Goodman GMVS96-U Quick Start Manual

Heating Input: 60,000-80,000 BTU/h
Standard Features
• Integrated communicating ComfortBridge™ Technology
• Commissioning and diagnostics via indoor board Blue-
tooth with the CoolCloud™ phone and tablet application
• Heavy-duty stainless-steel tubular heat exchanger
• Super-ferritic Stainless-steel secondary heat exchanger
• Single-stage gas valve
• Durable Silicon Nitride igniter
• Quiet modulating induced draft blower
• Self-diagnostic control board with constant memory
fault code history output to 3 x 7 segment display
• Eligible for installation in California's South Coast Air
Quality Management District (SCAQMD) and San
Joaquin Valley Air Pollution Control District (SJVUAPCD).
This furnace complies with the 14 ng/J NOx emission
limit in SCAQMD Rule 1111 and SJVUAPCD Rule 4905.
• EMI line filter kit must be installed. (It is intended for
field installation only on "VS" model, Bluetooth® capable
Ultra Low NOx Gas Furnaces. The purpose of the EMI
Filter is to reduce electromagnetic interference between
the furnace and other electrical devices)
• AHRI Certified; ETL Listed
SS-GMVS96-U
Cabinet Features
• Designed for multi-position installation -
• Certified for direct vent (2-pipe)
• Easy-to-install top venting with optional side venting
• Convenient left or right connection
• Cabinet air leakage (Q
• Heavy-gauge steel cabinet with durable finish
• Fully insulated heat exchanger and blower section
• Airtight solid bottom or side return with
* Complete warranty details available from your local dealer or at www.amana-hac.com. To receive the Lifetime Heat Exchanger Limited Warranty (good
for as long as you own your home), 10-Year Unit Replacement Limited Warranty and 10-Year Parts Limited Warranty, online registration must be
completed within 60 days of installation. Online registration is not required in California or Québec.
www.goodmanmfg.com
GMVS96-U
Ultra Low NOx, Single-Stage,
Variable-Speed ECM Gas Furnace
Contents
Nomenclature ............................................2
Product Specifications ............................... 3
Dimensions ................................................4
Airflow Specifications ................................5
Accessories ................................................5
Wiring Diagram ..........................................6
upflow, horizontal left or right
or non-direct vent (1-pipe)
for gas and electrical service
) ≤ 1.4%
Leak
easy-cut tabs for effortless removal in
bottom air-inlet applications
Up to 96% AFUE
6/20
