Omron H2F-D Quick Start Manual

Motor Time Switch
H2F-D
ON/OFF Control 48 Times per Day in 15-min
Increments
The H2F-D is a Low-cost Time Switch for Affordable
Operation in a Compact DIN 72 x 72-mm Body.
Choose the Ideal Model to Match the Application.
• Just insert the trippers for easy setup.
• Make exact time settings using the dial.
• Three mounting methods.
• Lineup includes models with power interruption backup.
• Safety standards: UL and CSA (except for H2F-30/-31).
The H2F-DM, -DMC, -DMF, -DMFC, -30, and -31 use
nickel metal hydride batteries.
Dispose of the batteries at a battery recycling location.
Replacement batteries are not available for previous H2F
Time Switches from March 2006 and earlier. Replace the
entire H2F Time Switch. Refer to Notice on page 7.
Ordering Information
Control Drive Power
cycle method interruption
backup
Daily Synchronous No
(24 hours) motor
Quartz motor Yes
(See note.)
Note: Always use the Time Switch with the Y92S-42 Battery mounted.
■ Accessories (Order Separately)
Name
Trippers (1 set for ON and OFF) (See note 1.) Y92S-21
Battery (See note 2.)
Power supply Mounting
voltage method
Control
output
100/110/120 VAC Model
200/220/240 VAC
100 to 240 VAC
12 to 24 VDC
Note: 1. Three gold-colored trippers for ON and three silver-colored
Model
Y92S-42
72 mm
For the most recent information on models that have been certified for
safety standards, refer to your OMRON website.
Flush mounting
SPST-NO SPDT
H2F-D H2F-DC
H2F-D H2F-DC
H2F-DM H2F-DMC
H2F-30 ---
trippers for OFF are enclosed with the H2F-D. Separately order
trippers if more are required.
2. The battery is built into the H2F-D. When the battery is nearing the
end of its service life, order the model number listed at the left.
CSM_H2F-D_DS_E_3_1
P S
E
72 mm
Surface mounting/
track mounting
SPST-NO SPDT
H2F-DF H2F-DFC
H2F-DF H2F-DFC
H2F-DMF H2F-DMFC
--- H2F-31
