REFRIGERATOR FOR ELECTRIC OPERATION
NDE1292
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
WARNING: Improper installation,
adjustment, alteration, service or
maintenance can cause injury or
property damage. Refer to this
manual. For assistance or additional
information consult a qualified
installer, service agency or the sup-
plier.
USA
Service Office
Dometic Corporation
509 South Poplar Street
LaGrange, IN 46761
Phone: 260-463-4858
825 12 33-00 (French 3309319.006)
INSTALLATION AND
®
OPERATING INSTRUCTIONS
Corporate Office
2320 Industrial Parkway Elkhart, IN 46515
For Service Center Assistance
Call: 800-544-4881
Contents:
Installation
Operating Instructions
Maintenance & Service
Pour votre sécurité
Ne pas entreposer ni utiliser de l'essence ni
d'autres vapeurs ou liquides inflammables à
proximité de cet appareil ou de tout autre
appareil.
Avertissement: Une installation, un réglage,
une modification, une réparation ou un
entretien non conforme aux normes peut
entraîner des blessures ou des dommages
matériels. Lisez attentivement le mode d'em-
ploi fourni avec l'appareil. Pour obtenir de
l'aide ou des renseignements supplémentai-
res, consultez un installateur ou un service
d'entretien qualifié ou le fournisseur.
®
Page
4
8
11
CANADA
Dometic Distribution Inc.
866 Langs Drive
Cambridge, Ontario
N3H 2N7 Canada
Phone: 519-653-4390
Advertisement
Related Manuals for Dometic NDE1292
Summary of Contents for Dometic NDE1292
- Page 1 ® Corporate Office CANADA Service Office 2320 Industrial Parkway Elkhart, IN 46515 Dometic Distribution Inc. Dometic Corporation 866 Langs Drive 509 South Poplar Street Cambridge, Ontario LaGrange, IN 46761 For Service Center Assistance N3H 2N7 Canada...
- Page 3 Heaters Power module and fuses Protection cover Thermofuse Drain water hose 12 volt Flexible cord FIG. 1 Terminal block AC relay Refrigerator control panel COLD 1 COLDEST LEGEND 1. Main Power Button ON/OFF 2. Temperature Selector Button A. AC Indicator Lamp B.
- Page 4 Vehicles and Mobile Housing. 12 Volts DC Connection If an external electrical source is utilized, the refrigera- The refrigerator model NDE1292 require a continuous tor, when installed, must be electrically grounded in ac- 12 volt DC supply to operate the control system.
- Page 5 INSTALLING REFRIGERATOR IN ENCLOSURE FIG. 4 The transport support at the rear of the refrigerator can be removed if necessary for the installation of the refrig- erator in the enclosure. (See figure above). Securing the Refrigerator After the refrigerator is put in place, the refrigerator is to NOTE: DO NOT install the appliance directly on be secured in the enclosure with six screws (not in-...
- Page 6 STEP 3: Two screws installed in the rear base. See FIG. 8. FIG. 8 FIG. 7 Hole for drain water hose Step 2: Two screws installed in the top frame. The top decoration panel must be removed from the re- frigerator before the screws can be installed.
- Page 7 CERTIFIED INSTALLATION METHODS OF INSTALLATION Certified installations require one roof vent and one lower The method of installation is shown in FIG. 9. It is es- side vent. sential that all maximum or minimum dimensions are For “Certified Vent System Kits” see page 13. strictly maintained as the performance of the refrigera- For further information contact your dealer or distribu- tor is dependent on adequate flow of air over the rear of...
- Page 8 FIG. 11 Side view View from above Overall Recess Refrigerator Dimensions Dimensions Model Height Width Depth Height Width Depth inch 59-31/32 33-11/16 26-21/32 59-1/16 32-3/4 NDE 1292 1523 1500 This method of installation and these clearances will give you adequate space for service and proper installation. OPERATING OPERATION This refrigerator is designed to work on 120 Volt AC.
- Page 9 DISPLAY PANEL COLD 1 COLDEST START UP INSTRUCTIONS DESCRIPTION OF OPERATING MODES A. A continuous 12 volt DC supply must be available for the electronic control to function. LIMP MODE OF OPERATION B. Press the main power ON/OFF button (1) to the This control system contains a feature where it will con- DOWN position.
- Page 10 When all the frost has melted, dry the interior of the re- HOW TO USE THE REFRIGERATOR frigerator and freezer with a clean cloth. Replace all food FOOD STORAGE COMPARTMENT and set the thermostat to the COLDEST temperature setting for a few hours. Then reset the thermostat to the The food storage compartment is completely closed and desired setting, usually at mid setting.
- Page 11 All RV absorption refrigerators, while similar, operate a The user should be aware of service that must be little differently than your home refrigerator. Dometic de- done on a regular schedule to keep the refrigerator signers and engineers have equipped your refrigerator operating properly.
- Page 12 Contact SPARE PARTS service point or distributor service dept. for assistance. The following list is a list of commonly used parts, which should be available, if required, from your Dometic Ser- vice Center. Part No. Description...
- Page 13 CERTIFIED VENT SYSTEM KITS REFRIGERATOR MODEL COMPONENTS PART NO. NDE 1292 Roof Base 3103633.XXX* Roof Cover 3103634.XXX* Lower Side Vent 3109349.XXX* Power Vent Asm. 3108705.744** * Fill in “XXX” with color code numbers. For color codes, contact your supplier. ** Alternate instructions forwarded with the Ventilator Kit. For further information contact your dealer or distributor.
- Page 14 Positioning of shelves Put a screwdriver into the slot of the shelf lock. Insert the ends of the wire shelf on the left-hand Turn the screwdriver counterclockwise. side at the desired position. Remove the shelf locks from the wire shelf. Slide the wire shelf to the left.
