Arrow Storage Products HDVAS107 Owner's Manual & Assembly Manual

10' x 7'
Hide thumbs

Advertisement

Quick Links

Download this manual
719280814
Owner's Manual
& Assembly Guide
Gloves must be worn
at all times to reduce
risk of injury!
Customer Service:
1-800-851-1085
assist@arrowsheds.com
BUILDING DIMENSIONS
†
Approx.
Size
10' x 7'
64 Sq. Ft. 432 Cu. Ft.
3,0 m x 2,0 m
6,0 m
* See Inside for Detailed Safety Information.
or
†
Size rounded off to the nearest foot
Exterior Dimensions
Storage
(Roof Edge to Roof Edge)
Area
Width
123 1/4"
2
12,2 m 3
313,1 cm
Depth
Height
Width
83 1/2"
90 5/8"
118 1/4"
212,1 cm
230,2 cm
300,4 cm
www.arrowsheds.com
Model No.
10' x 7'
Base
Size
307,3 cm x 205,7 cm
For proper base construction see page 12
Interior Dimensions
(Wall to Wall)
Depth
Height
78 1/4"
89 3/8"
198,8 cm
227,0 cm
01X
HDVAS107
Nominal Size
121" x 81"
Door
Opening
Width
Height
59 1/2"
69 1/4"
151,1 cm
175,9 cm

