Primary Harness (H1); Auxiliary Harness (H2); Door Lock Harness (H3) - Directed Electronics Automate AM5 Installation Manual

➤ Primary harness (H1)

H1/1 RED/WHITE
H1/2 RED
BROWN
H1/3
YELLOW
H1/4
BLACK
H1/5
VIOLET
H1/6
BLUE
H1/7
GREEN
H1/8
H1/9 BLACK/WHITE
H1/10 WHITE/BLUE
H1/11 WHITE
ORANGE
H1/12

➤ Auxiliary harness (H2)

LT. BLUE
H2/1
BROWN
H2/2

➤ Door lock harness (H3)

H3/1 BLUE
H3/2
H3/3 GREEN
18
(-) 200mA auxiliary channel
(+) 12v Constant power input
(-) Chassis ground connection
(-) Instant trigger ( Zone1)
(-) 200mA Domelight supervison output
(-) 200mA Channel 3 / 2nd unlock output
(+) /(-) Light Flash output
(-) 500mA Ground When Armed
(-) Multiplex input (Zone4)
(-) Unlock, (+) Lock output
(-) Lock, (+) Unlock output
