- Page 1 ...
- Page 2 • Ihre Verkaufsstelle Die Adressen Ihrer Servicepartner finden Sie im Garantieheft oder im Service-Adressenheft. Aktuelle Informationen zu unseren Produkten, Tips, Updates usw. finden Sie im Internet: http://www.fujitsu-siemens.com Is there ..any technical problem or other question you need clarified? Please contact: •...
- Page 4 ! " # $ % & ' ( ) * ...
- Page 5 Deutsch li h English Systembaugruppe D1159 System Board D1159 Technisches Handbuch Technical Manual Ausgabe November 1999 December 1999 edition...
- Page 6 Alle weiteren genannten Warenzeichen sind Warenzeichen oder eingetragene Warenzeichen der jeweiligen Inhaber und werden als geschützt anerkannt. Copyright Fujitsu Siemens Computers GmbH 1999 Alle Rechte vorbehalten, insbesondere (auch auszugsweise) die der Übersetzung, des Nachdrucks, der Wiedergabe durch Kopieren oder ähnliche Verfahren.
-
Page 7: Table Of Contents
Contents Introduction ............................1 Notational conventions......................1 Important notes..........................1 Information on boards ....................... 2 Features ............................3 Interfaces and connectors......................5 Temperature monitoring / system monitoring ................7 Hard disk connection......................... 8 port............................ 8 PCI bus interrupts ........................8 Settings............................. -
Page 9: Introduction
Introduction These system boards are available in different configuration levels. Depending on the hardware configuration of your device, it may be that you cannot find several options in the system board, even though they are described. You may find further information in the description "BIOS Setup". Notational conventions The meanings of the symbols and fonts used in this manual are as follows: Pay particular attention to texts marked with this symbol. -
Page 10: Information On Boards
Important notes The shipped version of this board complies with the requirements of the EEC directive 89/336/EEC "Electromagnetic compatibility". Compliance was tested in a typical PC configuration. When installing the board, refer to the specific installation information in the Operating Manual or Technical Manual of the receiving device. Connecting cables for peripherals must be adequately insulated to avoid interference. -
Page 11: Features
PXE. • Alert On LAN • Fujitsu Siemens system monitoring and temperature management • 2 RIMM slots for 64 to 1 Gbyte main memory (RIMM memory modules) • 1 additional board for SDRAM for 64 Mbyte to 512 Mbyte main memory (SDRAM memory modules of the DIMM format) •... - Page 12 Features • 1 AGP slot, 5 PCI slots AGP and PCI slots support 3.3 V main and auxiliary voltages. • AC'97 for audio devices • IDE hard disk controller connected to PCI bus for up to four IDE drives (e.g. IDE hard disk drives, ATAPI CD-ROM drives) The IDE hard disk controllers are designed for the extended busmaster ultra DMA33 mode and ultra ATA/66, and support the PIO modes 0 to 4.
-
Page 13: Interfaces And Connectors
Features Interfaces and connectors 1 = PS/2 keyboard port 5 = USB port 2 2 = PS/2 mouse port 6 = USB port 1 3 = Parallel port 7 = LAN port 4 = Serial port 1 The components and connectors marked do not have to be present on the system board. English - 5 U41126-J-Z156-1-74... - Page 14 Features 1 = Power supply monitoring 9 = Fan (e. g. for the optional fan (AUX)) 2 = Power supply 10 = Wake On LAN 3 = IDE drives 3 and 4 (secondary) 11 = Cover monitoring 4 = Connector for front panel 12 = I²C connector (primary SMBus) 5 = IDE drives 1 and 2 (primary) 13 = Fan for CPU 0 (processor 0)
-
Page 15: Temperature Monitoring / System Monitoring
The cover monitoring protects the system from unauthorized opening. The temperature and system monitoring are controlled by an onboard controller developed by Fujitsu Siemens. The following functions are supported: Temperature monitoring:... -
Page 16: Hard Disk Connection
Features With hardware monitoring - regardless of the operating system and processor - the advantages compared to conventional software monitoring are clear: − suitable for all operating systems and processor types − no additional load on processor (performance) − optimum reliability, even if process faults or faults are present in the operating system −... -
Page 17: Settings
Settings Settings 1 = Jumper 2 = Switch block Switch block Switch 1 = must be set to off Switch 3 = Write-protection for floppy disk Switch 2 = System BIOS recovery (RCV) Switch 4 = Clear CMOS (must be set to off during operation) Processor's clock speed The clock frequency of the processor is set automatically. -
Page 18: Setting Usb Power Jumper
Settings Setting USB power jumper The power supply of the USB port is set with the jumper. The USB port is only supplied with power when switched on. Position 1 - 2 The USB port is always supplied with power (default setting). Position 2 -3 Recovering System BIOS - switch 2 Switch 2 enables recovery of the old system BIOS after an attempt to update has failed. -
Page 19: Add-On Modules
Add-on modules Add-on modules For all steps described in this chapter exit the suspend mode before switching off the device and then pull the power plug out of the power outlet! Even when you have run down the device, parts of the device (e. g. memory modules, AGP and PCI extension boards) are still energized. -
Page 20: Installing / Removing Processor
Add-on modules Installing / removing processor Replacing the processor You can replace the processor in the slot of the first processor. The system board can be upgraded by a second processor if it is inserted into the slot for the second processor. If the system board only has one processor (inserted into the slot for the first processor (CPU 0)), a terminating board is installed in the slot for the second processor. -
Page 21: Upgrading Main Memory
Add-on modules Remove the old processor if necessary. Slide the processor into the bracket (1). Push the processor down in the bracket and press it into the slot until the clamps (2) to the left and right snap into place. If the processor has a temperature sensor or a fan, attach the associated cable to the connector for the temperature sensor or the fan on the system board. - Page 22 Add-on modules Removing C-RIMM or memory module Flip the holders to the right and left of the location outwards (1). Slide the module out of its slot (2). Installing C-RIMM module or memory module Note the coding of the module! Flip the holders on each side of the relevant location outwards.
-
Page 23: Installing Network Board With Wol
Add-on modules Installing network board with WOL Install the network board as described in the operating manual for your unit. Push the WOL cable onto the WOL plug connector of the system board. To use the WOL functionality of a network board the power supply must provide a 5 V auxiliary voltage of at least 1 A. -
Page 24: Glossary
Glossary Glossary The technical terms and abbreviations given below represent only a selection of the full list of common technical terms and abbreviations. Not all technical terms and abbreviations listed here are valid for the described system board. AC'97 ......Audio Codec '97 AGP ......Accelerated Graphics Port AMR ......Audio Modem Riser AOL......Alert On LAN... - Page 25 Information on this document On April 1, 2009, Fujitsu became the sole owner of Fujitsu Siemens Compu- ters. This new subsidiary of Fujitsu has been renamed Fujitsu Technology So- lutions. This document from the document archive refers to a product version which was released a considerable time ago or which is no longer marketed.