Advertisement

loading

Related Manuals for Arrow Storage Products HDVAS107

Summary of Contents for Arrow Storage Products HDVAS107

  • Page 1 719280814 Owner’s Manual & Assembly Guide www.arrowsheds.com Gloves must be worn at all times to reduce risk of injury! Model No. HDVAS107 10’ x 7’ Nominal Size Customer Service: 1-800-851-1085 Base 121” x 81” assist@arrowsheds.com Size 307,3 cm x 205,7 cm BUILDING DIMENSIONS †...
  • Page 2 SAFETY PRECAUTIONS... Safety precautions MUST be followed at all times throughout the construction of your building! Practice caution with the tools being used in the Care must be taken when handling various pieces assembly of this building. Be especially familiar with of your building since many contain sharp edges.
  • Page 3 ASSEMBLY TIPS & TOOLS Watch the Weather Closely: Be sure the day you choose to install your building is dry and calm. Do NOT attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Use Teamwork: Two or more people are required to assemble your building.
  • Page 4 FREQUENTLY ASKED QUESTIONS How long will it take to assemble the building? Assembly time depends on a variety of factors, including roof design, tools available, DIY skill and the pace at which you work. Guidelines for each shed assembly are approximate AFTER completion of the base, and assume two or more people working on the assembly.
  • Page 5 What kind of base do I use? You can: •Use an Arrow Base Kit •Pour a concrete slab •Build a wood deck/fl oor (use exterior-grade plywood) •Use patio blocks •Build on crushed gravel, dirt or grass Arrow provides a base kit accessory that is an option for most building sizes. If you are building a wood deck/fl oor, an Arrow fl...
  • Page 6 What if the rear wall angle and channels are too large to fi t inside of the rear wall panels? Check the dimensions of wall assemblies. They should be slightly smaller than the fl oor frames. Lay the assemblies on top of the rear fl oor frame and pull them up to the top of the wall panels causing the corner panels to stand erect and not lean inward.
  • Page 7 HARDWARE LIST... Part Hardware Views by Key No. Part Qty. Description List 65103 Hex Nut (#8-32) 65923-61 Small Bolt (Stone) (#8-32 x 3/8) (10 mm) #2 Phillips #2 Phillips 11/32 Hex. 65923-62 Small Bolt (Vanilla) (#8-32 x 3/8) (10 mm) 65923-06 Small Bolt (Black) (#8-32 x 3/8) (10 mm) 65004-61 Small Screw (Stone) (#8AB x 5/16) (8 mm) 65004-62 Small Screw (Vanilla) (#8AB x 5/16) (8 mm)
  • Page 8 PARTS LIST... Selected End Views by Key No. Part No. Part Description Qty. List 5284 Right Corner Post 1&2 5285 Left Corner Post 5287 Rear Splice Post 10778 Roof Beam 8364 Side Roof Trim 10786 Ridge Cap 6634 Gable Brace 8189 Shelf Bracket 9704...
  • Page 9 ASSEMBLY BY KEY NO. NOTE: Double Wall Studs are used on side and back walls to support Siding Panels. Walls Floor...
  • Page 10 ASSEMBLY BY KEY NO. Roof Doors...
  • Page 11 ASSEMBLY OVERVIEW Erect Post, Studs, and Door Jambs Build the Floor Frame Install Siding Panels Attach Gables and Roof Beams Install Roof Panel, Decorative Install Doors Gable Piece, Ridge Cap, Side Shed is now complete. Trim, Corner Cap...
  • Page 12 CONSTRUCTING A BASE... No matter which of the options below you choose for a base, an ARROW ANCHORING KIT is recommended as an effective method of properly securing your building after assembly is complete. OPTION 1: Directly on ground (earth) Assemble your building directly on level ground (grass, dirt, rock, sand, etc.).
  • Page 13 Step 1: Floor Frame Pre-Assembly You will need for this page: Washers are to be 10703 used painted parts only. Washers are not necessary on unpainted Front/Rear parts and there are not enough Floor Frame (QTY: 8) to use on every Screw and Bolt. Join two (2) Front/Rear Floor Frames together by overlapping them as shown and secure the Frames with four (4) Stone Bolts and Nuts.
  • Page 14 Step 2: Frame Pre-Assembly You will need for this page: 9339 9338 10707 10708 Left Rear Right Rear Front Inner Front Outer (QTY:2) Wall Angle Wall Angle (QTY: 1) Header Header Connect the Front Inner Header to a Front Outer Header using one (1) Stone Screw as shown.
  • Page 15 Step 3: Stud Assembly You will need for this page: 9344 (QTY:72) Siding Stud Join two (2) Siding Studs together using six (6) Stone Screws as shown. BUILD TWELVE (12) ASSEMBLIES 9344 9344 Top view of Siding Studs. 35 9/16” (90,3 cm) Repeat process to make eleven (11) more assemblies.
  • Page 16 Step 4: Roof Beam Assembly You will need for this page: 10778 10777 Roof Beam Roof Beam (QTY: 20) Place two (2) 2” (5,1 cm) Roof Beams back-to-back with small holes on top. Fasten together using four (4) Stone Bolts and Nuts. DO NOT FULLY TIGHTEN. BUILD FOUR (4) ASSEMBLIES End view of Roof Beam 10778...
  • Page 17 Step 5: Door Pre-Assembly You will need for this page: 10782 10718 10719 10720 67236 Horizontal Door Handle Diagonal Door Adhesive Pad Door Panel (QTY: 2) Door Brace Brace Brace (QTY: 24) Start assembly by sliding the Door Handle Place the ends of Diagonal Door Braces with Brace into the middle of the Door and securing small holes under Horizontal Door Braces it with four (4) Stone Screws.
  • Page 18 Step 6: Right Door Assembly You will need for this page: 66609 66809 66054 66811 Handle Locking (QTY: 2) (QTY: 6) (QTY: 6) Hinge Handle Right Latch Backplate 66812 Hinge Plate Decor Attach Hinges to Door using six (6) Flat Head Bolts. Install Locking Handle and Handle Backplate...
  • Page 19 Step 7: Left Door Assembly You will need for this page: 66609 66810 66811 66812 Handle Hinge Plate Left (QTY: 2) (QTY: 6) Hinge Backplate Decor Handle (QTY: 6) Attach Hinges to Door using six (6) Flat Head Bolts. Locking Handle Install Handle Backplate using two (2)
  • Page 20 Step 7: Continued You will need for this page: 66808 10721 66684 Bottom Top Latch Door Stop (QTY: 8) Latch Spring Spring Remove two (2) Screws from left side of Door Handle Brace and far left Screw from both top and bottom Horizontal Door Brace.
  • Page 21 Step 8: Floor Assembly You will need for this page: Assemblies from Step 1: 10784 • Floor Frame Assemblies (2) Side Floor (QTY: 8) Frame The remainder of the building assembly requires many hours and more than one person. Do not continue beyond this point if you do not have enough time to complete the assembly today.
