SERVICE BULLETIN
KODAK Multiloader
Eastman Kodak Company, Health Imaging, Imaging Service Center, Rochester, New York 14650
SERVICE BULLETIN NO. 240
MAY 1996
3053 KODAK MULTILOADER 700 / MULTILOADER 700 Plus
Adjusting the CASSETTE OPENER
This procedure is a replacement for the procedure in the Service Manual for the Kodak MULTILOADER 700,
Publication No. SM3053.
Important
Check that the OPENER SHOVEL is the correct length. If the OPENER SHOVEL was replaced or the length was
changed, do "LENGTH ADJUSTMENT", adjustment 3.18.1, in SM3053, 4/1990.
© Eastman Kodak Company
9B8327
Advertisement
Related Manuals for Kodak Multiloader 700
Summary of Contents for Kodak Multiloader 700
- Page 1 MAY 1996 3053 KODAK MULTILOADER 700 / MULTILOADER 700 Plus Adjusting the CASSETTE OPENER This procedure is a replacement for the procedure in the Service Manual for the Kodak MULTILOADER 700, Publication No. SM3053. Important Check that the OPENER SHOVEL is the correct length. If the OPENER SHOVEL was replaced or the length was changed, do “LENGTH ADJUSTMENT”, adjustment 3.18.1, in SM3053, 4/1990.
- Page 2 Figure 1 ROLLERS PRESSURE BOLTS CASSETTE STOP CASSETTE OPENER BRACKET CASSETTE END SWITCH 2 EXIT DOOR BRACKET CAMS CASSETTE H070_0150DCA H070_0150DC [1] Manually insert a CASSETTE and place in the centered position. Check that the CASSETTE is tight against the STOP at the CASSETTE END SWITCH. [2] Rotate the CASSETTE OPENER BRACKET fully up to the position in the illustration.
- Page 3 Figure 2 E-RING SWITCHING WASHERS SHAFT ROLLERS CASSETTE PRESSURE BOLTS BELT H070_0151DCA H070_0151DC Caution The WASHERS prevent the PRESSURE BOLTS from pressing excessively on the CASSETTE and causing the MOTOR to stall. [4] Manually move the CASSETTE OPENER BRACKET down and toward the PROCESSOR until you see the E-RING lift from each WASHER.
-
Page 4: Cassette Latch
Figure 3 [5] Move the CASSETTE OPENER BRACKET to the horizontal position. CASSETTE OPENER BRACKET H070_0152ACA H070_0152AC Important For Step 6 to Step 11, see Figure 4. [6] Now move the CASSETTE OPENER BRACKET down until • the PRESSURE BOLTS press onto the CASSETTE LID •... - Page 5 Figure 4 2 SCREWS CASSETTE OPENER BRACKET PRESSURE OPENER BOLT SHOVEL CASSETTE LATCH CASSETTE STOP 2 mm (0.08 in.) H070_0153ECA H070_0153EC...
-
Page 6: Ball Bearing
Figure 5 2 SETSCREWS ENTRANCE DOOR CAM BALL BEARING ENTRANCE DOOR CAM H070_0154DCA H070_0154DC [12] Move the CASSETTE OPENER BRACKET up fully and toward the front of the MULTILOADER. [13] Remove the CASSETTE. [14] Check the alignment of the edges of the ENTRANCE DOOR CAM and the BALL BEARING. If necessary: •...
