INSTALLATION GUIDE
Advertisement
Related Manuals for Pentair EasyTouch
Summary of Contents for Pentair EasyTouch
- Page 1 EASYTOUCH / INTELLITOUCH ® ® CONTROL SYSTEM UPGRADE TO INTELLICENTER™ CONTROL SYSTEM (For Legacy Systems 2003-2012) Air Temp 65° F 8:00 A.M. 78° 84° Pool Features Lights 6.50 Schedule Usage Chemistry Status INSTALLATION GUIDE IMPORTANT SAFETY INSTRUCTIONS READ AND FOLLOW ALL INSTRUCTIONS...
- Page 2 EasyTouch/IntelliTouch Control System Legacy Upgrade Kits Installation Instructions CUSTOMER SERVICE / TECHNICAL SUPPORT Technical Support Customer Service Sanford, North Carolina (8 A.M. to 8.30 PM ET) 8 AM to 5.30 PM — Eastern and Pacific Times Phone: (919) 566-8000 Phone: (800) 831-7133...
- Page 3 This guide provides installation and operation instructions for the IntelliCenter Control System. Consult ™ Pentair Water Pool and Spa, Inc. with any questions regarding this equipment (see “Customer Service/Technical Support”, page ii). Attention Installer: This guide contains important information about the installation, operation and safe usage of this product.
- Page 4 EasyTouch/IntelliTouch Control System Legacy Upgrade Kits Installation Instructions IMPORTANT WARNING AND SAFETY INSTRUCTIONS Water temperature in excess of 100° F (37.7° C) may be hazardous to your health. Prolonged immersion in hot water may induce hyperthermia. Hyperthermia occurs when the internal temperature of the body reaches a level several degrees above normal body temperature of 98.6°...
- Page 5 EasyTouch/IntelliTouch Control System Legacy Upgrade Kits Installation Instructions IMPORTANT WARNING AND SAFETY INSTRUCTIONS FCC Regulatory Safety Notice FCC non-modification statement: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
- Page 6 EasyTouch/IntelliTouch Control System Legacy Upgrade Kits Installation Instructions Pentair Water Pool and Spa IMPORTANT SAFETY INSTRUCTIONS For Installation of Electrical Controls at Equipment Pad (ON/OFF Switches, Timers, and Automation Control Systems) Install all electrical controls at equipment pad, such as on/off switches, timers, and control systems, etc.
- Page 7 Control System ® ® Legacy Upgrade Installation Kits Overview This manual describes how to upgrade an EasyTouch or IntelliTouch Control System to the IntelliCenter Control System. The upgrade Installation Kits apply to the following: • Legacy Systems: EasyTouch PL4/PSL4 Control Systems, EasyTouch Control Systems ®...
-
Page 8: Table Of Contents
Note: INSTALLING THE WIRELESS ANTENNA KIT. See IntelliCenter Control System Installation Guide. CAUTION: If there are EasyTouch or IntelliTouch Control System installed accessories, such as an Indoor Control Panel or Wireless Remote, they will no longer function after installing the IntelliCenter Control System Upgrade Kit. - Page 9 EasyTouch/IntelliTouch Control System Legacy Upgrade Kits Installation Instructions BOX CONTENTS Legacy Kit P/N 522045, 522046, 523218, 523530 Outdoor Control Panel (i5P, i5X) PCBA (i10P / i10PS / i10D / i10X) (P/N 523143) Transformer Bracket Assembly P/N 520222 Six (6) Screws ...
-
Page 10: Removing The Existing Outdoor Control Panel
EasyTouch/IntelliTouch Control System Legacy Upgrade Kits Installation Instructions Removing the Existing Outdoor Control Panel The following upgrade installation instructions are for EasyTouch PL4/PSL4, EasyTouch or ® IntelliTouch Control Systems using the 2003-2012 (horizontal low voltage circuit breakers configuration on bezel) Load Center or Power Center. - Page 11 EasyTouch/IntelliTouch Control System Legacy Upgrade Kits Installation Instructions Removing the Existing Outdoor Control Panel (Continued) 5. Disconnect the transformer connector from the existing Outdoor Control Panel circuit board. 6. Disconnect all other connections from the existing Outdoor Control Panel circuit board.
-
Page 12: Install The New 4A And 5A Low Voltage Circuit Breakers Bracket And System Transformer
EasyTouch/IntelliTouch Control System Legacy Upgrade Kits Installation Instructions Install the new 4A and 5A Low Voltage Circuit Breakers Bracket and System Transformer Remove the existing circuit breakers and system transformer breaker bracket: 1. Remove the circuit breakers and bracket with transformer: Remove the two side screws on the side of the enclosure, and the screws on the back of the enclosure securing the circuit breaker bracket. - Page 13 EasyTouch/IntelliTouch Control System Legacy Upgrade Kits Installation Instructions Install the new 4A and 5A Low Voltage Circuit Breakers Bracket and System Transformer (Continued) Bracket screw Bracket screw Label Bracket screw Bracket screw Figure 5. Transformer Bracket Assembly System Transformer Bracket...
-
Page 14: Installing The Intellicenter Control System Outdoor Control Panel
EasyTouch/IntelliTouch Control System Legacy Upgrade Kits Installation Instructions Installing the IntelliCenter™ Control System Outdoor Control Panel 1. Install the IntelliCenter Outdoor Control Panel (1) and Bezel: Mount the Outdoor Control Panel and bezel onto the enclosure. Install the two screws to secure the bezel (2) to the enclosure. -
Page 15: Connecting And Configuring Pool And Spa Equipment
EasyTouch/IntelliTouch Control System Legacy Upgrade Kits Installation Instructions Connecting and configuring pool and spa equipment Please refer to the IntelliCenter™ Control System Installation Guide (P/N 522989) and the IntelliCenter Control System User’s Guide (522990) for the following information: • Connecting the System Transformer (and SCG transformer option if installed) to the IntelliCenter Outdoor Control Panel main circuit board •... -
Page 16: Installing The Wiring Label On The Enclosure Front Door
EasyTouch/IntelliTouch Control System Legacy Upgrade Kits Installation Instructions Installing the Wiring Label on the Enclosure Front Door 1. Remove the backing from the wiring label. 2. Affix the wiring label ((7), P/N 522612) onto High Voltage Cover panel. See Figure 10. - Page 17 EasyTouch/IntelliTouch Control System Legacy Upgrade Kits Installation Instructions Notes Note: Refer to page 3 where (parts index number) is shown...
- Page 18 EasyTouch/IntelliTouch Control System Legacy Upgrade Kits Installation Instructions Notes Note: Refer to page 3 where (parts index number) is shown...
- Page 19 EasyTouch/IntelliTouch Control System Legacy Upgrade Kits Installation Instructions Notes Note: Refer to page 3 where (parts index number) is shown...
- Page 20 10951 WEST LOS ANGELES AVE., MOORPARK, CA 93021 • (805) 553-5000 www.pentair.com All indicated Pentair trademarks and logos are property of Pentair Inc. or its global affiliates in the U.S.A. and/or other countries. Third party registered and unregistered trademarks and logos are the property of their respective owners ©...
