COMMERCIAL MICROWAVE OVEN
Original Instruction
-
OPERATION MANUAL
This operation manual contains important information which you should read
GB
carefully before using your microwave oven.
IMPORTANT:
There may be a serious risk to health if this operation manual is not followed or if the oven is modified so that it operates
with the door open.
R-15AT 1000W(IEC 60705)
1

Advertisement

Table of Contents
loading

Related Manuals for Sharp R-15AT

Summary of Contents for Sharp R-15AT

  • Page 1 This operation manual contains important information which you should read carefully before using your microwave oven. IMPORTANT: There may be a serious risk to health if this operation manual is not followed or if the oven is modified so that it operates with the door open. R-15AT 1000W(IEC 60705)
  • Page 2 1. In the European Union If the product is used for business purposes and you want to discard it: Please contact your SHARP dealer who will inform you about the take-back of the product. You might be charged for the costs arising from take-back and recycling.

  • Page 3: Table Of Contents

    CONTENTS PART NAMES ..........2,3 HOW TO OPERATE THE OVEN ....... 5 IMPORTANT SAFETY INSTRUCTIONS ..1 CARE AND CLEANING ........14 INSTALLATION INSTRUCTIONS ....3 GUIDE .............. 15 ACCESSORIES ..........3 SPECIFICATIONS ..........18 SERVICE CALL CHECK ......... 4 SERVICE PROCEDURE FOR GERMANY ..

  • Page 4: Part Names

    PART NAMES OVEN " 1 Control panel 2 Door lock openings 3 Oven lamp 4 Ceramic floor (Not removal) 5 Door hinges 6 Door 7 Door open handle 8 Safety door latches & 9 Door seals and sealing surfaces 10 Cavity face plate 11 Air ventilation cover and openings 12 Power supply cord 13 Air intake filter (Air intake openings)

  • Page 5: Important Safety Instructions

    7. Clean the ceramic floor and the oven cavity damaged, it must be replaced by an authorised after use. These must be dry and free from SHARP service agent in order to avoid a hazard. grease. Built-up grease may overheat and begin to smoke or catch fire.
  • Page 6 In the event of a spill, turn off and unplug the oven immediately, and 2. Children should be taught all important safety call a SHARP service agent. instructions: use of pot holders, careful removal of food coverings; paying special attention to 3.

  • Page 7: Installation Instructions

    • Caution sheet (SPECIAL INSTRUCTIONS AND WARNINGS: part code TCAUHA429WRRZ and TCAUHA445WRRZ) NOTE: • When you order accessories, please mention the two items: part name and model name to your dealer or SHARP authorized service agent. • The model name is printed on the cover of this operation manual.

  • Page 8: Service Call Check

    E. At the end of this time, is the water warm? YES ____ NO _____ If "NO" is the answer to any of the above questions, call your dealer or an authorized SHARP Service Agent and report the results of your check.

  • Page 9: How To Operate The Oven

    HOW TO OPERATE THE OVEN NOTES : Introduction: Water, sugar and fat in food absorbs microwaves and causes their molecules to vibrate. • Microwaves pass through non-metallic dishes This creates heat by friction, in the same way your and utensils and heat the food inside the dishes. hands get warm when you rub them together.
  • Page 10 COOKING DOUBLE QUANTITY WITH MEMORY Example: If you want to cook a double quantity using memory 1. Step Procedure Key Order Display Press the DOUBLE QUANTITY key. NO. X2 NO. will flash on and off. Press the NUMBER key NO. X2 After about 1 sec.
  • Page 11 To programme time and power level into a memory Example: If you want to set 4 minutes on 60% for the 1st sequence and 2 minutes on 30% for the 2nd sequence for 1 serving in memory 1. Step Key Order Procedure Display Press the SET key twice within 2 sec-...
  • Page 12 To change the time constant for double quantity The time constant for double quantity is preset 1.7 times the single quantity cooking time, but you can alter this constant to suit your needs. Example: If you want to change the time constant to 1.67 in memory 1. Step Procedure Key Order...
  • Page 13 MEMORY CHECK You can check the information programmed into the memory. Checking time and power level Example: If you want to know the information programmed into the memory 1, memory 1 has been programmed for 4 minutes on 60% for the 1st sequence and 2 minutes on 30% for the 2nd sequence. Step Display Procedure...
  • Page 14 MANUAL COOKING Your oven can be programmed for up to 3 cooking sequences and has 11 preset microwave power levels. See page 6. You can enter cooking time up to 30 minutes for each stage. The total cooking time is 30 minutes maximum. NOTE FOR MANUAL COOKING 3.
  • Page 15 SEQUENCE PROGRAMMING This facility enables continued and uninterrupted operation of up to three different sequences. Example: If you want to cook for 5 minutes on 70% followed by 3 minutes on 100% Step Procedure Key Order Display Press the SELECT TIME key. Enter desired cooking time for the 1st sequence.(5 minutes) Press the SELECT POWER key.
  • Page 16 OTHER CONVENIENT FEATURES EXPRESS DEFROST Express Defrost is used to defrost meat and poultry. Enter desired defrost time, referring to the defrost chart. Example: If you want to defrost for 7 minutes and 30 seconds. Step Procedure Key Order Display Press the EXPRESS DEFROST key.
  • Page 17 COUNTER CHECK Set the counters to "0" before using your new oven (see COUNTER CLEAR below) to keep a record of the oven use. Example: If you want to know the total amount of times the oven has been used, and the number of times each programme has been used.

