Summary of Contents for Audiovox VOD715
-
Page 1: Dvd Player
PAUSE S OURCE ON OFF AUTO VO LUME S ELECT VIDEO MONITOR ELECTRONICS CORP . Released 5-13-03. VOD705 VOD715 DVD PLAYER WITH DROP-DOWN ® 128-6751 128-6751 1 of 31... -
Page 2: Important Notice
In the interest of safety, the VOD715 should never be installed where it will be visible, directly or indirectly, by the operator of the motor vehicle. -
Page 3: Safety Precaution
Congratulations on your purchase of the Audiovox VOD715 DVD Player with Drop-Down Video Monitor. The VOD715 has been designed to give you and your family many years of video entertainment in the mobile environment. Please read the directions that follow to familiarize yourself with the product and to ensure that you obtain the best results from your equipment. -
Page 4: Controls And Indicators Diagram
Controls and Indicators Diagram NOTE : Screen Mode Button Located on inside with screen in the closed position. 128-6751 4 of 31... - Page 5 5. STOP ( ) Button – To stop playing. 6. Infrared Transmitter and Sensor – Use to transmit audio to wireless headphones. Also allows the remote control to operate the VOD715 and to control other accessories in the system. 7. VOD715 Ventilation Opening.
- Page 6 22. FM Select Button – Each time this button is pressed will switched FMM cycles through (FM OFF – POD AUDIO – SAT AUDIO) and the frequency of the modulator will remain same. 23. VOLUME ( ) Button – Use this button to decrease the volume level of the headphone jacks.
-
Page 7: Remote Control Operation
3) Align the cover tabs with the remote control and press down until the cover clicks. The remote control will operate the VOD715 and most Audiovox VCP’s. It is not a universal remote control and will not control equipment from other manufacturers. -
Page 8: Dvd Function Descriptions
** Function not available on this model. 1. POWER Button* Press this button to turn the VOD715 on. Press the button again to turn the VOD715 off. 2. SOURCE Button* Video signals from video equipment connected to the audio / video inputs can be displayed on the monitor by pressing this button. - Page 9 6. Channel Up ( ) Button** Use this button to increase the channel number to the desired channel and to scroll upward in menu options. 7. MUTE Button Press this button to mute the audio. Pressing the button again restores sound to the previously set level. 8.
- Page 10 13. DISPLAY Button Press to display DVD Disc current information. Press DISPLAY button DVD Player Perform Once Display current TITLE & CHAPTER Twice Display current SUBTITLE 3 times Display current AUDIO language & channel 4 times Display current surround status...
- Page 11 17. REV ( ) Button* Allows the user to search in a backward direction at 2,4, 6 and 8 times the normal speed. 18. FWD ( ) Button* Allows the user to search in a forward direction at 2,4, 6 and 8 times the normal speed. 19.
-
Page 12: Number Buttons
26. SETUP Button Allows the user to select the DVD player’s options (Display, OSD Language, Defaults, Parental Control, Password, Exit Setup). 27. RIGHT ( ) Button Allows the user to shift to the right in the menu options. 28. PIX Button (PICTURE SELECT) Each time this button is pressed, the on screen picture adjustment display the “adjustment bars”... - Page 13 32. EJECT ( )Button* The disc will be ejected from disc compartment. 33. FM TRANSMITTER ON/OFF Button Turns FM Modulator power on/off. 34. SOURCE SELECT Button* With FM ON, used to selects the POD Audio (DVD and POD audio) or SAT Audio (Second IR input). With FM OFF, used to select SAT Audio or Car Audio.
-
Page 14: Overhead Dome Lights
4. Remember to turn the unit off and pivot the LCD to the locked position when not in use. Overhead Dome Lights The lights integrated into the VOD715 are controlled by a three position slide switch. Sliding the switch to the on position will turn the lights on. - Page 15 128-6751 15 of 31...
- Page 16 AV1 input. AUX A/V Input The VOD715 will accept an audio/video input through the RCA jacks located on the side of the unit. The audio / video device could be a video game system, video camera, or other input device.
