Sharp R-1500AT Service Manual page 43

SW4: Monitor switch
SW3:
Monitor
switch
SW2:
Secondary
interlock
switch
SW1:
Secondary
interlock
switch
Gray/Red
SW5:
Door sensing
switch
LATCH SWITCHES
Blue (Blue case)
White (Blue case)
Brown
Gray
Main wire
Gray/Red
harness
White/Blue (Blue case)
Gray (Blue case)
White/White
Green/Green
DC
Orange
harness 22
12 – 4
High voltage
rectifier (1)
MG1
Magnetron
FA
F
C2
High voltage
capacitor (2)
Wiring of high voltage components
R1500AT
C1
High voltage
capacitor (1)
Asymmetric rectifier (1)
T1: Power
transformer (1)
High voltage rectifier (2)
Asymmetric rectifier (2)
FA
F
MG2: Magnetron
T2: Power transformer
