■ CI-V commands

The following commands are changed in, or added to
the conventional Command table.
Cmd. Sub cmd. Data
1A* 05 0198 See the right. Send/read the Front key customize
0199 See the right. Send/read the Front key customize
0200 See the right. Send/read the Front key customize
0201 See the right. Send/read the Front key customize
0202 See p. 9.
0203 See p. 9.
0204 See p. 9.
0205 See p. 9.
0206 See p. 9.
0207 See p. 9.
0208 See p. 9.
0209 See p. 9.
0210 See p. 9.
0211 See p. 9.
0212 See p. 9.
0213 See p. 9.
0214 See p. 9.
0215 See p. 9.
0216 See p. 9.
27* 00 See p. 10.
14 See p. 10.
15 See p. 10.
16 See p. 10.
20 00/01
*(Asterisk) Send/read data
Description
[VOX/BK-IN] setting
[AUTOTUNE] setting
[▲] setting
[▼] setting
Send/read the MIC key customize
[UP] setting
Send/read the MIC key customize
[DOWN] setting
Send/read scope edge 4 frequencies
for 0.03 - 1.60 MHz
Send/read scope edge 4 frequencies
for 1.60 - 2.00 MHz
Send/read scope edge 4 frequencies
for 2.00 - 6.00 MHz
Send/read scope edge 4 frequencies
for 6.00 - 8.00 MHz
Send/read scope edge 4 frequencies
for 8.00 - 11.00 MHz
Send/read scope edge 4 frequencies
for 11.00 - 15.00 MHz
Send/read scope edge 4 frequencies
for 15.00 - 20.00 MHz
Send/read scope edge 4 frequencies
for 20.00 - 22.00 MHz
Send/read scope edge 4 frequencies
for 22.00 - 26.00 MHz
Send/read scope edge 4 frequencies
for 26.00 - 30.00 MHz
Send/read scope edge 4 frequencies
for 30.00 - 45.00 MHz
Send/read scope edge 4 frequencies
for 45.00 - 60.00 MHz
Send/read scope edge 4 frequencies
for 60.00 - 74.80 MHz
Read the Scope waveform data
• Only when "Scope ON/OFF status"
(Command: 27 10) and "Scope
data output" (Command: 27 11) are
set to "ON," outputs the waveform
data to the controller.
Send/read the Scope Center mode,
Fixed mode, SCROLL-C mode, or
SCROLL-F mode setting
Send/read the Span setting in the
Center mode or SCROLL-C mode
Scope
Send/read the Edge number setting
in the Fixed mode or SCROLL-F
mode Scope
Send/read the Marker Position (FIX
Type/SCROLL Type) setting
(00=Filter Center, 01=Carrier Point)
DCommand formats
• [VOX/BK-IN] setting
Command: 1A 050198
Data
00 VOX/BK-IN
01 PRESET
02 Voice/Keyer/RTTY Memory 1
03 Voice/Keyer/RTTY Memory 2
04 Voice/Keyer/RTTY Memory 3
05 Voice/Keyer/RTTY Memory 4
• [AUTOTUNE] setting
Command: 1A 050199
Data
00 AUTOTUNE
01 PRESET
02 Voice/Keyer/RTTY Memory 1
03 Voice/Keyer/RTTY Memory 2
04 Voice/Keyer/RTTY Memory 3
05 Voice/Keyer/RTTY Memory 4
• [▲]/[▼] setting
Command: 1A 050200, 050201
Data
00 M-CH UP
01 M-CH DOWN
02 PRESET
03 Voice/Keyer/RTTY Memory 1
04 Voice/Keyer/RTTY Memory 2
05 Voice/Keyer/RTTY Memory 3
06 Voice/Keyer/RTTY Memory 4
8
