- Page 1 OPERATION MANUAL DAIKIN ROOM AIR CONDITIONER MODELS FDMF50VVMG FDMF60VVMG FDMF71VVMG...
- Page 3 Read Before Operation Contents „ „ Read Before Operation Care Safety Precautions ........Care and Cleaning ........Names of Parts ..........„ When the Need Arises „ Multi Connection Troubleshooting ........... Note for Multi System ........Safety Precautions Read the precautions in this manual carefully This appliance is filled with R32.
- Page 4 Read Before Operation • Be sure to earth the unit. Do not earth the unit to a utility pipe, lightning conductor or telephone earth lead. Imperfect earthing may result in electric shock. CAUTION • Do not use the air conditioner for purposes other than those for which it is intended. Do not use the air conditioner for cooling precision instruments, food, plants, animals or works of art as this may adversely affect the performance, quality and/or longevity of the object concerned. • Do not expose plants or animals directly to the airflow from the unit as this may cause adverse effects. • Do not place appliances that produce naked flames in places exposed to the airflow from the unit as this may impair combustion of the burner. • Do not block the air inlets nor outlets. Impaired airflow may result in insufficient performance or trouble. • Do not sit on the outdoor unit, put things on the unit, or pull the unit. Doing so may cause accidents, such as falling or toppling down, thus resulting in injury, product malfunctioning, or product damage. • Do not place objects that are susceptible to moisture directly beneath the indoor or outdoor units. Under certain conditions, condensation on the main unit or refrigerant pipes, air filter dirt or drain blockage may cause dripping, resulting in fouling or failure of the object concerned. • After prolonged use, check the unit stand and its mounts for damage. If they are left in a damaged condition, the unit may fall and cause injury. • To avoid injury, do not touch the air inlet or aluminium fins of the indoor or outdoor units. • The appliance is not intended for use by unattended young children or infirm persons. Impairment of bodily functions and harm to health may result. • Children should be supervised to ensure that they do not play with the unit or its remote controller. Accidental operation by a child may result in impairment of bodily functions and harm health. • Avoid impacts to the indoor and outdoor units, or otherwise product damage may result. • Do not place flammable items, such as spray cans, within 1m of the air outlet. The spray cans may explode as a result of hot air from the indoor or outdoor units.
- Page 5 Read Before Operation Names of Parts Indoor Unit Drain discharge device Model name (built-in) (Model name plate) Drain piping Suction filter chamber (Sold separately) Suction duct (Field supply) Air filter Exhaust duct (Sold separately) (Field supply) Suction grille Air outlet grille (Field supply) (Field supply) Wiring between the indoor and outdoor units Refrigerant piping...
- Page 6 Multi Connection Note for Multi System A multi system has one outdoor unit connected to multiple indoor units. „ Selecting the operation mode 1. When the priority room setting is active but the set unit is not operating or when the priority Room A Room B room setting is inactive When more than one indoor unit is operating, priority is given to the first unit that was turned on.
- Page 7 Care Care and Cleaning CAUTION • Only a qualified service person is allowed to perform maintenance. • Before cleaning, be sure to stop the operation and turn off the circuit breaker. • Do not touch the aluminium fins of the indoor unit. If you touch those parts, this may cause an injury. „ How to clean the air fi lter When the remote controller indicates “Time to clean filter”, clean the air filter. • It indicates after running for a certain time. NOTE For cleaning, do not use any of the following: • Water hotter than 40°C • Volatile liquid such as benzine, petrol and thinner • Polishing compounds • Rough materials such as a scrubbing brush • You may change the time of indication “Time to clean filter”. If the indoor unit is used in a space where the air is too contaminated, ask your local dealer for solution. Contamination Time until indication is displayed 2500 hours...
- Page 8 Care Care and Cleaning „ How to clean air outlet, outside panels and remote controller Clean with soft cloth. When it is difficult to remove stains, use water or neutral detergent. NOTE • Do not wash the suction grille with water of 50°C or higher. It may cause discoloration and deformation.
- Page 9 When the Need Arises Troubleshooting Before making an inquiry or a request for repair, please check the following. If the problem persists, consult your dealer. Not a problem Check This case is not a problem. Please check again before requesting repairs. Case Description / what to check Operation does not start soon. • This is to protect the air conditioner. • When ON/OFF button was pressed You should wait for about 3 minutes. soon after operation was stopped. • When the mode was reselected „ When the air conditioner operates immediately after the circuit breaker is turned on Air does not come out.
- Page 10 When the Need Arises Troubleshooting „ Call your dealer immediately WARNING When an abnormality (such as a burning smell) occurs, stop operation and turn off the circuit breaker. • Continued operation in an abnormal condition may result in problems, electric shock or fire. • Consult the dealer where you bought the air conditioner. Do not attempt to repair or modify the air conditioner by yourself. • Incorrect work may result in electric shock or fire.
- Page 12 The two-dimensional bar code is a manufacturing code. M20N056 (2008) 3P620957-9A...
