Owner's Manual
Quick Installation ...................................4
Basic Operation .....................................5
UPS On/Off ..........................................5
LED Indicators .....................................5
UPS Systems
OMNIVSX650A
(Series Number: AG-04F0)
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
Copyright © 2020 Tripp Lite. All rights reserved.
Model:
Features ................................................6
UPS Features ......................................6
Battery Replacement ............................7
Storage and Service ..............................7
Regulatory Compliance ..........................8
1

Advertisement

Table of Contents
loading

Related Manuals for Tripp Lite OMNIVSX650A

Summary of Contents for Tripp Lite OMNIVSX650A

  • Page 1: Table Of Contents

    UPS Features ........6 Basic Operation ........5 Battery Replacement ......7 UPS On/Off ..........5 Storage and Service ......7 LED Indicators ........5 Regulatory Compliance ......8 1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support Copyright © 2020 Tripp Lite. All rights reserved.

  • Page 2: Important Safety Instructions

    • Connect the UPS to an outlet that is adequately protected against excess currents, short circuits and earth faults as part of the building installation. Agency Series Dimensions Output Short- Model Number Number (H x W x D) Weight AC Fuse/Breaker Circuit Current OMNIVSX650A AG-04F0 142 x 101 x 300 mm 4.8 kg Fuse: T5AL, 250VAC Approx. 66.2A Peak...
  • Page 3 • CAUTION: Do not open or mutilate batteries. Released electrolyte is harmful to the skin and eyes. It may be toxic. UPS and Battery Recycling Please recycle Tripp Lite Products. The batteries used in Tripp Lite products are sealed lead acid batteries. These batteries are highly recyclable. Please refer to local codes for disposal requirements.

  • Page 4: Quick Installation

    1. Make sure that the UPS is plugged into a live AC outlet. 2. Press the power button to turn on the UPS. A beep should sound when the UPS starts. 3. If the UPS still does not start, contact Tripp Lite Tech Support for assistance.

  • Page 5: Basic Operation

    Basic Operation UPS ON/OFF • Plug the UPS into a live, grounded outlet. The green LED will illuminate, the battery charger will engage as necessary and the SURGE PROTECTED outlets will begin passing power. • Plug equipment into the UPS: You will overload the UPS if the total volt-amp (VA) ratings for all the equipment connected to the BATTERY/ SURGE PROTECTED outlets exceed the UPS output capacity.

  • Page 6: Features

    AC Power Input: Use the Australian power cord to connect the OMNIVSX650A to the main power source. Replaceable Input Fuse: Protects your electrical circuit from overcurrent draw from the UPS load. If the fuse has blown, remove some of...

  • Page 7: Battery Replacement

    The RMA number, along with shipping instructions will be emailed to you. Any damage (direct, indirect, special or consequential) to the product incurred during shipment to Tripp Lite or an authorised Tripp Lite service centre is not covered under warranty.

  • Page 8: Regulatory Compliance

    Regulatory Compliance Identification Numbers For the purpose of regulatory compliance certifications and identification, your Tripp Lite product has been assigned a unique series number. The series number can be found on the product nameplate label, along with all required approval markings and information. When requesting compliance information for this product, always refer to the series number.
