- Page 1 DUST/WOODCHIP EXTRACTOR MODEL NO: CDE35B PART NO: 6470310 OPERATING & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS GC0321 - REV 2...
-
Page 2: Product Specifications
INTRODUCTION Thank you for purchasing this CLARKE Dust Extractor. This device is designed to collect large dust particles - wood chips, sawdust etc. greater that 5 microns in size. When cutting materials which may be toxic (some hardwoods, MDF etc.), the user must wear a dust mask capable of filtering dust down to 1 - 1.5 microns. -
Page 3: General Safety Precautions
4. Never use a power product if any part is damaged. Have it inspected and repaired by your Clarke dealer. Do not use if the electric cable, plug, or the machine itself, is in poor condition. -
Page 4: Environmental Recycling Policy
14. Do not attempt to repair or modify the dust extractor or attempt any electrical repair yourself. Consult a qualified electrician or the Clarke Service Department on 020 8988 7400. ENVIRONMENTAL RECYCLING POLICY... -
Page 5: Electrical Connections
ELECTRICAL CONNECTIONS WARNING! READ THESE ELECTRICAL SAFETY INSTRUCTIONS THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE MAINS SUPPLY. Before switching the product on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. This product is designed to operate on 230VAC 50Hz. - Page 6 COMPONENTS When unpacking please check contents and advise your dealer immediately if any parts are missing. The essential components are as follows: • 1 x Operating Instructions • 1 x Base Plate (4) + 1 off & Motor Plate (20) + 1 off Collector Body & Motor (11 &...
-
Page 7: Tools Required
• Phillips screwdriver • Flat bladed screwdriver • 10mm spanner HOSE ACCESSORY KIT The CDE35B dust extractor will need to be connected to your woodworking appliance using the CDE Kit (part number 6470312) shown. This includes: • 2.5 metre x 100mm (ID) flexible hose - fits between collector &... - Page 8 • A flexible hose kit is available from your Clarke dealer. (see page 7) STORAGE For long term storage the machine may be wall mounted. Provided for this are two hooks (27), the hooks are fitted to the wall at a convenient location with the screw centres 170mm apart, using the appropriate fixings (not supplied).
-
Page 9: Operation
OPERATION DO NOT OPERATE WITHOUT ALL PARTS IN PLACE! Do not attempt to clean, remove or attach dust bags or carry out any servicing to the machine whilst it is in operation. CAUTION: THE BLOWER HOUSING CONTAINS A HIGH SPEED FAN BLADE THAT COULD AMPUTATE FINGERS, GRAB LOOSE CLOTHING AND NECKTIES ETC, AND PROPEL DUST AT VERY HIGH VELOCITIES. -
Page 10: Maintenance
Ensure the hose is kept in good condition. A damaged hose will seriously effect the efficiency of the dust extractor and should be replaced. Contact your CLARKE dealer for replacements. CARE & STORAGE 1. When not in use, switch off and unplug from the power supply and ensure the power cable is not left as a hazard for persons to trip over. -
Page 11: Troubleshooting
5. Ensure the wall fixings are of sufficient strength to support the machine, considering the machines weight and vibration during its operation. TROUBLESHOOTING Problem Possible cause Suggested Remedy Motor will not run 1. Defective switch, cable 1. Check electrical or motor. connections to all components or consult your dealer. -
Page 12: Parts Diagram
PARTS DIAGRAM Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 13: Component Parts List
COMPONENT PARTS LIST Description Castor Pan head screw M6 x 16 Spring washer 6 dia Base plate Pan head screw M5 x 10 Inlet cover Socket head screw-M6x20 Setscrew M8 x 10 Washer Collector body Washer 8 dia Nut M8 Hex head screw -M8 x 10 Hex head screw -M8 x 15 Hex head screw -M6 x 15... - Page 14 DECLARATION OF CONFORMITY - UK Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
-
Page 15: Declaration Of Conformity - Eu
DECLARATION OF CONFORMITY - EU Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
