The system automatically bypasses any faulty point and arms all other triggers and sensors for the utmost possible protection. If you accidentally arm with

the hood, trunk or a door open, just close it (no need to disarm-and-rearm) and the system will again monitor that point.

The system's memory records the identity of the last eight activated or malfunctioning triggers and sensors, which allows your installer to instantly track down

malfunctions. To identify the triggers and sensors held in the system's memory, use the following procedure:

1. Remotely arm and disarm while pressing the blank button on the PlainView 2 switch.

2. The LED will flash 1-10 times to indicate the most recently activated point, pause, flash 1-10 times to indicate the second most recently activated

point, and so on.

3. Write down the number of flashes between pauses and refer to the chart above.

With the optional CliffNet Wizard, you'll see this chronological report right on screen.

If you hear three chirps when you disarm, it means that a trigger or sensor was activated in your absence. When you turn on the ignition, the LED will flash 1-10

times, pause, then repeat the flash cycle 4 more times. Count the flashes in one cycle and refer to the chart above.

You may set many of the features to your own preferences. Once you've changed a few settings, you'll find that programming the system is so easy that

you can even do it while driving. The system comes with all of its features preprogrammed as noted by the bold type in the Table of user-selectable features. To

change any of the settings, use the steps noted below. To restore the feature to its factory setting, just repeat the procedure.

NOTE: For greater programming ease and even more system control, consider the CliffNet Wizard Windows PC

software interface: www.clifford.com/wizard.

Briefly, here's how it will work:

You will pick a feature from the following Table of User-Selectable Features, noting the feature's column and row numbers.

•

You'll enter program mode by entering your valet/disarming PIN code and pressing the ✱ button of the dash- or console-mounted

•

PlainView 2 switch until you hear a chirp.

Press the blank PlainView 2 switch button the same number of times as the column number, then the ✱ button a number of

•

times equal to the row number.

1. Refer to the Table of user-selectable features and make note of the column (across) number and the row (down) number of the feature(s) you wish to

program.

2. Turn the ignition on, or start the engine (skip this step if the engine is running).

3. Enter your valet/disarming PIN code, then press and hold the ✱ button of the PlainView 2 switch for about 4 seconds until you hear a siren chirp.

4. Select the feature column: Press and release the blank button of the PlainView 2 switch the same number of times as the column number you wish.

Pause. You will hear the same number of chirps as the column number, audibly confirming your selection.

5. Select the feature row: Press and release the ✱ button the same number of times as the row number. You'll will hear a chirp each time you press to help

you count.

NOTE: You have 5 seconds to enter the row number after selecting the column number. If you wait too long, the system

jumps back to the "Feature Select" position (this is indicated with 3 chirps). If you wait another 60 seconds, the system

will exit program mode.

6. Pause. You will hear one or two chirps: Two chirps = ON, one chirp = OFF (If there is a NOTE for the selected feature, perform the actions noted).

NOTE: Some features, such as AutoStart (column 2, row 4) used with the optional IntelliStart 4 accessory, have

multiple settings. Simply reselect the feature additional times to progress through each possible setting.

7. You may now select another feature or exit program mode:

a. To select another feature in that same column, repeat step 5 within the next 5 seconds (after 5 seconds, 3 chirps mean you are back to the "Feature

Select" position).

b. To select a different feature column, go to step 4.

c. To exit program mode, turn the ignition off (you'll hear 3 chirps and the LED will turn off). If driving, just wait 60 seconds and the system will

automatically exit program mode.

If you make an error, just turn off the ignition and start again.

Automatic malfunction bypass with AutoReMonitoring™
