Sprayer Power Cord Installation
For Sprayer Cords:
240539 through 240543, 241852, 241879
WARNING
FIRE AND EXPLOSION HAZARD
Use of the plug retainer is essential to
reduce the risk of fire or explosion. Acci-
dental disconnection of the plug can
cause sparks. This can result in serious
injury and property damage. Also read
FIRE OR EXPLOSION HAZARD in
sprayer manuals.
For detailed instructions and warnings, see sprayer
manuals.
201
203
1. Remove two screws (203) from pressure control box.
2. Install plug retainer (202) around power cord plug (201).
3. Plug power cord (201) into pressure control.
4. Attach plug retainer (202) with two screws (203).
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440–1441
202
COPYRIGHT 1998, GRACO INC.
Graco Inc. is registered to I.S. EN ISO 9001
First choice when
quality counts.
201
240XXX*
CORD, power
202
192149
RETAINER, plug
203
114528
SCREW
* Select power cord part number from list below:
240539 CORD, power
(220V for Continental Europe, CEE 7/7)
240540 CORD, power (220V for Italy)
240543 CORD, power (220V–bare end)
241852 CORD, power (240V for Australia)
Ultra Max 1595 and Mark V only
241879 CORD, power (240V for Australia)
Ultra Max 795 and 1095 only
308838
Rev. C
1
1
2
