Page 2
Software licenses. If however you encounter any problems in obtaining the full corresponding source code we would be much obliged if you give us a notification to the email address gpl@asus.com, stating the product and describing the problem (please DO NOT send large attachments such as source...
Page 9
- AI Suite 3 - File transfer 搭載機能 <自作支援機能> UEFI BIOS EZ Mode - 直感的に操作できるグラフィカルなインター フェース - CrashFree BIOS 3 - ASUS EZ Flash 3 Utility Q-Design - Q-DIMM - Q-Slot - Fan Xpert 4 Core サーマル ソリューション - PCH & MOSヒートシンク採用ファンレス設計...
Page 10
TPM コネクター×1 CMOSクリアヘッダー×1 128 Mb Flash ROM、 UEFI AMI BIOS、 PnP、 SM BIOS 3.1、 ACPI 6.1、 多言語BIOS、 ASUS EZ Flash 3 Utility、 ASUS CrashFree BIOS 3、 BIOS機能 F11 EZ Tuning Wizard、 F6 Qfan Control、 F3 My Favorite、 F9 Search、 Last Modified Log、 F12画面キャプチャー、 ASUS SPD Information 管理機能...
Page 13
USB 3.1 Gen 1コネクター (20-1ピン USB3_12、 U31G1_56) U31G1_56 USB 3.1 Gen 1拡張用コネクターです。 USB 3.1 Gen 1増設用 PIN 1 ブラケットやフロントパネルUSB 3.1 Gen 1コネクターなど USB3+5V USB3+5V IntA_P1_SSRX- を接続することができます。 IntA_P2_SSRX- IntA_P1_SSRX+ IntA_P2_SSRX+ IntA_P1_SSTX- IntA_P2_SSTX- IntA_P1_SSTX+ IntA_P2_SSTX+ IntA_P1_D- IntA_P2_D- IntA_P1_D+ IntA_P2_D+ ASUS PRIME H370M-PLUS...
Page 14
M.2 Socket スロット (M.2_1、 M.2_2) M.2(SOCKET3) M.2 socket 3 (Key M)規格のSSDを取り付けることができま す。 本製品のM.2スロットは、 SATA / PCIe 両インター フェース 規格のストレージデバイスをサポートしています。 ・ M.2_1 スロット : Key M、 Type 2242/2260/2280、 SATA / PCI Express 3.0 x2 接続対応 。 M.2 Socket 3 第1スロット (M.2_1) にM.2 SATA SSDを取り付けた場合、 SATA 6Gb/s 第2ポート...
Page 15
USB 2.0コネクター (10-1ピン USB78, USB1114) USB78 USB1114 USB 2.0 ポート拡張用コネクターです。 USB 2.0 増設用ブラ ケットやフロントパネル USB 2.0 コネクターなどを接続す ることができます。 PIN 1 PIN 1 TPMコネクター (14-1ピン TPM) TPM (Trusted Platform Module) を接続することができま す。 TPMはプラットフォームの監視やデータの暗号化、 電子 証明書を保管といった高レベルなセキュリティ機能を備えて います。 PIN 1 ASUS PRIME H370M-PLUS...
Page 26
Please select boot device: and to move selection ENTER to select boot device ESC to boot using defaults P2: ST3808110AS (76319MB) aigo miniking (250MB) UEFI: (FAT) ASUS DRW-2014L1T(4458MB) P1: ASUS DRW-2014L1T(4458MB) UEFI: (FAT) aigo miniking (250MB) Enter Setup 画面に次のようなメッセージが表示されたら、 5秒以内に<Enter>を押しサポートDVDから FreeDOSを起動します。...
Consult the dealer or an experienced radio/TV technician for help. The use of shielded cables for connection of the monitor to the graphics card is required to assure compliance with FCC regulations. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. ASUS PRIME H370M-PLUS...
Page 36
Compliance Statement of Innovation, Science and Economic Development Canada (ISED) This device complies with Innovation, Science and Economic Development Canada licence exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
Page 37
ASUS Recycling/Takeback Services ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for you to be able to responsibly recycle our products, batteries, other components as well as the packaging materials.
Page 38
доступний на: www.asus.com/support Cijeli tekst EU izjave o sukladnosti dostupan je na: www.asus.com/support Türkçe AsusTek Computer Inc., bu aygıtın temel gereksinimlerle ve ilişkili Čeština Společnost ASUSTeK Computer Inc. tímto prohlašuje, že toto Yönergelerin diğer ilgili koşullarıyla uyumlu olduğunu beyan eder.
Page 40
800 Corporate Way, Fremont Phone/Fax No: (510)739-3777/(510)608-4555 hereby declares that the product Product Name : Motherboard Model Number : PRIME H370M-PLUS Conforms to the following specifications: FCC Part 15, Subpart B, Unintentional Radiators Supplementary Information: This device complies with part 15 of the FCC Rules. Operation is subject to the...
