8.Manual Override

• The luminaire can be switched on for longer peroids via the
7
use of the manual override mode. This can be activated by
using the internal wall switch. Switch the internal wall
switch once OFF/ON within 2 seconds.
• The luminaire will continuously light for 6 hours, until the
fitting is set back to auto mode. To return to auto mode,
switch the internal wall switch OFF/ON again within 2
seconds.
• The unit will return to auto mode and now operate as
setup after the walk test procedure.

9. Troubleshooting Guide

Problem
The luminaire does
not switch on when
in the detection area.
1.5 - 2.0M
3M
Cause/Solution
Bulb faulty or missing.
Nearby light sources causing interference.
Redirect the PIR or light source if possible.
appro.90°
5M
Detection Area
7M
