- Page 1 UHF Wireless Systems ESW-R210 UHF Synthesized Diversity Receiver Installation and Operation...
-
Page 2: Risk Of Electric Shock
AVIS interference and dropouts. The ESW-R210 also provides +12V DC on the antenna jacks to power in-line RF devices. The receiver is housed in a full-width standard 19" (1U) NE PAS OUVRIR rack-mountable case, with rack-mount adapters included. - Page 3 Output Connections There are two audio output jacks on the back panel: balanced (4 mV) and unbalanced (40 mV). Use shielded audio cable for the connection between the receiver and the mixer. If the input of the mixer is a from the "...
-
Page 4: Receiver Controls And Functions
Fig. B Receiver Front Panel Front Panel Controls and Functions (Fig. B) 1 POWER SWITCH: Press switch On and the Channel Designator Display (5) will light. 2 AF LEVEL INDICATOR: Indicates the audio modulation level of the received signal. The LEDs light up from left to right. -
Page 5: System Operation
LED – doing so will cause the system to overload and distort. The audio output level of the ESW-R210 has been optimized for best performance and no adjustment is necessary. The level control on the front panel controls the headphone jack only. -
Page 6: Specifications
32.768 kHz Operating Range 300' typical Operating Temperature Range 41° F (5° C) to 113° F (45° C) Frequency Response 100 Hz to 15 kHz ESW-R210 RECEIVER Receiving System Dual independent tuners, automatic switching diversity Image Rejection >100 dB Signal-to-noise Ratio >107 dB (IEC-weighted at ±40 kHz... - Page 7 Engineered Sound Designator Frequency (MHz) 728.125 728.250 728.375 728.500 728.625 728.750 728.875 729.000 729.125 729.250 729.375 729.500 729.625 729.750 729.875 730.000 730.125 730.250 730.375 730.500 730.625 730.750 730.875 731.000 731.125 731.250 731.375 731.500 731.625 731.750 731.875 732.000 732.125 732.250 732.375 732.500 732.625 732.750...
- Page 8 Notice to individuals with implanted cardiac pacemakers or AICD devices: Any source of RF (radio frequency) energy may interfere with normal functioning of the implanted device. All wire- less microphones have low-power transmitters (less than 0.05 watts output) which are unlikely to cause difficulty, especially if they are at least a few inches away.
