Makita DTL062 Instruction Manual
Cordless angle impact wrench
Hide thumbs
Also See for DTL062:
- Instruction manual (53 pages) ,
- Instruction manual (29 pages) ,
- Instruction manual (53 pages)
Table of Contents
Advertisement
Quick Links
Advertisement
Table of Contents
Related Manuals for Makita DTL062
Summary of Contents for Makita DTL062
- Page 1 INSTRUCTION MANUAL Cordless Angle Impact Wrench DTL062 DTL063 Read before use.
-
Page 2: Specifications
Vibration The vibration total value (tri-axial vector sum) deter- Noise mined according to EN62841: The typical A-weighted noise level determined accord- Model DTL062 ing to EN62841: Work mode : impact tightening of fasteners of the Sound pressure level (L ) : 88 dB (A) maximum capacity of the tool... - Page 3 Model DTL063 Do not expose power tools to rain or wet con- Work mode : impact tightening of fasteners of the ditions. Water entering a power tool will increase maximum capacity of the tool the risk of electric shock. Vibration emission (a ) : 16.5 m/s Do not abuse the cord.
- Page 4 Battery tool use and care Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type of battery pack may create a risk of fire when used with another battery pack. Use power tools only with specifically desig- nated battery packs. Use of any other battery packs may create a risk of injury and fire. When battery pack is not in use, keep it away from other metal objects, like paper clips, coins, keys, nails, screws or other small metal objects, that can make a connection from one...
-
Page 5: Functional Description
CAUTION: DO NOT let comfort or familiarity Only use genuine Makita batteries. with product (gained from repeated use) replace strict Use of non-genuine Makita batteries, or batteries that adherence to safety rules for the subject product. have been altered, may result in the battery bursting causing fires, personal injury and damage. It will also MISUSE or failure to follow the safety rules stated in this void the Makita warranty for the Makita tool and charger. - Page 6 Battery protection system (Lithium- Indicator lamps Remaining capacity ion battery with star marking) Lighted Blinking 75% to 100% 50% to 75% 25% to 50% 0% to 25% Charge the battery. The battery may have malfunctioned. ► 1 . Star marking Lithium-ion batteries with a star marking are equipped with a protection system. This system automatically NOTE: Depending on the conditions of use and the cuts off power to the tool to extend battery life.
- Page 7 Lighting up the front lamp ASSEMBLY CAUTION: CAUTION: • Do not look in the light or see the source of light • Always be sure that the tool is switched off and directly. the battery cartridge is removed before carrying out any work on the tool. Selecting correct socket Always use the correct size socket for bolts and nuts. An incorrect size socket will result in inaccurate and inconsistent fastening torque and/or damage to the bolt or nut.
-
Page 8: Operation
Adjusting the angle head The angle head can be adjusted 360°(8 positions in 45-degree increments). To adjust it, loosen the hex bolt and remove the angle head. Adjust the angle head to the desired position and rein- stall it so that the teeth on the housing will match up with the grooves in the angle head. Then tighten the hex bolt to secure the angle head. ► 1 . -
Page 9: Maintenance
Never use gasoline, benzine, thinner, alcohol or the like. Discoloration, deformation or cracks (408) may result. To maintain product SAFETY and RELIABILITY, repairs, (M8) (306) any other maintenance or adjustment should be per- formed by Makita Authorized Service Centers, always using Makita replacement parts. (204) OPTIONAL (M6) (102) ACCESSORIES Fastening time CAUTION: NOTE: •... - Page 12 Makita Europe N.V. Jan-Baptist Vinkstraat 2, 3070 Kortenberg, Belgium Makita Corporation 3-11-8, Sumiyoshi-cho, Anjo, Aichi 446-8502 Japan 885277B222 www.makita.com 20190423...