  • Page 18: Care And Cleaning

    INFORMATION WITH ERROR MESSAGE If ERROR message is displayed, follow the instructions below. ERROR MESSAGE The time you set exceeds a maximum time. Touch STOP/CLEAR key and enter appropriate time. CARE AND CLEANING CLEAN THE OVEN AT REGULAR INTERVALS AND REMOVE ANY FOOD DEPOSITS - Keep the oven clean, or the oven could lead to deterioration of the surface.This could adversely affect the life of the appliance and possibly result in a hazardous situation.

  • Page 19: Guide

    GUIDE USEFUL THINGS TO KNOW ABOUT MICROWAVES Metals Microwaves set the water molecules contained in the should not, as a rule, be used in microwave ovens food vibrating. The resulting friction generates heat because microwaves cannot penetrate metals and that can be used to defrost or cook the food. reach the food inside.
  • Page 20 INFORMATION ABOUT POWER LEVEL 100%-70% power: The high power is perfect for warming up or regenerating food. You can also use it to make food boil e.g. water and then cook further with lower power.(e.g. for rice or noodles) 60%-40% power: For longer cooking times and compact types of food.
  • Page 21 Int. Microwave Menu 2 Stck 1 Stck Temp. Power Levels 100% SPECIALS Danish Pastrys 20±2°C ca. 10 sec. – 100% *Douhgnuts/Berliner 20±2°C ca. 9 sec. ca. 14 sec. *Boucheés à la reine 20±2°C 100% ca. 20 sec. ca. 27 sec. *Burger 5±2°C 100%...

  • Page 22: Specifications

    (This product is designed for commercial application only and as such it falls outside the scope of Regulation (EC) 1275/2008 implementing EU Directive 2005/32/EC on eco-design requirements for standby and off mode electric power consumption. Sharp do not recommend the product for domestic application and will not accept any liability for such use.)

  • Page 23: Service Procedure For Germany

    Sollte Ihr Profi-Mikrowellengerät trotz sorgfältiger Herstellung und Endkontrolle einen Mangel aufweisen, können Sie innerhalb der Garantiezeit zusätzlich zu den gesetzlichen Sachmängelansprüchen, die Ihnen gegen Ihren Verkäufer zustehen, Garantieleistungen gegen Sharp Electronics (Europe) GmbH in Anspruch nehmen. Diese stehen Ihnen zu, wenn ein herstellungsbedingter Material- und/oder Verarbeitungsmangel (nachfolgend "Mangel") bei dem Profi-Mikrowellengerät oder Teilen davon - mit Ausnahme der Garraum-Glühlampe-innerhalb von 24 Monaten auftritt.
  • Page 24 Manufacturer: SHARP Corporation 22-22, Nagaike-cho, Abeno-ku, Osaka 545-8522, Japan Authorised Representative: SHARP Electronics Europe Ltd. 4 Furzeground Way, Stockley Park, Uxbridge, Middlesex, UB11 1EZ, UK TINSZA280WRRZ-H31 Printed in Thailand...
