Spare parts, accessories and wear parts

The IndraControl extension modules can be used for complex connections to
controls that cannot be operated at the S20 bus, such as interface modules to
Profinet, Profibus, CAN and Sercos or Safety connection.
The IndraControl extension modules may only be operated under the mounting
and installation
(temperature, degree of protection, humidity, EMC etc.) specified in this
documentation.
5 Spare parts, accessories and wear parts
5.1 Connector 24 V
Ordering code
XA-CN01
Tab. 5-1: Connector, 24 V

5.2 Connector set for the CAN module

Ordering code
S20-CNS 2S-O/D/UI/E1/E2
Tab. 5-2: Connector set CAN module

5.3 Bus base module

Ordering code
XA-BS11
Tab. 5-3: Bus base module for extension bus

5.4 End clamp

Ordering code
SUP-M01-ENDHALTER
Tab. 5-4: End clamp

5.5 Wear parts

There are no wear parts in the extension modules.
Bosch Rexroth AG R911345570_Edition 05
conditions, the
Part number
R911173741
Part number
R911173804
Part number
R911173772
Part number
R911170685
IndraControl XFE 01.1 Extension Mod-
ules Profibus, RT-Ethernet, Sercos, CAN
position and the
Description
24 V plug
Description
Connector set for the 24 V module and the
CAN module
Description
Bus base module for extension modules
Description
2 pieces of snap-on end brackets for 35
mm NS 35/7.5 or NS 35/15 carrier plate;
width: 9.5 mm
ambient conditions
