ENGLISH ¢SAFETY PRECAUTIONS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”...
Page 3
This product, when installed as indicated in the instructions contained in this manual, meets FCC requirements. Modification not expressly approved by DENON may void your authority, granted by the FCC, to use the product. 3. NOTE This product has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
ENGLISH Thank you for choosing the DENON AVR-1707 AV Surround Receiver. This remarkable component has been engineered to provide superb surround sound listening with home theater sources such as DVD, as well as providing outstanding high fidelity reproduction of your favorite music sources.
Setting the Crossover Frequency ················································47 Setting the Test Tone ···································································47 Operating the remote control unit Operating DENON audio components ·······································48 Setting the preset memory function ··········································48 Operating a component stored in the preset memory ····49 ~ 51 Setting the punch through function···········································52 Additional Information···························································...
Note Wall About the remote control unit In addition to controlling the AVR-1707, the attached remote control unit (RC-1048) can also be used to control the following products: q DENON component products w Component products other than DENON: •...
Getting Started Part names and functions For details on the functions of these parts, refer to the pages given in parentheses ( ). Front panel Power operation button SETUP MIC jack ·········································(10) (ON/STANDBY) ··········································(10) SYSTEM SETUP button ····························(40) Power indicator ·········································(10) SURR.
ENGLISH Getting Started Rear panel !1 !0 o PRE OUT terminal········································(8) EXT. IN terminals ·······································(14) DIGITAL terminals (Optical/Coaxial) ·······································(9, 15) AUDIO OUT terminals···························(9, 15) Speaker terminals ···························(8, 18, 43) Power supply cord·····································(18) AC outlets···················································(18) Remote control unit Indicator ····················(48, 52) Input source selector buttons ····························(19) System buttons········(50, 51)
Page 9
Getting Started [ Rear ] ZONE2 buttons···············(36) Input source selector/ Number buttons·······(19, 51) Tuner system/System buttons······················(31, 51) TEST TONE/DISPLAY button························(47, 51) Cursor buttons ···(11, 22, 51) NOTE: • If buttons on the front or rear are pressed strongly, the button on the opposite side will be activated too.
ENGLISH Easy Setup Procedure • This section contains the basic steps necessary to configure the AVR-1707 according to your listening room environment and the source equipment and loudspeakers you are using. • To set the sound field manually ( page 45).
Turn clockwise to tighten, then insert the banana plug. ¢ Connections • With the AVR-1707, up to ten speakers can be connected for surround playback. • When making connections, also refer to the operating instructions of the other components. Speaker Impedance 6 ~ 16 Ω/ohms...
Easy Setup Procedure Connecting a DVD player and monitor • To connect the video output from the DVD player to the AVR-1707, you only need to choose one connection type. For more information about the video up conversion function ( •...
Button name only : Buttons on the main unit and remote control unit Auto Setup The AVR-1707’s auto setup use the attached microphone to measure the acoustic properties in the room and automatically make the optimum settings. • To make the sound field settings manually ( page 45).
ENGLISH Easy Setup Procedure r Starting Auto Setup Press to start the Auto Setup. • Start the measurements. Measurement of each channel is performed as follows: 1: The subwoofer speaker is measured twice. 2: Not displayed when “ZONE2” is set at “Setting the Power Amplifier Assignment”...
Please check the following matters, reset the pertinent items, and measure again. Be sure to turn off the AVR-1707’s power before checking the speaker connections. D D H H...
Video signal ENGLISH The video conversion function With the AVR-1707, the Video signal and the S-Video signal which were inputted are mutually converted. And also the Video signal and the S-Video signal which were inputted are converted into a higher quality.
• With discs on which special copyright protection measures have been taken, however, the digital signals may not be output from the DVD player. In this case, connect the DVD player’s analog multi-channel output to the AVR-1707’s EXT. IN terminals for playback. Also refer to your DVD player’s operating Video camera / instructions.
• When recording to a VCR, it is necessary that the type of cable used with the playback source equipment be the same type that is connected to the AVR-1707 VCR OUTPUT terminal. Example: VCR IN → S-Video cable : VCR OUT → S-Video cable VCR IN →...
Connecting the XM terminal • AVR-1707 is the XM Ready ® receiver. You can receive XM ® Satellite Radio by connecting to the XM Passport System (sold separately) and subscribing to the XM service. • Plug the XM Passport System into XM terminal on the rear panel.
Connecting the iPod When using an iPod, you must connect the Control Dock for iPod (ASD-1R, sold separately) and the DOCK CONTROL jack on the AVR-1707 with a mini-jack and assign the iPod to any AUDIO and/or S-VIDEO terminal(s). The diagram below shows an example of connections for when the iPod is assigned to the DVD/VDP terminal.
Connecting Other Sources ZONE2 speaker out connections • When the surround back’s power amplifier is assigned to the ZONE2 output channel at Power Amplifier Assignment mode, the surround back speaker terminals can be used as the ZONE2 speaker out terminals ( page 36).
