABLE Torque to 15 in-lb (1.7 N m) and then back up 1/16 to 1/8 turn DETAIL B Fig. 2 ti25654a 308939D...
  • Page 6 Instructions Adjust Simultaneous Gun Triggering To reduce the risk of fluid injection injury, always disengage the trigger cable to the gun(s) before moving or adjusting the guns or gun arms. See page 3. Align the front of guns by adjusting the If one gun triggers before the other, reduce gun arms.
  • Page 7 Instructions Disengage the gun trigger safety latch To mount guns on engine-side of the cart: and engage the cable (402, H). For both guns, disengage the cables Vertical position of first or second gun: (402, H) and engage the trigger safety lever.
  • Page 8 Instructions Mount Gun in the Gun Holder Relieve pressure, page 2. Disengage the trigger cable. See page 3. Disengage the gun’s trigger safety lever (J). Loosen the gun holder knob (93). Position the gun so the gun trigger is resting on the remote trigger lever (H). Be sure the gun is mounted straight and then tighten the knob (93) firmly.
  • Page 9 Instructions Trigger Cable and Dual Gun Selector Operation Trigger cable tension adjustment (Fig. 6) Shown in three positions Relieve pressure, page 2. Be sure the gun is properly mounted in holder as instructed in Step 4 under ti25657a Fig. 5 Mount Gun in the Gun Holder, page Pull the actuator level (94) forward and hold it.

  • Page 10: Parts Drawing

    Instructions Parts Drawing Second Gun and Hose Kit Model 241284 REF 402 132 47 113, 158 ti25659a 308939D...

  • Page 11: Parts List

    Instructions Parts List Second Gun and Hose Kit Model 241284 Ref. Part Description Qty. 287566 CLAMP, arm suppprt 188135 GUIDE, cable 100846 FITTING, lubrication 111016 BEARING, flanged 111230 SCREW, mach, flhd, 1/4-20 x 1’ 100015 NUT, hex, 1/4-20 100016 LOCKWASHER, 1/4”...

  • Page 12: Graco Standard Warranty

    Graco’s written recommendations. This warranty does not cover, and Graco shall not be liable for general wear and tear, or any malfunction, damage or wear caused by faulty installation, misapplication, abrasion, corrosion, inadequate or improper maintenance, negligence, accident, tampering, or substitution of non-Graco component parts.

  • Page 13: Graco Information

    For the latest information about Graco products, visit www.graco.com. For patent information, see www.graco.com/patents. TO PLACE AN ORDER, contact your Graco distributor or call 1-800-690-2894 to identify the nearest distributor. All written and visual data contained in this document reflects the latest product information available at the time of publication.
