8.2 Dimensions of Outdoor Unit
8.2.1 Dimensions of Outdoor Unit
Model
R24PEV1K
RY24PEV1K
Item
A
1018
B
C
D
E
8.2.2 Dimension Requirement of the Installation Space of Outdoor Unit
0.5m
8.3 Precautions on Installation of Outdoor Unit
To ensure the unit in proper function, selection of installation location must be in accordance with following
principles:
(1) Outdoor unit shall be installed so that the air discharged by outdoor unit will not return and that suffi cient
space for repair shall be provided around the machine.
(2) The installation site must have good ventilation, so that the outdoor unit can take in and exhaust enough
air. Ensure that there is no obstacle for the air intake and exhaust of the outdoor unit. If there is any obsta-
cle blocking the air intake or exhaust, remove it.
(3) Place of installation shall be strong enough to support the weight of outdoor unit, and it shall be able to
insulate noise and prevent vibration. Ensure that the wind and noise from the unit will not affect your
neighbors.
(4) Avoid direct sunshine over the unit. It is better to set up a sun shield as the protection.
(5) Place of installation must be able to drain the rainwater and defrosting water.
English
R30PEV1K
RY30PEV1K
980
412
427
695
790
572
610
378
395
0.5m
B
Fig.8.3
R36PEY1K
RY36PEY1K
1018
412
840
572
378
2m
Fig.8.4
D
A
Unit: mm
R42PEY1K
RY42PEY1K
R48PEY1K
RY48PEY1K
1107
440
1100
631
400
0.5m
27