Press < ANALOG > to select “ANALOG”, < EXT. IN > to select “EXT. IN”. AUTO (All auto mode): The type of input signal is detected and the AVR-1707’s surround mode is switched automatically. Can be selected for sources for which the Digital In Assignment mode ( page 41) is made.
Using the surround modes Types of surround modes and their features The AVR-1707 is equipped with many surround modes. We recommend using the surround modes as described below in order to achieve the maximum effect for the specific signal source.
ENGLISH Selecting the play mode (DIRECT/STEREO) F G, ENTER The AVR-1707 is equipped with two 2-channel playback modes exclusively for music. Select the mode to suit your tastes. ¢ DIRECT mode This mode is for playing with high quality sound. The audio signals are transmitted directly, without passing through the tone circuits, etc.
Basic Operation Selecting the Dolby Digital and DTS Surround mode (only with digital input) Select an input source for which digital (COAXIAL or OPTICAL) is set ( page 41). INPUT MODE Press to select “AUTO”. [STANDARD] Press to select “STANDARD (Dolby/DTS Surround)”.
ENGLISH Basic Operation F G, ENTER SURROUND PARAMETER ENTER D H F G [STANDARD] SURROUND PARAMETER ENTER D H F G About the button names in this explanation < > : Buttons on the main unit : Buttons on the remote control unit Button name only : Buttons on the main unit and remote control unit Selecting the Dolby Pro Logic...
Basic Operation Selecting the DTS NEO:6 mode It is possible to play analog input signals and digital input signals (2- channels) in the surround mode. [STANDARD] Press to select “DTS NEO:6”. DOLBY PL DTS NEO:6 NEURAL SURROUND Play a program source. SURROUND PARAMETER Press F F G G...
ENGLISH Basic Operation Surround modes and parameters Channel output Surround Mode SURROUND FRONT SURROUND SUB- CENTER BACK WOOFER STEREO EXT. IN DOLBY PRO LOGIC DOLBY PRO LOGIC DTS NEO:6 DOLBY DIGITAL DTS SURROUND NEURAL SURROUND 5CH/7CH STEREO MONO MOVIE ROCK ARENA JAZZ CLUB VIDEO GAME MATRIX...
Page 29
Basic Operation ¢ Differences in surround mode names depending on the input signals Button Surround Mode Note ANALOG LINEAR PCM STANDARD DTS SURROUND DTS ES DSCRT6.1 DTS ES MTRX6.1 DTS SURROUND DTS 96/24 DTS + PL x CINEMA DTS + PL x MUSIC DTS + NEO:6 DTS NEO:6 CINEMA...
Page 30
ENGLISH Basic Operation Button Surround Mode Note ANALOG LINEAR PCM DIRECT DIRECT DSP SIMULATION 5CH/7CH STEREO MONO MOVIE ROCK ARENA JAZZ CLUB VIDEO GAME MATRIX VIRTUAL STEREO STEREO 4 : Mode selectable in default status C C : Selectable mode E E : Non-selectable mode NOTE : *1: If the Surround Back speaker setup is set to “None”, then “5CH STEREO”...
Using the DENON original surround modes The AVR-1707 is equipped with a high performance digital signal processor (DSP) that uses digital signal processing to recreate sound fields artificially. One of seven surround modes can be selected according to the program source and parameters can be further adjusted to achieve even more realistic sound fields.
ENGLISH Basic Operation F G, <ON/STANDBY> <PRESET •> SELECT/ENTER <POWER> <SURROUND MODE>, SURROUND PARAMETER [CH SELECT], ENTER D H F G [5CH/7CH STEREO] [DSP SIMULATION] SURROUND PARAMETER ENTER D H F G About the button names in this explanation < >...
Basic Operation Setting the tone control Adjust the bass and treble to suit your tastes. ¢ Adjusting the tone SURROUND PARAMETER Press D D H H Press to select “TONE DEF. ON”. In the direct mode, “TONE” cannot be selected. Press to select “OFF”.
ENGLISH Basic Operation <INPUT SELECTOR> BAND SHIFT STATUS CHANNEL TUNING SHIFT CHANNEL [FM/AM] [XM RADIO] STATUS D H F G [TUNER] TUNING [MODE] BAND [MEMORY] D H F G About the button names in this explanation < > : Buttons on the main unit : Buttons on the remote control unit Button name only : Buttons on the main unit and remote control unit...
Basic Operation XM Satellite Radio AVR-1707 is the XM Ready receiver. You can receive XM ® Satellite Radio by connecting to the XM Passport System (sold separately) and subscribing to the XM service. ¢ Introducing XM Satellite Radio There’s a world of audio listening pleasure beyond AM and FM. XM Satellite Radio.
User mode function The AVR-1707 is equipped with a function for storing the selected input source, the auto surround mode and input mode in the memory and selecting these settings when you want to use them.
Information on the latest version of the software can be obtained on the Apple Computer website. • With the AVR-1707 it is possible to display folder names and file names on the screen like titles. The AVR-1707 can display up to 64 characters, consisting of numbers, capital letters and small letters.
[MODE] Press for at least 2 seconds to switch from the Browse mode to the Remote mode. • “Remote iPod” is displayed on the AVR-1707’s display. [D D H H ] Watching the iPod’s screen, press to select [ENTER] [G G ] “Photos”...
