➤ Auxiliary harness (H2)

H2/1
BROWN
This wire supplies a 200 mA (-) output that can be used to honk the
vehicle's horn. It provides a pulsed output when the security system is
armed/disarmed and in the triggered sequence or in panic mode. In
most vehicles with (-) horn circuits this wire can control the vehicle's horn
without adding a relay. If the vehicle has a (+) horn circuit, an optional
relay must be used to interface with the vehicle's horn circuit.
Warning:
relay or a low-current input. Transistorized output can only
supply (-) 200 mA. Connecting directly to a solenoid,
motor, or other high-current device will cause the module
to fail.
H2/2 LT. BLUE
This input responds to a negative input with Warn Away or instant trig-
ger. It can be used with Directed dual-stage sensors. It can also be used
for hood and trunk pins and reports Zone 4.
© 2008 Directed Electronics All rights reserved.
(-) HORN HONK OUTPUT
Never use this wire to drive anything but a
(-) MULTIPLEX INPUT (ZONE 4)