-
Page 17: Dvd Basics
Regional Coding Both the DVD player and disc are coded by region. These regional codes must match in order for the disc to play. If the codes don’t match, the disc won’t play. This unit’s code is region 1. Other regional codes cannot be played in this unit. -
Page 18: Settings And Adjustments
Settings and Adjustments This chapter describes how to set and how to adjust using the on-screen SETUP menu. Using the Setup Menu Using the setup display, you can do the initial setup, adjust the picture quality, and set the various outputs. You can also set a language for the on-screen display and the setup display and limit playback by children. - Page 19 Settings for Display Press the SETUP button and select Display. The DISPLAY SETUP allows you to adjust screen setting (aspect ratio) Press and then use the ( )buttons to select the appropriate settings. 4:3 / PS This displays the wide picture on the screen with a portion of the left &...
- Page 20 Settings for Parental (Parental Control) This section of the SETUP Menu allows user to control the content of movie playback from G to Adult. The Parental Control function allows you to limit viewing to your preference. 1. Use the buttons to select from: G (Children) PG 13 NC-17...
-
Page 21: New Password
Settings for Password (Parental Control Password) Press the SETUP button and select PASSWORD. The PASSWORD SETUP allows you to change the parental control password. Press and then press Enter. OLD PASSWORD Input the old password or the default password (4 digits) NEW PASSWORD Input a new password (4 digits) using numeric buttons CONFIRM PWD... -
Page 22: Playing Audio Cds
Playing Audio CDs When playing an audio CD, the DISPLAY Banner appears automatically. It displays the current track and the amount of the time for that track playing, the total amount of time on the disc and the current time running on the disc. Press the DISPLAY button on the remote to display the DISPLAY Banner. -
Page 23: Playing Mp3 Discs
CD-R discs that have been encoded in MP3 format can be played on your DVD player. Press the DISPLAY button on the remote to DISPLAY Banner. The options below show you what happens when you press the DISPLAY button. - Page 24 When an MP3 disc is inserted in the player, the Smart Nav screen appears automatically. You can change folders and songs through Smart Nav. The DVD player plays the songs in order they were burned on to the disc. 1. If a disc is playing, press STOP. Press the up or down arrow button to go through the folder list on the right side of the Smart Nav screen.
- Page 25 Selecting a Play Mode You can choose what order the songs will play on a disc temporarily. The FOLDER play mode is the default. To access the play mode options, press STOP if the disc is playing. Press the right arrow button until the PLAY MODE option is highlighted. Use the up or down arrow to choose an option.
- Page 26 Program Play To use the program play option, you must create a playlist of songs in the order you want them to play. Note: Once you begin adding songs from a folder to create your play list, you cannot add songs from a different folder. 1.
-
Page 27: Troubleshooting
• Insert a disc with the label side facing Disc won’t play • Check the type of disc you put into disc tray. This DVD player only plays DVD’s, audio CDs and MP3s. • Both the unit and the disc are coded by region. - Page 28 SOLUTION PROBLEM • Picture is The disc might be damaged. Try distorted another disc. • It is normal for some distortion to appear during forward or reverse scan. • No forward or Some discs have sections that reverse scan prohibit rapid scanning or title and chapter skip.
-
Page 29: Replacement Parts
Replacement Parts Remote Control 136B3447 Specifications LCD Backlighting Edge Light Tube Resolution 1440 x 234 Pixels 336,960 Operation Temperature 32 -140º F (0 - 60º C) Storage Temperature -4 - 176º F (20 - 80º C) Backlight life 10,000 Hours Video Display System NTSC/PAL Headphone Audio Output... -
Page 30: 12 Month Limited Warranty
Applies to Audiovox Mobile Video Products AUDIOVOX ELECTRONICS CORP. (the Company) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within 12 months from the date of original purchase, such defect(s) will be repaired or replaced with reconditioned product (at the Company's option) without charge for parts and repair labor. - Page 31 For Customer Service Visit Our Website At .audiovox.com Product Information, Photos, FAQ’s Owner’s Manuals 128-6751 © 2003 Audiovox Electronics Corp., Hauppauge, NY 11788 128-6751 31 of 31...
