Subject : Adding KX-TG3721BX1, KX-TGA371BX1 (for Philippine) to the KX-
TG3721BX Series.
Note: All other information is the same as KX-TG3721BXB Service Manual (Order No.
KM41108487CE). You can download and refer the Service Manual on TSN Server.
Please file and use this supplement manual together with the service manual for Model No.KX-
TG3721BXB/KX-TG3721BXN/KX-TG3722BXB/KX-TG3722BXN/KX-TGA371BXB/KX-TGA371BXN,
KM41108487CE .
TABLE OF CONTENTS
1 Exploded View and Replacement Parts List ------------ 2
1.1. Cabinet and Electrical Parts (Base Unit) ------------ 2
1.2. Cabinet and Electrical Parts (Handset) -------------- 3
1.3. Accessories ------------------------------------------------- 4
PAGE
(for Philippine)------- 5
Telephone Equipment
KX-TG3721BX1
Model No.
KX-TGA371BX1
2.4 GHz Digital Cordless Answering
System
1: Black Version
(for Philippine)
© Panasonic System Networks Co., Ltd. 2012
Unauthorized copying and distribution is a violation
of law.
ORDER NO. KM41202636SE
Advertisement
Related Manuals for Panasonic KXTG3721BX Series
Summary of Contents for Panasonic KXTG3721BX Series
-
Page 1: Table Of Contents
1.1. Cabinet and Electrical Parts (Base Unit) ------------ 2 1.2. Cabinet and Electrical Parts (Handset) -------------- 3 1.3. Accessories ------------------------------------------------- 4 1.4. Replacement Parts List (for Philippine)------- 5 © Panasonic System Networks Co., Ltd. 2012 Unauthorized copying and distribution is a violation of law. -
Page 2: Exploded View And Replacement Parts List
KX-TG3721BX1/KX-TGA371BX1 1 Exploded View and Replacement Parts List 1.1. Cabinet and Electrical Parts (Base Unit) 19 (*1) (CUSHION/LCD) Push the lead wire toward the arrow after it puts a seal. (*1) PCB1 Do not process a lead wire on jack holder. PCB2 Ref.No. -
Page 3: Cabinet And Electrical Parts (Handset)
2 8 mm Put it in the center. Note: (*1) This cable is fixed by welding. (*2) The rechargeable Ni-MH battery HHR-4MRT is available through sales route of Panasonic. (*3) Attach the SPACER (No. 115) to the exact location described above. -
Page 4: Accessories
KX-TG3721BX1/KX-TGA371BX1 1.3. Accessories... -
Page 5: Replacement Parts List (For Philippine)
KX-TG3721BX1/KX-TGA371BX1 1.4. Replacement Parts List Safety Ref. Part No. Part Name & Description Remarks (for Philippine) PNBC1345Z1 BUTTON, MESSAGE PS-HB PNJK1103Z KEYBOARD SWITCH 1. RTL (Retention Time Limited) PNLA1083Z ANTENNA Note: PNHR1387Z GUIDE, JACK PS-HB The “RTL” marking indicates that its Retention Time is PQJJ1T039M JACK, MODULAR K2ECYZ000001 JACK, DC... - Page 6 KX-TG3721BX1/KX-TGA371BX1 Safety Ref. Part No. Part Name & Description Remarks Safety Ref. Part No. Part Name & Description Remarks R102 PQ4R10XJ475 4.7M R611 D0GA103JA021 10k R103 PQ4R10XJ184 180k R612 D0GA332JA015 3.3k R104 PQ4R10XJ184 180k R613 D0GA332JA015 3.3k R105 PQ4R10XJ105 R665 D0GA103JA021 10k R106 PQ4R10XJ105...
- Page 7 KX-TG3721BX1/KX-TGA371BX1 Safety Ref. Part No. Part Name & Description Remarks Safety Ref. Part No. Part Name & Description Remarks C523 F1G1H100A722 10p PNJK1113R KEYBOARD SWITCH C601 ECUE1A104KBQ 0.1 PQHR11315Z GUIDE, SPEAKER ABS-HB C603 ECUE1C103KBQ 0.01 L0AA02A00095 SPEAKER C611 ECUE1A104KBQ 0.1 PQHS10784Y SPACER, SPEAKER NET C661...
- Page 8 KX-TG3721BX1/KX-TGA371BX1 Safety Ref. Part No. Part Name & Description Remarks Safety Ref. Part No. Part Name & Description Remarks J0JDC0000045 IC FILTER ECUE1H100DCQ 10p J0JDC0000045 IC FILTER ECUE1H100DCQ 10p (RESISTORS) ECUE1H100DCQ 10p D0GA102JA021 1k ECUE1H100DCQ 10p PQ4R18XJ3R3 C103 ECUE1H101JCQ 100p D0GA122JA015 1.2k C104 ECUE1H100DCQ 10p...
- Page 9 KX-TG3721BX1/KX-TGA371BX1 1.4.5. Fixtures and Tool Safety Ref. Part No. Part Name & Description Remarks PQZZ1CD300E JIG CABLE PNZZTG3721BX BATCH FILE CD-ROM PQZZ430PIR TIP OF SOLDERING IRON PQZZ430PRB RUBBER OF SOLDERING IRON KXTG3721BX1 KXTGA371BX1...
