Summary of Contents for Asko PROFESSIONAL WMC622VG
Page 1
Dear Customer, Thank you for choosing this quality product from ASKO. We hope it will meet your expectations and fulfi ll your needs for many years to come. Scandinavian design combines clean lines, everyday functionality and high quality. These are key characteristics of all our products and the reason they are greatly appreciated throughout the world.
Contents Before using your machine for the fi rst Washing time Sort your laundry. Transport protection Turn on the main power switch Packing material Open the washer door and load the Washer door washing Language selection Add detergent and fabric softener, as required Checking water hardness Select the programme...
Page 3
Contents Troubleshooting The washer door will not open Opening the door in an emergency The machine will not start After power failure Wet washing still in the machine Error messages Over fl ow fault Heating fault Technical information Information on energy labelling Energy labelling Technical data Transport protection...
Before using your machine for the fi rst time Transport protection Checking water hardness Remove any transport protection devices before The quantity of detergent needed depends, installing the machine. See the "Transport amongst other things, on how hard the water protection"...
Safety instructions General • Bleaches that contain chlorine can • Read the operating instructions and be replaced with oxygen-based keep them in a safe place. bleaches. Otherwise, a neutralization • Installation of water and electricity, if cycle should be performed by running required, should be carried out by a the Cotton program at the highest qualifi...
Safety instructions Installation See the "Installation" chapter. Overfl ow guard function If the machine’s water level rises above the normal level, the overfl ow guard function begins to pump water out and shuts off the water intake. If the water level has not dropped within 60 seconds, the program is terminated.
Child safety Keep an eye on children! • Always close the washer door and start the programme immediately after you have added detergent. • Do not allow small children to use or play with the washing machine. • Store detergent and fabric softener out of the reach of children.
Description of the washing machine 1. Main power switch 2. Dispenser 3. Programme panel 4. Serial number plate (on inside of washer door) 5. Washer door...
Dispenser 1. Pre-wash 2. Main wash with liquid detergent. Use the separator (A). 3. Main wash with powder detergent. Do not use the separator. 4. Fabric softener 5. Release button 6. Child safety catch...
Advice and tips before washing Here are some tips that may help you before soot and coff ee. Note however that diffi cult washing. protein stains with albumen content (blood, milk, meat and fi sh) fi rst need to be soaked in Sorting your laundry cold water as they are diffi...
Page 11
Advice and tips before washing greater impact on the environment. Try to use less detergent, and increase only if you are not satisfi ed with the results. NOTE! Due to environmental concerns, we discourage the use of strong chemicals. When using agents for bleaching or stain removal, there is a risk of rust (corrosion) and discolouration of the machine.
Washing Sort your laundry. Wash ball or net See the "Advice and tips before washing" If you use a wash ball or net, place it directly in chapter. the drum and select a programme without pre- Place underwired bras in a laundry net. wash.
Washing Select the programme Programme selector Time remaining Start Main power switch Program Stop The display shows the programme name, the White, 90 °C water temperature and the spin speed. Programme for normally to heavily soiled The washing machine has a number of laundry.
Page 14
Synthetics, 40 °C Disinfection, 40 °C Programme for synthetics, delicate blended Programme where the temperature reached materials and permanent press cotton. Suitable during the main wash is maintained above 40 °C for shirts and blouses. Follow the washing for 20 minutes. instructions for each garment.
Page 15
Washing Programme chart Water consumption (approx. liter) 1)+2) Program Cold Standard cotton 1200 1,50 3:25 Standard cotton 1200 0,90 3:05 Heavy wash 1200 2,60 2:05 Heavy wash 1200 1,40 1:40 Standard cotton 1200 1,07 3:05 Standard cotton 1200 0,91 2:55 White 1200 2,40...
Page 16
Washing Adjustment of the displayed washing time Advanced technology allows the appliance to sense the amount of laundry and add the required amount of water during the washing process. Depending on the washing load, washing time can be longer or shorter and the time displayed will be adjusted accordingly.
Washing Close the washer door and Once the program has fi nished press the Start button The text "Done" is shown on the display for 2 minutes. The machine then turns off . NOTE! Once the program is fi nished, the washer door will automatically unlock.
Settings You can change the following Water intake settings: (depending on the model) • Language Connecting to both the hot and cold water • Temperature °C/°F supplies reduces the wash time and reduces • Water intake the washing machine's electricity consumption. •...
Care and cleaning Cleaning the detergent compartment Cleaning the inside of the machine to avoid unpleasant smells Pull out the detergent compartment using the release button. Modern detergents often allow clothes to be washed at low temperatures. This means that small deposits can build up in the machine.
Care and cleaning 5. Place the agitator in the mounting hole with Rinse holes under the agitator the F-mark towards you. Ensure that all the If you suspect that objects such as nails or agitator fasteners are in their holes in the paper clips may have fallen into the wash drum.
Troubleshooting The washer door will not open D Push the tool downwards to open the 1. Check that the main power switch is on. washing machine door. 2. Has the power supply been cut off ? Check the house fuses (circuit breakers). If the temperature in the drum exceeds 60 °C, then the door lock will remain activated.
Troubleshooting Error messages Water inlet fault If an error occurs during the programme a Check: message is shown on the display. To exit the • that the tap on the water pipe is open. message after taking measures, turn the •...
Technical information Information on energy labelling Information sheet pursuant to the Commission Regulations (EU) No. 1061/2010 and 1015/2010 Model WM70.C Maximum washing load 6 kg Energy effi ciency class Annual energy consumption (AE 186 kWh per year Power consumption Standard cotton 60 °C with a full load (E 1,07 kWh t,60...
Technical information Information for test institute Energy labelling European test standard: EN 60456 Washing program: Standard cotton , 60 °C, 1200 rpm, 6 kg cotton Connection: Cold water 15 °C Test method for noise measurement: IEC-60704-2-4 Technical data Height: 850 mm Width: 595 mm Depth:...
Transport protection Remove the three transport bolts and the plastic 3. Remove the plastic covers from the plugs. plugs for locking the machine for transport Push the plastic covers into the three holes before using the machine. that contained the plugs. Save the plastic plugs in case the machine is moved in the future.
Installation Positioning the washing machine The washing machine can be installed as a built-in or freestanding unit. Place the machine on a fi rm surface with easy access to the plug. A. Built-in The washing machine can be installed under a counter top with a working height of 850-900 mm.
Installation Drainage connection Electrical installation A water outlet hose is included with the If the machine is delivered from the factory machine. with a plug attached, it can be connected to an This is attached to the machine's outlet and earthed wall socket.
Service Before contacting the service division Model Before you contact the service division, make designation sure that you know the model designation, type designation and serial number. The model designation can be found on the panel. The type designation and serial number Type plate can be found on the type plate on the inside of the washer door.
The selected programme is shown in the display. CLOSE THE WASHER DOOR AND PRESS THE START BUTTON The time remaining is shown in hours and minutes. We reserve the right to make changes. Gorenje, Partizanska 12, 3320 Velenje, Slovenija www.asko.com WM70.C PROFESSIONAL WMC622VG en (03-20)
