SensorRail
™
ADRL3TRK Series
SpeedDome
Ultra Programmable
®
Dome on a Rail
Service Guide
CAUTION: Only a certified
installer is authorized to install this
equipment. Installation by anyone
else will void the SensorRail
warranty.
Contents
About this Guide.................................................... 1
About the Product.................................................. 1
Theory of Operation .............................................. 2
Preventive Maintenance...................................... 12
Functional Check ............................................. 12
Structure Check and Maintenance................... 12
Trolley Check and Maintenance ...................... 13
Servicing.............................................................. 15
Firmware Upgrade ........................................... 15
Motor Replacement.......................................... 17
CPU Board Replacement................................. 18
Wires, Brackets ................................................ 18
KST25DC Dust Collector Kit ............................ 20
Copper Install Tool ADRLCIT .......................... 23
RF Attenuator................................................... 25
Light Reduction Kit ........................................... 25
Antenna Bracket Replacement ........................ 28
RF Link DIP Switch Settings ............................ 28
Self-Tapping Screw Installation ....................... 29
End Cover Replacement.................................. 29
Ordering Parts ..................................................... 30
Specifications ...................................................... 33
Declarations ........................................................ 34
© 2006 Sensormatic Electronics Corporation
SENSORRAIL IIIE
SERVICE GUIDE
IIIE
About this Guide
This guide explains how to service the SensorRail
IIIE system. However it does not explain:
• How to repair or replace components on the
CPU board.
• How to program or operate the system. Refer to
SensorRail IIIE User Guide 8200-0593-04.
• Product specifications. Refer to SensorRail IIIE
Installation Guide 8200-0593-02.
If you need assistance, contact...
American Dynamics Technical Services
United States:
Toll Free 800-507-6268, Option 2
International: 561-912-6259, Option 2
Fax: 845-624-7658
In Europe:
Technical Services at EMEA AD Technical Support
+800 CALL TYCO or (+800 22 55 8926)
From the UK: 08701 238 787
Direct: +31 475 352 722
Fax: +31 475 352 725
Hours: 09:00-17:00 CET-EET-GMT
About the Product
The SensorRail IIIE system enables a SpeedDome
Ultra dome camera to transmit video as it moves
along a rail to the ideal surveillance position.
The system consists of:
• 2.5m rail sections (number determined by the total
length of the rail) with installation hardware
• A light reducing section at each end of the rail
• Ceiling suspension assembly, which includes M8
threaded rods, ceiling attachment hardware (not
supplied), and mounting stirrups
• Copper tracks
• Camera trolley with dome camera, RF transmit
antenna, and motor
• PowerRail module that supplies dc power to the
camera trolley, converts RS-422 data to RS-232 data
used by the trolley, and receives the video signals
from the dome camera
• Trolley stop and retrieval tool
•
RF receive antenna.
1 of 34
8200-0593-03, REV. A
