Page 1: Operating Instructions
5” LCD TV Operating Instructions TFT5000 Model No. For assistance, please call: 1-800-645-4994 Or visit us at WWW.AUDIOVOX.COM Before connecting, operating or adjusting this product, please read these instructions completely. Please keep this manual for future reference 128-7104... - Page 2 The Lightning flash with the arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “DANGEROUS VOLTAGE” within the product’s enclosure that may be of sufficient magnitude to constitute a risk or electric shock to persons. The Exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing instructions in Federal Communication Commission Information (FCC)
- Page 3 compliance could void the user’s authority to operate this equipment Storage Store the LCD TV in a dark room at room temperature and low humidity in the original packing condition, to avoid condensation that may cause damage. Handling Since the LCD TV consists of glass and precise electronic components, it will be damaged by dropping it or excessive shock.
-
Page 4: Safety Instructions
Safety instructions To prevent injury due to use of this product, please read the “Safety Instructions” carefully before operation. Never watch TV while driving. Prohibited Could cause traffic accident or fall. The customer should not dismantle or repair unit. Dismantling prohibited Could cause fire or electric shock. - Page 5 CAUTION Never use other battery Prohibited than indicated. Never Broken battery and leakage would cause fire, injury or environ- ment pollution. Use the indicated AC connector or vehicular connector. Mandatory Use of anything “Use the other than indicated subassemblies or the designated would cause fire or components!”...
- Page 6 CAUTION Never have metallic or flammable objects Inserted or fall into the Prohibited Loudspeaker. Would cause fire and Charging and invalidate Water tightness. Special attention Needed in a family With children with Children. Never keep it at locations With higher temperature Due to closed car windows Prohibited Or sunshine.
-
Page 7: Use Instructions
Use Instructions Water tightness This set is waterproof and meets the requirement for JIS level 5 (spray protected*). Although it can be used under rainfall or water spraying, attention should be paid to the following points: Never immerse it in water. Never have it bonded to a lot of water. -
Page 8: Names And Functions Of Components
Names and functions of components Loudspeaker Liquid crystal Picture Desktop Stand The angle can be adjusted to obtain a clear picture. Control/indication panel VHF/UHF changeover button For VHF/UHF selection Telescope antenna Pull it out for use. Adjust its length and direction Depending on the wave conditions. -
Page 9: Battery Box Cover
Battery cavity Accommodate 4 pieces Of single 1 batteries in the Case of battery use. Battery box cover To be opened/ Closed for battery Insertion /fetching. Jack box cover External antenna terminal Connector in the use of the external antenna. LOCK of the battery Box cover LOCK box cover... -
Page 10: Power Supply
Power supply This product uses battery or external power When battery is used Use alkaline batteries. Order 4 pieces of alkaline batteries available in the market. Never use Zn-Mn batteries with very short life cycle, for it would cause unstable operation. - Page 11 Insert the battery. Insert 4 pieces of single 1 battery in the direction as indicated in the body of the TV set. Close the battery box cover. Close the LOCK of the battery box cover. Press [·PUSH·] until a snap is heard.
- Page 12 In the case of use of the external power supply Open the box cover snap. Press Connection to household Power supply Connect the separately purchased AC Connector to the external power supply Terminal. AC connector Rated input voltage AC100V Rated output DC6V/1A EIAJ unified Output plug...
-
Page 13: Switch On Power
Usage When watching TV Pull out the telescope antenna. Switch on power. Channel selection Power About battery replacement The indicator is off under normal conditions. The red indicator lights up when the Battery is used up. Once the red indicator lights up, there will be “no picture or sound ”... - Page 14 Select channels. Channel selection Power To the right To the left When the picture is not clear In the case of strong waves, channel selection will possibly stop before the correct channel is displayed. Continue channel selection until correct signal is received. Furthermore, there may possibly be better reception with the telescope antenna being shortened.
- Page 15 Adjust volume. Adjustment button. cut off power after watching. Channel selection Power CAUTION In winter and other dry seasons, touching of the antenna or terminals would lead to discharging due to static electricity on the fingertip, thus causing wrong operation. In such cases, Power off and on the unit.
- Page 16 CAUTION Before using it in a bathroom, make sure to close the battery box cover and jack cover. Failures or electric shocks would be caused when the battery box cover and the jack cover are left open. When an external antenna is used When the picture is not clear even with a pulled out antenna in a poor reception environment or in a building, use a separately purchased antenna adjuster connected with the external antenna to obtain a stable picture.
- Page 17 When used as a TV monitor When video cables are needed. Open the jack cover CAUTION It is not waterproof when the jack cover is left open. Never use video cables when it is used in a bathroom or other places where water is used Connect the video camera cable to the AV terminal.
-
Page 18: Troubleshooting
Troubleshooting In case of abnormalities, proceed with the following investigation before requesting servicing. In the following cases Used up battery. (Red indicator for No picture and Battery replacement is lit). No sound. Wrong installation battery Direction. Min. volume and brightness. AC connector/vehicular connector not connected correctly. - Page 19 Troubleshooting In the following cases Used up battery. Picture not clear (Red indicator for battery Rolling replacement is lit). Overlapping Spot or ripple Telescope antenna not adjusted correctly. Channel not selected properly. Poor receiving environment. Too strong waves Reflected waves from the receiving hill or building.
-
Page 20: Maintenance
REPAIR: (Important) DO NOT SHIP PRODUCT BACK FOR REPAIR WITHOUT FIRST CONTACTING AUDIOVOX AT 1-800-645-4994. NOTICES: The contents stated in this document and the product may be subject to change without prior notice. Please ask your distributor or go to information. -
Page 21: Specifications
Specifications Power supply Battery (alkaline dry battery, nickel hydrogen battery or NiCd battery, 4 Pieces (separately purchased) AC Power source 120VAC 60Hz 9.3W DC input 6VDC 500mA Power consumption Dimensions (WxHxD) Weight Picture size Number of pixels 224，640 pixels Display element Drive mode Optical source Signal receiving... -
Page 22: Customer Record
Repair and Warranty Service purpose. Model Number: ____TFT5000______ Serial Number: _________________________ _____________ Audiovox Electronics Corporation 150 Marcus Blvd Hauppauge, NY 11788 1-800-654-4994...
