©2016 Lennox Industries Inc.
Dallas, Texas, USA
V
E
HW
Lennox Global VRF Unit
VE
Evaporator Type: HW, UM, CC, 4C, 1C, 2C, HD, SD, LD, GD, AH, OA
HW
Cooling Capacity MBtu/h
007
Certification Status: N: Non-certified; C: AHRI/ETL;
N
4
Refrigerant: 4: R410a
Internal Use
32
