MATERIALS INCLUDED IN THIS PACKAGE: 1) VOD701 (136D3428) Video Monitor with DVD (1pc) / VOD702 (136D3429) TV/Video Monitor with DVD (1 pc) 2) 12 Pin Power / Signal harness (P/N 112B2821) (1 pc) 3) 3 Pin Power Wire Harness with choke (P/ N 112B3274) (1 pc)
GENERAL SYSTEM CONFIGURATIONS: The following is intended to provide some of the system configurations that are possible with the VOD701 and VOD702 series Drop Down Video Systems: System 1: Video Monitor without TV tuner (VOD701), with DVD and FM modulator.
VEHICLE PREPARATION: Locate a constant power source (+12v at all times), an accessory power source (+12v when key is in the ACC. and run positions, and 0v when key is off), and also a good ground generally, these wires can be found at the ignition switch or fuse-box. The mounting method and location will vary from vehicle to vehicle, so this manual will only focus on the installation of the video monitor and related console accessories.
MINI CONSOLE INSTALLATION: This page only covers special installation considerations for the mini-console installation. If the video monitor is to be installed in a vehicle with the mini console (P/N 102C3916 ), this console may need to be trimmed to fit the contour of the vehicle headliner. In this installation, the video monitor is mounted directly to the overhead cross-member in the roof using the mounting screw bosses.
Page 7
MOUNTING THE MINI-CONSOLE Roof Roof Support Headliner 5"x9"x3/4" Plywood Block or Optional VOHBKT (4) Self drilling screws (not supplied) Mini-Console Video Unit (4) #8 flat washers (4) #8x3/4" self tapping screws...
Page 8
VOD701 Red RCA (Audio Right) White RCA (Audio Left) Yellow RCA (Video) Power Connector "Y" Adapter 4 Pin for use with IR LED: Non-Stereo Harness - Optional Clean the IR Receiver Window on the front of the VCP. Installations Remove Adhesive Backing and Apply IR LED to IR Item# 5 Window on the Face of the VCP.
Page 9
VOD702 Red RCA (Audio Right) White RCA (Audio Left) Yellow RCA (Video) Power Connector "Y" Adapter 4 Pin for use with IR LED: Non-Stereo Clean the IR Receiver Window on the front of the VCP. Installations Remove Adhesive Backing and Apply IR LED to IR Item# 5 Window on the Face of the VCP.
Page 10
POD modulator (FTR300) using the POD remote control. Using an Audiovox XM satellite receiver 1) The Audiovox XM-01 satellite receiver does not operate the same as the Sirius, the FM modulator is external to the XM receiver.
CONNECTING THE DOME LIGHTS The dome lights in the video monitor require three connections to the vehicle's wiring. There are two common types of dome light circuits used, positive or negative switched. Positive systems supply voltage to the interior lights to turn them on, negative switched systems apply ground to illuminate the bulbs.
Negative Switched Dome lighting Factory Dome light circuit Troubleshooting: SYMPTOM: No power at Video Monitor Power but no video or sound Picture, but no sound Static on TV Stations (Tuner Version Only) No Infrared remote func- tions for VCP (or other com- ponents) Red / black - Lamp on To 12 pin...
