SATA6G_1(Gray) - SATA6G_6(Gray)
SATA6G_1(Gray) - SATA6G_6(Gray)
This item allows you to enable or disable the selected SATA port.
Configuration options: [Disabled] [Enabled]
Hot Plug
These items appears only when the SATA Mode Selection is set to [AHCI] and allows
you to enable or disable SATA Hot Plug Support.
Configuration options: [Disabled] [Enabled]
3.6.6
PCH-FW Configuration
This item allows you to configure the firmware TPM.
3.6.7
Onboard Devices Configuration
The items in this menu allow you to switch between PCIe Lanes and configure onboard
devices.
HD Audio
This item allows you to use the Azalia High Definition Audio Controller.
Configuration options: [Disabled] [Enabled]
RGB LED lighting
When system is in working state
This item allows you to turn the RGB LED lighting on or off when the system is in the
working state.
Configuration options: [On] [Off]
When system is in sleep, hibernate or soft off states
This item allows you to turn the RGB LED lighting on or off when the system is in the
sleep, hibernate or soft off states.
Configuration options: [On] [Off]
3.6.8
APM Configuration
The items in this menu allow you to set system wake and sleep settings.
ErP Ready
This item allows you to switch off some power at S4+S5 or S5 to get the system ready for
ErP requirement. When set to [Enabled], all other PME options are switched off.
Configuration options: [Disabled] [Enable(S4+S5)] [Enable(S5)]
3-16
Chapter 3: BIOS Setup