  • Page 22 Step 9: Posts/Frame You will need for this page: Assemblies from step 2: 5284 5285 10779 • Header Assembly (1) • Rear Wall Angle Right Corner Left Corner Side Wall Post Post Angle Assembly (1) (QTY: 22) Position Right and Left Corner Posts at the corner of the Floor Frame as shown.
  • Page 23 Step 10: Splice Post/Door Jamb You will need for this page: 10780 80069 5287 Rear Splice Right Door Left Door (QTY: 4) (QTY: 6) Post Jamb Jamb (QTY: 4) Position Splice Post at the center of the rear wall and fasten using two (2) Stone Screws into rear Floor Frame and four (4) Stone Bolts and Nuts into Rear Wall Angle Assembly.
  • Page 24 Step 11: Studs You will need for this page: 10834 Assemblies from step 3: • Stud Assemblies (12) Front Wall Channel (QTY: 2) (QTY: 16) Following dimensions, measuring from the end of angle, position a Stud Assembly inside top angle and fasten with one (1) Stone Screw through the lower hole of angle. Place bottom of Stud Assembly over Floor Frame as shown.
  • Page 25 Step 12: Side Siding You will need for this page: Washers are to be used on painted 10773 parts only. Washers are not necessary on unpainted parts and there are not enough to use on every Screw and Bolt. Side Siding (QTY: 36) (QTY: 24) Slide bottom Side Siding into channels of Corner Posts as shown.
  • Page 26 Step 13: Rear Siding You will need for this page: 10775 Rear Siding (QTY: 24) (QTY: 30) Slide bottom Rear Siding Panels into channels of Corner Posts and Splice Post as shown. Once in place, secure with four (4) Vanilla Screws per Panel. Screws going into bottom Floor Frame also secure Stud Assemblies.
  • Page 27 Step 14: Front Siding You will need for this page: 8827 Front Siding (QTY: 24) Slide Front Siding into channels of Corner Posts and Door Jambs as shown. Once in place, secure Panels from inside the building to the Corner Posts and Door Jambs using four (4) Stone Screws per Panel.
  • Page 28 Step 15: Gables You will need for this page: 9704 9703 6634 9496 69835 Right Gable Left Gable Gable Brace Gable Brace Edge Trim (QTY: 16) GABLES STACKED TOGETHER DURING SHIPPING MISTAKEN FOR ONE GABLE! SEPARATE GABLES BEFORE CONTINUING. Edge Trim (Plastic) Install Edge Trim to cover Gable Edge BEFORE doing ANY work with Gables.
  • Page 29 Step 15: Continued You will need for this page: 9009 67545 6228 Weather Gable Brace Track Support (QTY: 5) Stripping (QTY: 32) Working one (1) Gable at a time, lift Left and Right Gables into place on top of Rear Wall Angle.
  • Page 30 Step 16: Roof Beams/Braces You will need for this page: Assemblies from step 4: • Roof Beam Assembies (5) (QTY: 20) Side of Beams with small Secure the Roof Beam Assemblies holes must face up. to the Gables as shown using two (2) Stone Bolts and Nuts on each end of each Roof Beam Assembly.
  • Page 31 Step 16: Continued You will need for this page: 9204 Beam Brace (QTY: 4) In the front, attach the Roof Beam Brace to the Track Support with one (1) Stone Bolt and Nut as shown and rotate to align with Roof Beam. Secure to Roof Beam with one (1) Stone Bolt and Nut as shown.
  • Page 32 Step 17: Roof Assembly You will need for this page: 10770 10771 Roof Skylight (QTY: 6) Panel Panel Place Skylight Panel and Roof Panel according to the diagram below. Ensure that the ends of the Panels with the slotted holes are at the same end with the slot to the outside of the fi...
  • Page 33 Step 17: Continued You will need for this page: 80067 10774 67545 Right Roof Weather Left Roof (QTY: 24) (QTY: 12) Stripping Panel Panel Attach Back Right Roof Panel to Top Roof Beam only using Don’t focus weight four (4) Stone Screws. on roof! Remove Edge Trim from the Left Gable under the Roof Panel.
  • Page 34 Step 17: Continued You will need for this page: 67545 • Skylight Assemblies (2) Weather (QTY: 24) (QTY: 2) Stripping Don’t focus weight on roof! Attach two (2) Skylight Assemblies, one at a time, to Roof Beams using twelve (12) Stone Screws. Secure Skylight Assemblies to Back Roof Panels using one (1) Stone Bolt and Nut per Panel as shown below.
  • Page 35 Step 17: Continued You will need for this page: 80067 10774 66827 67545 Weather Left Roof Right Roof (QTY: 8) (QTY: 48) Gable Decor Stripping Panel Panel Don’t focus weight on roof! (QTY: 6) Attach Front Left and Right Roof Panels, one at a time, to Roof Beams using twelve (12) Stone Screws per Panel.
  • Page 36 Step 18: Ridge Cap/Roof Trim You will need for this page: 10786 8364 66183 66183 67468 Left Corner Side Roof Right Corner (QTY: 4) (QTY: 4) Ridge Cap Trim Peak Cap Don’t focus weight (QTY: 8) on roof! Fully tighten Bolts and Nuts on Roof Beams. Install Peak Caps and Ridge Cap using eight (8) Stone Bolts and Nuts as shown.
  • Page 37 Step 19: Door Installment You will need for this page: Assemblies from step 5: 10702 10827 • Right Door Assembly (1) Door Jamb • Left Door Assembly (1) (QTY:4) (QTY:12) Ramp Angle NEED AT LEAST TWO PEOPLE TO PERFORM THIS STEP! Place the Door Jamb Angles behind the Door Jambs.
  • Page 38 Step 20: Shelf Brackets You will need for this page: 8189 Shelf Bracket (QTY:8) Choose which sides and Studs to mount the Shelf Brackets on. Shelf Brackets can be installed on side and / or rear walls. If installing on rear wall, Shelf Brackets must be placed on adjacent Studs.
  • Page 39 ANCHORING OPTIONS... IMPORTANT: • If you have swing doors, they must hang and swing level before anchoring building. • Anchor your building at this time. See below for details on anchoring. • If you have purchased a Floor Frame Kit, you should install it at this time. •...
  • Page 40 CARE & MAINTENANCE... Exterior Care: For a long lasting fi nish, clean and wax the exterior surface. We recommend washing with a mild soap solution. DO NOT use power washing to clean your shed. Using a spray automotive type wax periodically on the exterior is highly recommended if you are in a high humidity or coastal climate region.
  • Page 41 ARROW ACCESSORIES... ANCHOR KITS FLOOR FRAME KITS Model No. AK4 MODELS FB47410, FB5465, Anchor Kit contains heavy-duty steel FB106-A, FB109-A, FB1014-A, augers, 60' (18 m) of steel cable and and FBSDS108 4 cable clamps. No digging or concrete pouring, just insert cable under roof, A simple fl...
  • Page 42 ASSEMBLY NOTES...
  • Page 43 ASSEMBLY NOTES...
