External Dimensions
291 mm (11.46")(W) x 253 mm (9.96")(D) x 231
mm (9.09")(H) (With the feed tray attached and the
document eject tray closed)
291 mm (11.46")(W) x 603 mm (23.74")(D) x
mm (14.29")(H) (With the feed tray attached and
the document eject tray open)
Weight (without AC adapter)
Aprpoximately 2.8 kg (6.17 lb)
Power Supply (using AC adapter)
DC24V 1.0A
Power Consumption
Scanning: Maximum 19W or less
In the Sleep mode: Maximum 1.4W or less
With power switch OFF: Maximum 0.1W or less
Noise Not more than 48 dB
Operating Environment
Temperature: 10°C to 32.5°C (50°F to 90.5°F)
Humidity: 20% to 80% RH
AC Adapter (100 to 240 V type)
Model Number MG1-5039 (24V)
Input AC100 to 240V, 50/60 Hz, 1.06 to 0.6 A
Output DC24V 2.0A
Weight Approximately 0.3kg (0.66 lb)
Specifications are subject to change without notice due to product
improvements.

Replacement parts

Exchange roller kit (product code: 0697C003)
Kit to replace the rollers (feed roller, retard roller).
• For the replacement procedure,
on p. 92.
• Contact your local authorized Canon dealer or service
representative for detailed information about the replacement parts.
see "Replacing Consumable Parts"
Option
Barcode module (product code: 1922B001)
2D code module(product code:1922B003)
363
Add-on module to recognize barcodes printed on documents during
scanning,
Carrier sheet (for passports) (Product code: 0697C002)
This is a carrier sheet for scanning passports.
Flatbed scanner unit102 (product code: 2152Cxxx)
Flatbed scanner unit that can be connected to and used with a DR
scanner. Connecting the unit to this scanner enables you to use this
scanner as a flatbed scanner with an automatic document feeder.
Flatbed scanner unit201 (product code:6240Bxxx)
A flatbed scanner unit that can be used by connecting to a DR scanner
and supports A3 size paper. Connecting the unit to this scanner
enables you to use this scanner as a flatbed scanner with an
automatic document feeder.

About the Flatbed Scanner Unit

The optional Flatbed Scanner Unit can be connected to and used with
this scanner.
System requirements
The computer must comply with the necessary system requirements
of Flatbed Scanner Unit.
The scanner driver of Flatbed Scanner Unit needs to be installed to
use the unit.
About Use with CaptureOnTouch
About Assigning Function to Start Button
When you connect Flatbed Scanner Unit, you can assign Scanning
Shortcut of CaptureOnTouch to the start button of Flatbed Scanner
Unit.
