5. Press F9 to Change capability filter.
6. Select Any Console.
7. To select the IOP that will support your intended console, do one of the following:
v If the adapter to be used for the intended console is under the same IOP as the previous console's
adapter, the console IOP is already correctly tagged. Go to step 8.
v If the adapter to be used for intended console is under a different IOP than the currently
configured console, place a 1 in front of the IOP to select it as the console IOP.
8. Verify an adapter for use as an optional alternate console. To verify the tagging for an alternate
console, find the IOP with the twinaxial adapter that will be used for the alternate console. It is
properly tagged if you see a > (greater than) symbol on the same line. If the > is not on this line,
enter an option 2 in front of the IOP being selected as the alternate console.
| Note: The selection of an alternate console only pertains when twinaxial workstations are to be the
alternate console and the console type is also twinaxial console. The alternate console must be
|
under a different IOP than the IOP tagged for use by Operations Console. Operations Console
|
| cannot be used as an alternate console. Do not tag the same IOP for the console and the
alternate console.
|
9. Press F3 to exit to the DST main menu.
10. Select Work with DST environment.
11. Select System Devices (skip this step if using SST).
12. Select Select Console.
13. If you are currently using Operations Console local console on a network (LAN), select Operations
Console local console on a network (LAN) and follow these steps to deallocate the network adapter:
Note: If this resource will be used for the service tools server (iSeries Navigator connections) or you
plan to use the local console on a network (LAN) as a backup console then you won't need to
do the clear. If either of these choices is true, continue with step 13e.
a. Select Operations Console (LAN). The LAN adapter currently in use should be shown.
b. Press F11.
c. Press F6 to clear the configuration data.
d. Press F7 to store this new value.
e. Press F12 twice to exit this window.
f. Select Console.
14. Select Twinaxial.
15. Press F3 to return to the DST main menu.
The system is now configured for use by your intended console type.
|
If you do not plan to use Operations Console as a backup console, do not remove or move it or its
adapter at this time. You may need it to debug problems.
The system value QAUTOCFG must be set to ON. Use one of the following methods to verify or set this
system value on the system:
v Use the WRKSYSVAL QAUTOCFG command.
v During a manual IPL, in the IPL Options window, select Y for Set major system options. Then, for
Enable automatic configuration, select Y.
Continue with Performing optional steps on the PC when changing from an Operations console to a
twinaxial console.
Related tasks