MAIN ZONE. • When a sold separately room-to-room remote control unit (DENON RC-616, 617 or 618) is wired and connected between the MAIN ZONE and ZONE2, the remote-controllable devices in the MAIN ZONE can be controlled from ZONE2 using the remote control unit.
About the memory functions ¢ Last function memory The various settings set when the AVR-1707’s power is switched to standby are stored in the memory. When the power is turned back on, the settings made when the power was switched to standby are recalled.
Digital Inputs It is possible to assign the Control Dock for iPod’s (ASD-1R, sold separately) audio and/or video signals to any input terminals on the AVR-1707 and play them. This assigns the component video input terminals for the different input sources.
Page 42
ENGLISH Advanced Setup – Part 1 3. Option Setup Item No. O p t i o n S e t u p 2 ~ 4 5 ~ 11 Items To suit your preference, a surround back channel’s power Power Amp amplifier can be assigned to the front channel (“Front A”...
ENGLISH Advanced Setup – Part 1 About the front display The AVR-1707 is equipped with an alpha numeric front panel display that can also be used to check and adjust settings. Some representative front display examples are shown below. Item No.
CD, AUX, DVD, TV, VCR, V.AUX, CD-R: Assign the different source according to the devices connected to the AVR-1707’s input terminals. ENTER Press to enter the setting and switch to the iPod Assignment setting.
Advanced Setup – Part 1 Setting the Video Convert This sets whether or not to use the video conversion function. F F G G Press to set. ON, OFF: Select “ON” to use the video conversion function, “OFF” if you do not want to use it.
Front Bi-Amp connections Dynamic sound with a range wider than that of full range systems can be played by connecting bi-amp compatible speakers to the AVR-1707. Be sure to consult the owner’s manual of your bi-amp-capable speakers for further information before proceeding.
(output) level of +18 dB, which is extremely loud. Power On Volume Level: • LAST: The volume set when the AVR-1707 was last used is stored in the memory and set when the power is turned on. • – – – (Mute): The volume is always muted when the power is turned on.
ENGLISH Advanced Setup – Part 1 Setting the Auto Surround Mode Set whether or not to store the surround mode last played for the input signal. The surround mode used at last for the three types of input signals shown below is stored in the memory, and the signal is automatically played with that surround mode the next time it is input.
ENGLISH Advanced Setup – Part 2 • The distance changes in units of 1 foot (0.1 meters) each time the button is pressed. Select the value closest to the measured distance. • Please note that the difference of distance for every speaker should be 20 ft (6.0 m) or less.
Setting the preset memory function • DENON and other makes of components can be operated by setting the preset memory. • This remote control unit can be used to operate components of...
ENGLISH Operating the remote control unit [MODE SELECTOR 1] [MODE SELECTOR 2] Operating a component stored in the preset memory [MODE SELECTOR 1] to “AUDIO” or “VIDEO”. Set to the AUDIO side for the CD, TAPE or CD-R/MD position, and to the VIDEO side for the DVD/VDP, DBS/CABLE, VCR or TV position.
Page 53
Operating the remote control unit ¢ Functions of buttons for the different devices [Front] Device operated CD player CD recorder MODE SELECTOR 1 AUDIO MODE SELECTOR 2 CD-R / MD – – – – ON / SOURCE Preset channel selection Preset channel selection Preset channel selection SHIFT...
Page 54
– – DISPLAY RETURN – – Default setting DENON DENON (Preset code) (111) (111) Special remarks Special remarks: It is only possible to set the preset memory for one device per mode. When a new code is preset, the previous code is automatically deleted.
Operating the remote control unit [MODE SELECTOR 1] [MODE SELECTOR 2] [MEMORY] [INPUT MODE] Setting the punch through function “Punch Through” is a function allowing you to operate on CD, TAPE, CD-R/MD, DVD/VDP or VCR components when in the DBS/CABLE or TV mode. By default, nothing is set.
ENGLISH Additional Information About the speakers Surround back speakers Sound position directly to the rear can be achieved easily by adding a surround back speaker to a 5.1-channel system. In addition, the acoustic image extending between the sides and the rear is narrowed, thus greatly improving the expression of the surround signals for sounds moving from the sides to the back and from the front to the point directly behind the listening position.
Page 57
Additional Information Surround The AVR-1707 is equipped with a digital signal processing circuit that lets you play program sources in the surround mode to achieve the same sense of presence as in a movie theater. Dolby Surround [1] Dolby Digital Dolby Digital is the multi-channel digital signal format developed by Dolby Laboratories.
• DVD player’s audio output setting is produced. not set to bit stream. • DVD player is not DTS-compatible. • AVR-1707’s input setting is set to analog. Copying from DVD to • Copying between a source such as VCR is not possible.
Troubleshooting Symptom Cause “OFF AIR” is displayed • The selected channel is not currently • Select the another channel. in the XM mode. broadcasting. Receiving only XM • The XM Tuner is not activated. • Contact XM Radio. channels 0 and 1. Specifications ¢...
